- Page 1 Mirror Dash Cam FHD 1080P Front and Rear Dual Lens ミラー型 ドライブレコーダー 2ウェイ1080Pの前後カメラドライブレコーダー User Manual Model / モデル: RVM-1088L (Left-hand drive / 左ハンドル車) RVM-1088R (Right-hand drive / 右ハンドル車)
- Page 2 PREFACE Thank you for choosing this RVM-1088 L / R Mirror Dash Camera FHD 1080P Front and Rear Dual Lens recorder. Please read this user manual carefully before using the device. 1.Do not attempt to alter or repair this device. Any alterations or unauthorized repairs will void the warranty. 2.This device can only be used as directed. Any unauthorized power distribution (such as by attaching this item directly to the battery) might damage the device, and will void the warranty. 3.This manual should be kept for installation, operation, and specification checks. Upgrades, updates, and other reasons for change may cause specifications to change, resulting in a change in type. Before Use: Removed the protective film on the Screen and the lens before using it. Any obstruction may affect and degrade the quality of viewing and recording.
-
Page 3: Table Of Contents
Directory: 1. Appearance and Ports Description-------------------------- 2. Installation Guide------------------------------------------------ 3. TF Memory card selection------------------------------------- 4. Quick operation Guide----------------------------------------- 5. On-screen Icons definitions----------------------------------- 6. Settings Menu--------------------------------------------------- 7.Key Functions Description------------------------------------- 8. Parameters------------------------------------------------------- 9. FAQ----------------------------------------------------------------... -
Page 4: Appearance And Ports Description
Appearance and Ports Description Item Description Camera Lens Front Camera Lens Camera USB Port External (rear) camera connect port GPS Port GPS antenna port (optional) TF Card Slot Insert or Eject the TF card Power USB Port Car Cigar lighter power cord connect Mount Clips To fix the silicon bandages Monitor Screen Touch screen monitor (slide touch supported) Power Button Press and hold to Power ON / OFF, short press to turn OFF / ON screen display... -
Page 5: Installation Guide
Installation Guide Mount the mirror dash cam Step1: Attached the mirror dash cam to the rearview mirror of your vehicle with the silicon bandages as shown . Adjust the mirror direction as needed, rotate the front camera direction, to even the horizontal and vertical views. Step2: Using the pry tool to pry up the edges of the decorative paneling in the vehicle so the wiring can be run underneath, run the power cable along with the front windshield, down the structural pillar, and across the passenger dash panel to the car cigar lighter, make sure that it does not interfere with your vision and will not impede your ability to drive in any way. Plug the car cig charger into the car cigar lighter socket, and plug the other end of the power cord into the power USB port on the dash cam as shown in the figure below. ... - Page 6 Rear Cam installation Step 1: Secure the rear camera with 3M adhesive Adjust the position, tear off the cover of 3M adhesive on the rear camera and install the rear camera near the license plate lamp. (The camera bracket is designed for vertical angle adjustable. Install the rear camera bracket on the rear camera and tighten it with screw driver if needed.)
- Page 7 Step 2: Remove the panel (Optional for SUV / Mini VAN which has rear door vehicles) Remove the inside panel of the trunk to expose the car's rear wiring room. Pop up your trunk and look for a solid interior panel that covers the other side of the license plate mount area. Then, insert a trim removal tool or other thin device behind the panel and pry it open. Step 3: Hide the cable Use the trim strip removal tool to pop up the tailgate trim strip, then the cable is inserted from the outside into the trunk of the car.
- Page 8 Step 4: Connect the rear camera cord to the extension cable. Step 5: Connect the Red trigger wire (Reversing trigger) Connect the Red reversing trigger to the positive pole of car revers light. (The display screen on the mirror will be force switch to rear camera during car reversing as the backup monitor system.)
- Page 9 Step 6: Wire the power cord of the rear camera to the front of the car If desired,use the trim tool to pop the windshield panel directly above the windshield.Then,pass the cable through the exposed chamber. Step 7: Start the car and turn on the dash cam. Test the mirror dash cam to make sure each functions work properly. ...
-
Page 10: Tf Memory Card Selection
About TF Memory Card CLass10 or above High-speed TF card ( or or icon on the TF card) is strongly recommended to be used for this dash cam. Low-speed TF cards might result in video data loss, video file damage, camera system slowness, and other unexpected issues. -TF card install Please insert the TF SD card before power on the mirror dash cam. When using the TF Card for the first time, format the TF card by the dash cam. Recommended to format the TF card monthly to keep the TF card as the optimum condition. -TF card eject Power Off the Mirror Dash Cam then push to eject the TF card. -
Page 11: Quick Operation Guide
Quick operation Guide: Primary Camera Slide out Slide in Slide out 360 Degree Rotatable Camera Lens Slide up / down to adjust the vertical view angle, work for both front and rear camera. 12:25 00:09 2021-04-16 Fri 0Km/h... -
Page 12: On-Screen Icons Definitions
On-screen Icons definitions: 00:09 2021-04-16 Fri 0Km/h Video Recording status: Flashing On Red --- normal recording ； Flashing On Yellow --- emergency recording; Time / Date Display: Click it to reset the time and date Setting Menu: Valid while recording Stopped Playback: Video/Picture playback Stop / Start Recording: Click to stop / start the recording Camera: Take a snapshot after click Emergency lock: Manually lock the current video file GPS Status: (External GPS module required, Sold separately) Screen display brightness: Manually adjust the brightness Driving Speed: (External GPS module required, Sold separately) GPS Position: (External GPS module required, Sold separately) G-sensor Status: Low/Mid/High/Off Loop recording time: 1min / 2mins / 3mins Sound Recording status TF memory card status External power supply connect status ... -
Page 13: Settings Menu
Settings Menu This mirror dash cam will start recording after power on. (TF card installed required) Touch the icon to stop recording, then touch icon to entry settings menu. 12:25 Video Resolution 1080P 2021-04-16 Fri Loop Rercording 1min Sound Record Key Tone Touch each item to enter setup options: Menu Page 1... - Page 14 Menu Page 2 Menu Page 3...
