DESCRIPTION
Aluminium Structure
Powder coated
CONFORM
International regulation
The assembly time for tennis umpire chair is estimated at 60 minutes with 1 people.
The equipment has to be regularly maintained by the owner. It is recommended to:
- Check every week that all the bolts are correctly tightened
- Fix paint defects if the unit has been damaged, using the adapted paint specified by the
manufacturer.
- Replace all damaged or missing parts with a spare part recommended by the manufacturer.
- Clean the product by using dishwasher soap, clean water, and soft cloth.
One full year parts and labour guarantee. Every claim regarding the condition of the delivered equipment
has to be done within the warranty period following receipt of the product.
The warranty will not apply to:
-
Any degradation during transport.
-
Any degradation due to poor maintenance.
-
Any degradation due to use differing from which the product was intended.
-
Any defect claimed after the end of the warranty period.
-
Any damage due to a faulty installation or assembly of the product.
All manuals and user guides at all-guides.com
PRODUCT REF
ASSEMBLY TIME
MAINTENANCE
WARRANTY
ASSEMBLY INSTRUCTIONS
TENNIS UMPIRE CHAIR
S25332
:
UNIT
Advertisement
Related Manuals for SODEX S25332
Summary of Contents for SODEX S25332
- Page 1 All manuals and user guides at all-guides.com ASSEMBLY INSTRUCTIONS TENNIS UMPIRE CHAIR S25332 UNIT PRODUCT REF DESCRIPTION Aluminium Structure Powder coated CONFORM International regulation ASSEMBLY TIME The assembly time for tennis umpire chair is estimated at 60 minutes with 1 people.
-
