Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale
Operating and Service Manual
Part No. MAN463iR-PH_201118
Page 1 of 20
S
by S Instruments, Inc.
In-Floor Platform Scale
Operating and Service
Manual
,
SInstruments, Inc.
600 Young Street, Tonawanda, NY 14150
Tel: 716-693-5977
Fax: 716-693-5854 URL:
www.srscales.com
Copyright 2020 SInstruments, Inc.
email:
sri@srinstruments.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR Scales SR463iR-PH Series and is the answer not in the manual?

Questions and answers

Related Manuals for SR Instruments SR Scales SR463iR-PH Series

Summary of Contents for SR Instruments SR Scales SR463iR-PH Series

  • Page 1 Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 1 of 20 by S Instruments, Inc. In-Floor Platform Scale Operating and Service Manual SInstruments, Inc. 600 Young Street, Tonawanda, NY 14150 Tel: 716-693-5977 Fax: 716-693-5854 URL: www.srscales.com Copyright 2020 SInstruments, Inc.

  • Page 2: Table Of Contents

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 2 of 20 TABLE OF CONTENTS TABLE OF FIGURES ........................2 PACKING CHECKLIST- SR463IR-PH (TWO SEPARATE SHIPMENTS) ......3 PACKING CHECKLIST- SR463IR-PH (SINGLE SHIPMENT) ..........3 PACKING CHECKLIST- SR463IR-3PH (TWO SEPARATE SHIPMENTS) ......4 PACKING CHECKLIST- SR463IR-3PH (SINGLE SHIPMENT) ..........4 PACKING CHECKLIST- SR463IR-4PH (TWO SEPARATE SHIPMENTS) ......5 PACKING CHECKLIST- SR463IR-4PH (SINGLE SHIPMENT) ..........5...

  • Page 3: Packing Checklist- Sr463Ir-Ph (Two Separate Shipments)

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 3 of 20 PACKING CHECKLIST- SR463iR-PH (Two Separate Shipments) In-Floor Platform Scale  DESCRIPTION QUANTITY 1st Shipment WALL BOX ASSEMBLY 1 ea PIT FRAME ASSEMBLY 1 ea CONDUIT 1 ea...

  • Page 4: Packing Checklist- Sr463Ir-3Ph (Two Separate Shipments)

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 4 of 20 PACKING CHECKLIST- SR463iR-3PH (Two Separate Shipments) In-Floor Platform Scale  DESCRIPTION QUANTITY 1st Shipment WALL BOX ASSEMBLY 1 ea PIT FRAME ASSEMBLY 1 ea CONDUIT 1 ea...

  • Page 5: Packing Checklist- Sr463Ir-4Ph (Two Separate Shipments)

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 5 of 20 PACKING CHECKLIST- SR463iR-4PH (Two Separate Shipments) In-Floor Platform Scale  DESCRIPTION QUANTITY 1st Shipment WALL BOX ASSEMBLY 1 ea PIT FRAME ASSEMBLY 1 ea CONDUIT 1 ea...

  • Page 6: Assembly

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 6 of 20 ASSEMBLY 14 3/4" 3 3/4" STEP 1: Unpack the scale system and check parts against the PACKING CHECKLIST. If there are any missing or damaged parts, please call the WALL BOX Service Hotline at: 1-800-654-6360.

  • Page 7: Figure 4: Concrete Fill And Installation Tabs

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 7 of 20 ASSEMBLY cont’d STEP 6: (Figure 4) Back fill around the perimeter of the Pit Frame Assembly with 3000PSI concrete. Trowel the concrete level with the scale frame and existing floor.

  • Page 8: Figure 7: Side Clearance Adjustment Bolts

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 8 of 20 ASSEMBLY cont’d Note: This scale is designed so that the Platform Assembly is level with the Pit Frame Assembly. When tiling or carpeting the platform deck, be sure to compensate for the thickness of the material.

