SODEX S30052W Assembly Instructions Manual

Volleyball posts, mobile, tension

Advertisement

DETAILS
SODEX INTERNATIONAL
18 rue de l'avenir – Bât. 224
14650 CARPIQUET
Tel. : +33 (0)2.31.53.78.70
Email: karine.chaigneau@sodexinternational.com
DESCRIPTION
Steel structure D90
Powder Coated
CONFORM
European norm
NF EN 1271
The time to make the assembly of this volleyball post is estimated for 1 person, at 35minutes. (without filling the
counterweights).
Equipment must be maintained regularly by the owner, it is recommended for good functionning to :
- Check fasteners every week to insure tighteness.
- Repaint on positions prone to impacts, with coloured paint specified by sodex international.
- All damaged parts must be immediately replaced with a spare part specific to this product specified by sodex inter-
national.
One full year parts and labor guarantee. Every claim regarding the condition of the delivered equipment has to be
done within the legal period,of the reception of the material.
The warranty will not apply to:
-
All degradation during the transport.
-
All degradation due to poor maintenance.
-
All degradation due to use differing from which was intended
-
Any defect claimed after the end of the legal period.
-
Any damage due to a faulty installation or assembly of the module
THIS MATERIAL HAS BEEN BUILT AND DESIGNED ACCORDING TO THE FRENCH AND EUROPEAN STANDARD EN-NF 1271
ASSEMBLY INSTRUCTIONS
VOLLEYBALL POSTS, MOBILE,
TENSION BY CAPSTAN
PRODUCT REF
Note: We recommend that the distance between two
pillars should not exceed 9.5m
ASSEMBLY TIME
MAINTENANCE
WARRANTY
S30052W
:
PAIR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S30052W and is the answer not in the manual?

Questions and answers

Summary of Contents for SODEX S30052W

  • Page 1 - Check fasteners every week to insure tighteness. - Repaint on positions prone to impacts, with coloured paint specified by sodex international. - All damaged parts must be immediately replaced with a spare part specific to this product specified by sodex inter- national.
  • Page 2: Montage

    MONTAGE NECESSARY TOOLS (NOT INCLUDED) Phillips Screwdriver Wrench 17 INCLUDED ITEMS GUIDING TO SAND (x2) STEP 1: STEP 2: Open the caps and fill sand into the counterweight Close the caps Screws M5x15...
  • Page 3: Necessary Items

    MONTAGE NECESSARY TOOLS (NOT INCLUDED) Phillips Screwdriver Wrench 17 INCLUDED ITEMS 1- ASSEMBLAGE OF BASE AND COUNTERWEIGHT WITH WHEELS (x2) Counterweight with wheels Turn-knob M10X20 Base NECESSARY ITEMS...
  • Page 4 MONTAGE 2- ASSEMBLAGE COUNTERWEIGHT ON POST (x2) Upper part of post Screws BC M10x30 + washers M10 Lower part of post Do the same with the other post NECESSARY ITEMS...
  • Page 5 MONTAGE 3- ASSEMBLAGE OF SECOND COUNTERWEIGHT (x2) NECESSARY ITEMS 4 – NET TENSION STEP 1 STEP 2 Fix the net cord to the S hook Fix the net cord to the U hook Adjust the height of net by taking the PVC turn-knob and pull it downwards.
  • Page 6 PACKING LIST MOBILE POSTS VOLLEYBALL TENSION BY CAPSTAN PRODUCT REF S30052W Index H PAIR NOMENCLATURE Package Weight Dim. Index Designation Description Quantity Packing Method N° (kg) (mm) S30052W- 2 Upper parts plastic buble+ 2 + 2 1530x200x180 2 Lower parts...
  • Page 7: Packing List

    PACKING LIST MOBILE POSTS VOLLEYBALL TENSION BY CAPSTAN PRODUCT REF S30052W Index H PAIR PRE-ASSEMBLED ACCESSORIES Package Designation Description Note N° Slip ring for tube Assemble the upper & D76/60 lower parts 2 locking bolts Ø10 + Assembled on upper...
