DETAILS
SODEX INTERNATIONAL
18 rue de l'avenir – Bât. 224
14650 CARPIQUET
Phone: + 33 (0) 2.31.53.78.70
Email: karine.chaigneau@sodexinternational.com
DESCRIPTION
Alu structure ø101.6
Plastified
5.60x11m
CONFORM
European norm
NF EN 16579
The time to make the assembly of the goal is estimated at 30min at 3 persons (sealing not included). It is
recommanded to use a lift machine for the installation of the post into the sheaths.
The equipement has to be regularly maintained by the owner. It is adviced to:
- Check every week that all the screws are correctly tightened
- Fix paint defects if the module has been damaged, using the adapted paint, specified by the manufactu-
rer.
- Replace all damaged or missing parts with a spare part recommended by the manufacturer.
- Clean the product by using dishwasher soap, clean water, and soft cloth.
If the forecast planned a bad weather (strong wind,...), the goal should be removed from the sheaths and
put on the ground.
One full year parts and labor guarantee. Every claim regarding condition of the delivered equipment has to
be done within the legal period of the reception of the material. The warranty will not apply to:
-
all degradation during the transport.
-
all degradation due to use differing from which was intended.
-
all degradation due to poor maintenance.
-
any defect claimed after the end of the legal period.
-
any damaged due to a faulty installation and assembly of the module
11M ALU RUGBY GOAL
PRODUCT REF
ASSEMBLY TIME
MAINTENANCE
WARRANTY
PRODUCT SHEET
S20112
:
PAIR
Advertisement
Related Manuals for SODEX S20112
Summary of Contents for SODEX S20112
- Page 1 PRODUCT SHEET 11M ALU RUGBY GOAL S20112 PAIR PRODUCT REF DETAILS SODEX INTERNATIONAL 18 rue de l’avenir – Bât. 224 14650 CARPIQUET Phone: + 33 (0) 2.31.53.78.70 Email: karine.chaigneau@sodexinternational.com DESCRIPTION Alu structure ø101.6 Plastified 5.60x11m CONFORM European norm NF EN 16579 ASSEMBLY TIME The time to make the assembly of the goal is estimated at 30min at 3 persons (sealing not included).
- Page 2 FIXATION & SEALING End zone line NB: All the dimensions are in millimeter Dig 2 holes for the fixation of the sockets according to the written dimensions. - Put the sockets on the holes. Be sure that at the end, the ground is at the same level. - Realize the sealing with concret CPJ45 do- sed by 350 kg.
-
Page 3: Included Items
ASSEMBLY Before the assembly and before putting the posts in the sockets ,be sure that the goal is on the field zone and once the goal is in position, check that the runners are positioned outside the field zone. NECESSARY TOOLS (NOT INCLUDED) Mallet Allen wrench10mm INCLUDED ITEMS... - Page 4 ASSEMBLY 2– ASSEMBLY OF THE CROSSBAR (x4) STEP 1 STEP 2 NECESSARY ITEMS 3– ASSEMBLY OF THE POSTS IN THE SOCKETS (x2) End zone INSTALLATION OF THE POSTS IN THE SOCKETS : 800 mm...
-
Page 5: Packing List
PACKING LIST RUGBY 11M ALU GOAL PRODUCT REF S20112 Index A PAIR NOMENCLATURE Package Weight Dim. Index Designation Description Quantity Packing Method N° (kg) (mm) Upper and Bottom Post Plastic bubbles+cardboa Left+ 1 + 1 + 1 rd 5 layers...
