NI Switches Getting Started Guide
For PXI and SCXI Switch Modules
Contents
™
This document explains how to install, configure, and set up National
Instruments PXI and SCXI switch modules. This document covers the
NI-DAQ 7.x software relative to NI switch modules. For a more detailed
explanation of NI-DAQ 7.x, refer to the DAQ Quick Start Guide for
NI-DAQ 7.x available on the NI-DAQ 7.x Device Documentation CD.
Conventions ............................................................................................ 2
Safety and Compliance ........................................................................... 2
Related Documentation........................................................................... 3
1. Unpack the Module and Accessories .................................................. 3
2. Verify the Components ....................................................................... 4
3. Install the Software ............................................................................. 5
4. Install the PXI Switch Modules .......................................................... 7
5. Install the SCXI Switch Modules........................................................ 8
6. Configure the PXI Switch Modules .................................................... 18
NI-DAQmx ...................................................................................... 18
PXI System ...................................................................................... 19
7. Configure the SCXI Switch Modules ................................................. 20
NI-DAQmx ...................................................................................... 20
Traditional NI-DAQ ........................................................................ 23
8. Install the Terminal Blocks and Connect Signals ............................... 28
Derating Modules That Share the HVAB........................................ 29
9. Program the Switch Modules.............................................................. 30
NI-SWITCH Soft Front Panel (SFP) ............................................... 30
NI-SWITCH API ............................................................................. 30
NI-DAQmx API............................................................................... 31
Technical Support Resources.................................................................. 31
