- Page 1 Industrial PC PPC-A55-133 PN: CS19108-RK3568-133P Content can change at anytime, check documentation website for latest information. www.chipsee.com...
-
Page 2: Table Of Contents
Contents 1. PPC-A55-133 1.1. Product Overview 1.2. Ordering Options 1.2.1. Operating System 1.2.2. Optional Features 1.3. Hardware Features 1.4. Power Input 1.5. Touch Screen 1.6. Connectivity 1.6.1. RS232+RS485+CAN+GPIO Connector 1.6.2. USB Connectors 1.6.3. LAN Connectors 1.6.4. WiFi & BT Module 1.6.5. -
Page 3: Ppc-A55-133
PPC-A55-133 PPC-A55-133 Front View Rear View Chipsee Page 3 of 18... -
Page 4: Product Overview
Product Overview ® The Cortex -A55 series PPC-A55-133 (PN: CS19108-RK3568-133P) is a high-quality IP65- compliant industrial panel PC. It features a 13.3” ten-point capacitive touch screen with a resolution of 1920 x 1080 pixels and a brightness of 400 cd/m . -
Page 5: Ordering Options
Installation on an industrial cabinet • Integration with the existing equipment The PPC-A55-133 Industrial Panel PC is based around the powerful RK3568 System on Chip (SoC), powered by the Rockchip RK3568 low-power processor which integrates a quad-core ® Cortex -A55 processor. -
Page 6: Optional Features
Software Documentation section provides a detailed instruction on how to install different OSes on your own. However, bear in mind that Chipsee can’t take the responsibility of inadequate installation procedure. If you “brick” your device, please contact Chipsee Technical Support at support@chipsee.com... -
Page 7: Power Input
Power Input The PPC-A55-133 Industrial Panel PC can be powered by a wide range of input voltages: From 12V to 36V DC. The power input connector is a 3-pin, 3.81mm terminal. The polarity and the pinout is clearly marked on the housing of the product as shown in the figure below. -
Page 8: Touch Screen
Use a high-quality Power Adapter Unit (PSU) with low EMR. You can also provide power from a battery. Make sure that the PPC-A55-133 Power Input connector (pin 3) is properly connected to the Power System Ground to provide sufficient EMI shielding and eliminate the problem entirely. -
Page 9: Connectivity
System Ground. Connectivity There are many connectivity options available on the PPC-A55-133 industrial PC. It has 1 x USB 2.0 HOST, 1 x USB 3.0 HOST, 1 x USB Type-C, 1 x network connector (RJ45) supporting up to 1 Gbps, 8 x GPIO, 2 x CAN and 4 x UART terminals (RS232/485). - Page 10 PPC-A55-133 RS232+RS485+CAN+GPIO Connector The table below offers a detailed description of every pin: RS232 / RS485 / CAN / GPIO Pin Definition: Pin Number Definition Description Pin 1 CAN0_H CAN H signal Pin 2 CAN1_H CAN H signal Pin 3...
-
Page 11: Usb Connectors
PPC-A55-133 USB Connectors RS232 / RS485 / CAN / GPIO Pin Definition: Pin 22 GND_ISO Isolated Ground Pin 23 VCC5V System 5V output, up to 1A Pin 24 VDD_ISO Isolated Power Input, supports 5V~24V Table 137 Connectivity Section Attention •... -
Page 12: Lan Connectors
Use CAT5 or better cables to achieve full data throughput over maximum distance defined by the 1000BASE-T standard (100m). WiFi & BT Module The PPC-A55-133 Industrial Panel PC is equipped with the popular Realtek RTL8821CS WiFi/BT module which supports BT/BLE 2.1/3.0/4.2, as well as 802.11ac/abgn 433Mbps 2.4/5.8 GHz Wireless LAN (WLAN). -
Page 13: 4G/Lte Module
PPC-A55-133 4G/LTE Module Figure 598: RTL8821CS WiFi/BT Module The PPC-A55-133 includes an SMA connector for an external WiFi/BT antenna, as illustrated in the figure below. WiFi+BT Antenna SMA 4G/LTE Module The PPC-A55-133 Industrial Panel PC is equipped with a mini-PCIe connector that can connect a 4G/LTE module. -
Page 14: M.2 Ssd Slot
M.2 SSD Slot There is a M.2 slot on the PPC-A55-133 that allows an optional SSD. The M.2 slot is capable of holding a PCI-E 3.0 x 2, 2280 NVME SSD. The PPC-A55-133 does not come shipped with an SSD by default, if you want a different configuration you can consult us when placing an order. -
Page 15: Audio Connectors
By plugging in the headphone cable, the internal speaker will be disabled automatically. HDMI Connector The PPC-A55-133 Industrial Panel PC is equipped with 1 x HDMI OUT connector. The HDMI connector allows connecting an additional (external) monitor. HDMI output resolution can be configured by the software. -
Page 16: Prog Button
PROG Button Mounting Procedure You can mount PPC-A55-133 with VESA mounting: 100 x 100 mm, 4 x M4 (6mm) screws. You can also mount PPC-A55-133 with panel mounting method. Attention Please make sure the display is not exposed to high pressure when mounting into an enclosure. -
Page 17: Mechanical Specifications
PPC-A55-133 Mechanical Specifications Mechanical Specifications For PPC-A55-133, the outer mechanical dimensions are 355 x 225 x 55mm (W x L x H). Chipsee Page 17 of 18... -
Page 18: Disclaimer
If you cannot find the solution you’re looking for, feel free to contact us. Please email Chipsee Technical Support at support@chipsee.com, providing all relevant information. We value your queries and suggestions and are committed to providing you with the assistance you require.