- Page 15 Menu Page 4 50Hz 60Hz Menu Page 5 Menu Page 6 & 7...
- Page 16 Menu Page 6 & 7...
-
Page 17: Key Functions Description
Key Functions Description: Power on / off Auto power On / Off: This mirror dash cam is powered by the car cig charger that come with the box. Plug the car cig charger into the cigarette lighter socket, then start engine ignition. The camera will be power on automatically. The mirror will be turn off after the car ignition off. Manually power On / Off: Press and hold the power key for 3s to turn On / Off the mirror. Date and Time setting Recommended to set the date and time to your local time when first time use. You can set from setting menu follows steps: 12:25 Date / Clock Settings 2021-04-16 Fri Time Display Time Format English Language 12:25 Date / Clock Settings Date / Clock Settings 2021-04-16 Fri Time Display 2021 ： ： Time Format Cancel English Language... - Page 18 Switch Monitor Screen display Touch the icon on the main screen, you can cycle switch the screen display from Front Camera / Rear Camera / 2 Split Screen Display. Recorded Video Browsing and playback Stop the recording, touch the icon on the main screen. Entry the video files browsing. 1/15 FILE210416-154800F.TS FILE210416-154900F.TS FILE210416-155000F.TS FILE210416-155100F.TS 00:00 00:28 Regular Videos Locked Videos Snapshot Front / Rear camer Video Playback Lock / Unlock current video Delete current video ...
- Page 19 Screen display brightness adjustment Slide touch the bar to adjust the display screen brightness. Mirror Display of External Camera The default screen display of rear camera is the same as the regular rear view mirror, the left and right directions are match you views, and the text is opposite. You can set the mirror function ON / OFF for different mount facing of external camera. (Mirror function ON for camera facing rear / OFF for camera facing front) 12:25 Lock File Cycle Overwrite 2021-04-16 Fri Screen Setting at Startup External camerra External Camera Priority Display Mirror Display of External Camera Mirror function ON Mirror function OFF...
- Page 20 External Camera Upside Down Flip You can set the external camera display upside down flip from setting menu. In case the camera been mounted as upside down to fit the mount conditions (Mount at the top of truck cover of Pickups). 12:25 Screen Setting at Startup 2021-04-16 Fri External Camera Priority Display Mirror Display of External Camera External Camera Upside Down Flip Regular mount Upside down mount...
-
Page 21: Parameters
Parameter TS format Max support 128GB Class 10 micro SD card ON/ OFF English/简体中文/ Japanese DC +5V/3A Voltage input -4°~+158°F / -20°~+70° c -22°~+176°F / -30°~+80° C What In the box : - RVM-1088 Mirror dash cam x 1pc; - External Camera x 1pc ； External Harness （19 ft/6M） x 1pc - Mounting bandage (2 Long/ 2 Short) x 2 sets; - Car Cig Power Harness (10ft/3M) x 1pc; - Crowbar x 1pc - User Manual x 1pc; - Mirror Clean cloth x 1pc... -
Page 22: Faq
F.A.Q For most malfunctions, reset the setting to default or power off then power on the device might help to solve the issues right away. What should I do if the device keep pop up “micro-SD Card full”? 1.Format micro‒SD Card. (Copy the files before format if needed) 2.Replace a new micro‒SD Card Why does the product continuously display “No SD Card”? 1.Check if the micro-SD card insert into the device 2. Format the micro-SD card with PC then retry on the dash cam. 3. Replace a new micro-SD card. What can i do if the product is not work properly? 1.Power off and remove the micro-SD card from the device, then restart the products 2. Press the Reset button with a pin. Why I cannot playback the recorded videos. 1. The video file is not recorded by this device. 2. The micro-SD card been damaged. Others: Do not attempt to alter or repair this device. Any alterations or unautho- rized repairs will void the warranty. Remove the protective film from the lens before using it. Remove the films on both front and rear cameras. Any obstruction may affect and degrade the quality of recording. - Page 23 (オプションオプション) micro SDカードを挿入します...
- Page 26 English/简体中文/ Japanese...
- Page 28 （GPSアンテナはオプション製品で、 店舗に連絡して買ってください。 ） （GPSアンテナはオプション製品で、 店舗に連絡して買ってください。 ）...
- Page 41 DC +5V/ 3A （GPSアンテナはオプション製品で、 店舗に連絡 して買ってください。 ）...
