- Page 1 Industrial PC PPC-A55-050 PN: CS12720-RK3568-050P Content can change at anytime, check documentation website for latest information. www.chipsee.com...
-
Page 2: Table Of Contents
Contents 1. PPC-A55-050 1.1. Product Overview 1.2. Ordering Options 1.2.1. Operating System 1.3. Hardware Features 1.4. Power Input 1.5. Touch Screen 1.6. Connectivity 1.6.1. RS232/RS485/CAN 1.6.2. USB Connectors 1.6.3. LAN Connectors 1.6.4. WiFi & BT Module 1.7. TF Card Slot 1.8. -
Page 3: Ppc-A55-050
PPC-A55-050 PPC-A55-050 Front View Rear View Side View 1 Chipsee Page 3 of 16... -
Page 4: Product Overview
Installation on an industrial cabinet • Integration with the existing equipment The PPC-A55-050 Industrial Panel PC is based around the powerful RK3568 System on Chip (SoC), powered by the Rockchip RK3568 low-power processor which integrates a quad-core ® Cortex -A55 processor. -
Page 5: Ordering Options
Software Documentation section provides a detailed instruction on how to install different OSes on your own. However, bear in mind that Chipsee can’t take the responsibility of inadequate installation procedure. If you “brick” your device, please contact Chipsee Technical Support at support@chipsee.com... - Page 6 1(1,2)This product has 4 x UART channels in total. The default configuration is 2 x RS232 and 2 x RS485, include 1 debug port. UART can be swapped between RS232 and RS485 modes easily, so if you need different RS232/ RS485 configuration, please get in touch with the Chipsee Technical Support at support@chipsee.com...
-
Page 7: Power Input
Power Input Power Input The PPC-A55-050 Industrial Panel PC can be powered by a wide range of input voltages: From 6V to 36V DC. The power input connector is a 3-pin, 3.81mm terminal. The polarity and the pinout is clearly marked on the housing of the product as shown on the figure below. -
Page 8: Connectivity
Use a high-quality Power Adapter Unit (PSU) with low EMR. You can also provide power from a battery. Make sure that the PPC-A55-050 Power Input connector (pin 3) is properly connected to the Power System Ground to provide sufficient EMI shielding and eliminate the problem entirely. - Page 9 PPC-A55-050 RS232/RS485/CAN Figure 566: Relation between serial pins on embedded vs. enclosed version of the PPC-A55-050 Industrial The table below offers more detailed description of every pin and its definition: RS232 / RS485 / CAN Pin Definition: Pin Number Definition...
-
Page 10: Usb Connectors
PPC-A55-050 USB Connectors RS232 / RS485 / CAN Pin Definition: Pin 4 RS232_2_RXD CPU UART2, RS232 RXD signal, Debug Port Pin 3 RS232_2_TXD CPU UART2, RS232 TXD signal Debug Port Pin 2 System Ground Pin 1 System +5V Power Output, No more than 1A Current output Table 127 Connectivity Section ... -
Page 11: Lan Connectors
WiFi/BT module which supports BT/BLE 2.1/3.0/4.2, as well as 802.11ac/abgn 433Mbps 2.4/5.8 GHz Wireless LAN (WLAN). Figure 569: RTL8821CS WiFi/BT Module The PPC-A55-050 includes an SMA connector for an external WiFi/BT antenna, as illustrated in the figure below. Chipsee Page 11 of 16... -
Page 12: Tf Card Slot
TF Card Slot WiFi+BT Antenna SMA TF Card Slot The PPC-A55-050 Industrial Panel PC features 1 x TF Card (micro SD) slot: SD, TF slots can address up to 128GB of memory. Figure 570: TF (micro SD) Card Slot Audio Connectors The PPC-A55-050 Industrial Panel PC features some audio peripherals. -
Page 13: Hdmi Connector
The PPC-A55-050 Industrial Panel PC supports 1 x HDMI-D 2.0 interfaces. Figure 572: HDMI Connector PROG Button The PPC-A55-050 Industrial Panel PC has one button on the board marked as PROG, shown in the figure below. When button is pressed before power, the PPC-A55-050 will enter MASKROM mode which can use Type-C port do upgrade system. -
Page 14: Mechanical Specifications
Guide. Mechanical Specifications PPC-A55-050 The outer mechanical dimensions of PPC-A55-050 are 138.55 x 84.70 x 27.10mm (W x L x H). Please refer to the technical drawing in the figure below for details related to the specific product measurements. Figure 575: PPC-A55-050 Technical Drawing... -
Page 15: 3D Model
PPC-A55-050 3D Model 3D Model PPC-A55-050 3D model can be viewed in the online doc in a web browser, if you are reading from the PDF version, please visit the online doc. Chipsee Page 15 of 16... -
Page 16: Disclaimer
If you cannot find the solution you’re looking for, feel free to contact us. Please email Chipsee Technical Support at support@chipsee.com, providing all relevant information. We value your queries and suggestions and are committed to providing you with the assistance you require.
