Barcelona
450 CFM/11.5 SONES @ 0.10" WG. HVI CERTIFIED 120 Volts, 2.8 amps, 60 hz.
• Dimensions
Overall bottom projection - 10
Height - 10
1 / 4
"
Width: 19
7 / 16
"
• Hood Body
All metal cold rolled with stainless steel fascia.
• Motor
3 speed, permanently split capacitor motor. Rated 120 volts,
60 hz., 2.8 amps.
• Lighting
Two - Hi spot ES 16, 50 watt maximum halogen lights.
• Ducting
Vertical ducting: 6" round duct adapter complete with polymetric
back draft damper.
• Blower Wheel
Dual inlet, electronically balanced polymetric centrifugal blower
wheel, 5
27 / 32
" width 59 paddles.
• Cut Out Opening Size
Width - 18"
Depth - 10"
• Filters
Two - Model SVGF03, modular aluminum, dishwasher safe
grease filters
(included)
• Available Finishes
Stainless Steel.
Air Flow - CFM
460
PROJECT
LOCATION
CONTRACTOR
FAN
MODEL
CFM
NUMBER NUMBER
C
US
Specifications subject to change without notice.
®
Collection, Seville
15 / 16
"
.
Static Pressure (inches of w.g.)
0
0.1
0.125
0.25
450
447
434
IN
RPM
WATTS
W.G.
™
PERFORMANCE
0.375
0.5
0.75
422
411
389
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS
SONES
QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
SEV24SSH
RANGE HOODS
Power Unit Insert
SEV24SS
10
1 / 4
"
10
15 / 16
"
19
HVI Sones
Fan Speed
@ .1 SP
RPM
1.0
366
11.5
2650
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
10"
7 / 16
"
Power
Watts
440
Updated 1-07