  • Page 9: Figure 8: Front Panel Assembly

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 9 of 20 ASSEMBLY cont’d STEP 15: Install Front Panel Assembly (Figure 8) to the previously mounted Wall Box Assembly. Use supplied star washers and screws. Ensure that the screws are securely tightened. Figure 8: Front Panel Assembly STEP 16: Restore power to the display.

  • Page 10: Replacement Parts And Accessories

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 10 of 20 REPLACEMENT PARTS AND ACCESSORIES Part # Description SE4961-1 CABLE ASSEMBLY, 12 FT SE4961-2 CABLE ASSEMBLY, 15 FT MAN463IR-PH MANUAL HANDRAIL, SS, 34” X 34” MF9526 HANDRAIL, SS, 48”...

  • Page 11: Cleaning And Disinfecting

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 11 of 20 CLEANING and DISINFECTING CLEANING To clean the display / user interface and other scale contact areas:  Use a soft cloth dampened with water and mild detergent to clean scale surfaces. ...

  • Page 12: Storage And Transportation

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 12 of 20 STORAGE and TRANSPORTATION This is a built-in scale system. To maintain proper operation of this instrumentation, storage and transport conditions should not vary outside the following conditions: Relative Humidity 0% to 85%, Ambient Temperature 14°F to 122°...

  • Page 13: Button Functions

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 13 of 20 BUTTON FUNCTIONS Figure 10: Button Display WEIGH Press and hold to zero scale. Button is used to zero the system before placing the patient on the scale.

  • Page 14: Basic System Operation

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 14 of 20 BUTTON FUNCTIONS con’t ENTER Press to save change in digits for calibration, for unit’s set-up, for time and date set-up and saving completed calibration data. UP / SELECT Press UP to adjust height up from the default for BMI calculation, to increase the scale’s “on time”, or to select a digit when setting time and date.

  • Page 15: Theory Of Operation

    Page 15 of 20 THEORY OF OPERATION SR Instruments patient weighing systems are digital scales. Strain-gauge force cells convert the force of an applied weight into an analog signal. This signal is amplified by an operational amplifier and converted to a digital signal by an analog to digital converter. The digital signal is transferred to a micro-controller where it is filtered, converted to appropriate units and displayed on a liquid crystal display.

  • Page 16: Calibration

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 16 of 20 CALIBRATION NOTE: Ensure that nothing is in contact with the scale system during this procedure. Remove hands from the system when noting the displayed calibration results. APPLIED HIGH LIMIT...
  • Page 17 Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 17 of 20 CALIBRATION cont’d SETTING CALIBRATION NOTE: Ensure that nothing is in contact with the scale system during this procedure. Remove hands from the system when noting the displayed calibration results. STEP 1: Access the Calibration Switch by breaking the Calibration Seal on the underside of the display extrusion.

  • Page 18: Troubleshooting

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 18 of 20 TROUBLESHOOTING SYMPTOM REASON/CORRECTIVE ACTION Printer paper door is not completely closed. Close Display screen toggles “DOOR OPEN” door. There is no paper in the printer and the printer Display screen toggles “DOOR AND paper door is not completely closed.

  • Page 19: Warranty

    SR Instruments, Inc.’s part, and it neither assumes nor authorizes any other person to assume for SR Instruments, Inc. any other liabilities in connection with the sale of said articles. In no event shall SR Instruments, Inc.

  • Page 20: Sinstruments, Inc

    Model SR463iR-PH, SR463iR-3PH Series In-Floor Platform Scale Operating and Service Manual Part No. MAN463iR-PH_201118 Page 20 of 20 S Instruments, Inc. Precision & Technology in ® Perfect Balance SInstruments, Inc. 600 Young Street, Tonawanda, NY 14150 Tel: 716-693-5977 Fax: 716-693-5854 URL: www.srscales.com Copyright 2020 SInstruments, Inc.
