2K(1600P) QHD
WIRELESS DASH CAM
User Manual
Model: DV-880WM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV-880WM and is the answer not in the manual?

Questions and answers

Summary of Contents for AX2V DV-880WM

  • Page 1 2K(1600P) QHD WIRELESS DASH CAM User Manual Model: DV-880WM...
  • Page 2: Before Use

    <<< Preface >>> Thank you for choosing this AX2V DV-880WM 2K(1600P) QHD Wi- Fi Dash Camera. Please read this user manual carefully before using the device, keep the manual properly for future use. ■The dash camera combined with functions like WDR, HDR, Loop Recording, 170°...
  • Page 3 ■ The dash camera with built-in 32G high-speed flash memory as the video storage space. The external MicroSD Card slot as the optional if you want to make the backup of the recorded files to the card. (It is recommended to use a high-speed Calss10 MicroSD card (with C10 marked) for this Dash Cam, Max 128GB supported.
  • Page 4: Function Keys

    <<< Appearance & Function keys >>> Function Keys: Multi-function Button: ⚫ Press to mark as locked of the current recording video. (The file will be saved at “Lock” folder) Press and hold for 10s to Reset ⚫ the hardware and load the default settings (included the SSID/ PSW of Wi-Fi), after then the dash camera will be restarted automatically.
  • Page 5 Red LED Constant On --- The external SD card insert, but not recording. (Can be set On / Off from the setting via APP) Red LED Slow Flashing--- Video Recording on SD card. Red LED Off --- The external SD card not insert or not been detected. <<<...
  • Page 6 <<< APPLICATION QUICK GUIDE >>> Main UI of APP...
  • Page 7 Real-Time Display Interface of APP...
  • Page 8 File Browse Interface of APP Click icon from real-time display page into files browse. Choose “Built-in Storage (eMMC)” to browse the files that saved on eMMC; Choose “External Storage (TF card)” to browse the files that saved on external Micro SD card; Folders: "Loop": Normal recorded video files with loop recording coverage.
  • Page 9 Video Playback Interface of APP Click any video file from preview folder, into the playback interface. Kindly note: The files recorded on the external SD card just with 1080P resolution. The files downloaded to the smartphone album via Wi-Fi just with 720P resolution.
  • Page 10 How to save the 2K resolution original files? The Dash Camera provide 2K 1600P QHD resolution recording. To save the card usage space, the 2K files only be saved on the internal eMMC storage; To make a copy of original 2K resolution files, please follow below instruction. 1.
  • Page 11 Dash Camera Setting Options Interface of APP Paraphrase (Default setting as bold blue marked): Sound Recording:On/Off Speaker Volume: Off/Low/Middle/High Video Resolution: 1600P/1440P/1080P Off/1Minute/3Minutes/5Minutes Loop Recording Options: Video Encoding Type:H264/H265 Anti-Flicker:50HZ/60HZ Time Watermark: On/Off (Date and time display on video) Flip:On/Off (Flip video up and down)...
  • Page 12 Wi-Fi Name: Wi-Fi SSID can be customized Wi-Fi Password: Wi-Fi passcode can be customized (Press and hold the multi-function button for 10s to rest the passcode to default "12345678") Firmware Version: Device Firmware version Format SD Card: Card format (Built-in eMMC or external SD card can be chosen).
  • Page 13 Option B: Use the ACC power hardware kit to get power from car fuse box. If there has any question about the installation, please contact with us by email: service@ax2v.com...
  • Page 14 <<< Wiring Diagram >>> Note: ACC+ power hardwire kit as an optional accessory for Parking Mode functions (both Parking Monitor Collision Detection or Time-lapse Video recording), not ASIN: B0B468JMG1 included in the package and sold separate. (Search from Amazon.com) (Red) ACC+ Connect to the ACC DC +12V Power (Black) GND Connect to the vehicle metal body...
  • Page 15: Specification

    <<< Specification >>> Image Processor: H.264/H.265; 2K 1600P@30fps Image Sensor: 5M Pixels COMS sensor Lens: 170°Wide-Angle High-Definition Camera, F1.8 Video Recorder: Normal recording, time-lapse recording and Collision locked Video resolution: 2K QHD 1600P@30fps; 1080P@30fps, 720P@30fps Video format: .TS (H.264 or H.265) Photo resolution: 2M Pixels Micro SD card capacity: Class10, up to 128GB card supported.
  • Page 16: What In The Box

    Collision during normal recording or Parking Monitor or Time-lapse video recording modes) "Parking Mode":Time-lapse recorded video files What In the box: - DV-880WM dash cam x 1pc; - Mounting Pad with adhesive x 1pc; - Car Cig Charger × 1pc (Cable Length (11.5FT)) - User Manual x 1pc;...
  • Page 17 <<< Common troubleshooting >>> 1. Camera can’t Power On: Use the original car cig charger that come with box, check the car cig charger LED indicator is on; Check the Power USB connector been plugged into the dash cam USB port. Or if use the power hardware kit, check the B+ and ACC wiring are correct, and make sure that the car is in ignition state.
  • Page 18 Before you return the product, please contact with us first, there might has a better and prompt solution to solve the issue for you. Make every user satisfied is our final goal. For Products information: amz-us@ax2v.com For Tech Support or After service: service@ax2v.com Notice: Do not operate the phone or dash cam while driving.
