- Page 1 V RM IR N Freedom - Lagoon - Vintage I N S T R U C T I O N M Freedom (2217) Freedom (2217) Lagoon (2219) Vintage (2219)
- Page 2 No part of this manual may be reproduced in any form what so ever (print, photocopy, microfilm or any other process) without written permission of the publisher, or processed, duplicated or distributed by using electronic systems. © N.V. Vermeiren N.V. 2015...
-
Page 3: Table Of Contents
2217, 2219 2015-03 Contents Preface ............................2 Product description..................... 3 Intended Use ........................ 3 Technical specifications ....................4 Drawing ........................5 Location identification plate ..................5 Accessories ........................6 ... -
Page 4: Preface
First of all we want to thank you for putting your trust in us by selecting one of our tricycles. The Vermeiren tricycles are the result of many years of research and experience. During the development, special attention was given to the ease of use and the serviceability of the tricycles. -
Page 5: Product Description
The tricycle should not be used to transport heavy objects. Use only Vermeiren approved accessories. The manufacturer is not liable for damage caused by the lack of or improper service or as a result of not following instructions from this manual. -
Page 6: Technical Specifications
Technical terms below are valid for the tricycle in standard settings. Make Vermeiren Address Vermeirenplein 1/15, B-2920 Kalmthout Type Tricycle Description 2217 2219 Freedom Lagoon, Vintage Maximum occupant mass 110 kg 125 kg Maximum load basket 25 kg 25 kg 670 mm 768 mm... -
Page 7: Drawing
2217, 2219 2015-03 Drawing 1 = Handgrips 2217 2 = Gear shifter 3 = Handlebar 4 = Lever brakes 5 = Front reflector 6 = Mudguards 7 = Front brakes 8 = Front wheels 9 = Frame 10 = Pedals 11 = Chain cover 12 = Rear wheels 13 = Rear reflector... -
Page 8: Accessories
2217, 2219 2015-03 Accessories Handlebars Adjustable handlebar bracket Hand holder / belt Handlebar lock system Back support / pelvic support Adjustable saddles Saddle tube with shock absorber Pedals with straps / foot supports ... -
Page 9: Use
2217, 2219 2015-03 This chapter describes the everyday use. These instructions are for the user and the specialist dealer. The tricycle is delivered fully assembled by your specialist dealer. Only the handlebar needs to be adjusted upwards. The instructions intended for the specialist dealer on how to set up the tricycles are given in §... -
Page 10: Operating The Gear Shifter
The Vermeiren tricycles 2217, 2219 have been designed entirely for your comfort. This tricycle can be adjusted to individual requirements as explained below. To find a service facility or specialist dealer near you, contact the nearest Vermeiren facility. A list of Vermeiren facilities can be found on the last page. -
Page 11: Manner Of Delivery
2217, 2219 2015-03 Manner of delivery The Vermeiren tricycles shall be delivered with: 1 frame with rear and front wheels pedals saddle handlebar + handgrips bell basket instruction manual accessories Torque Adjust the brakes Adjust the brakes according following rules: 1. -
Page 12: Adjusting The Chains
2217, 2219 2015-03 Adjusting the chains The wheels of the tricycle are driven by a chain on the rear axle. For first time use the chains are set in the factory. After a while it is possible that the chains runs off the axle. -
Page 13: Adjusting The Saddle
2217, 2219 2015-03 Adjusting the saddle CAUTION: Risk of injury - Never adjust the saddle when the user is sitting on the saddle. CAUTION: Risk of injury – Check that the saddle is firmly secure before using the tricycle. Adjust the height of the saddle as follow (stepless): ... -
Page 14: Maintenance
Use only inflating equipment which complies with regulations and indicates the pressure in bar. We do not accept any liability for damage caused by using inflation equipment not supplied by the manufacturer. Maintenance For the maintenance manual of the tricycles refer to the Vermeiren website: www.vermeiren.be. Page 12 ... - Page 15 Dealer´s stamp: Dealer´s stamp: Date: Date: Dealer´s stamp: Dealer´s stamp: Date: Date: Dealer´s stamp: Dealer´s stamp: Date: Date: For service checklists an additional technical information, please see our specialist dealers nearest to you. More information on our website at: www.vermeiren.com.
