- Page 1 SIT WIFI GUIDE WIFI KIT PART #946-799 www.regency-fire.com SIT WiFi Guide Instructions FPI Fireplace Products International Ltd. 6988 Venture St., Delta, B.C. Canada, V4G 1H4 PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE 09.25.23 920-729...
-
Page 2: Table Of Contents
SIT WiFi Guide Instructions TABLE OF CONTENTS WIFI COMPATIBLE HARDWARE ...... WIFI COMPATIBLE UNITS ......PROFLAME CONNECT PLUS APPLICATION ..INTRODUCTION ..........SETTING UP YOUR FIREPLACE ....... ADDITIONAL MENUS AND ADVANCED SETTINGS OPERATION ..........USING THE APP IN CONJUNCTION WITH THE REMOTE RE-PAIRING THE FIREPLACE WITH THE APP... -
Page 3: Wifi Compatible Hardware
SIT WiFi Guide Instructions WIFI COMPATIBLE HARDWARE • IFC: 911-311 • Remote: 911-341 (white wall mount), 911-355 (black handheld) • 946-799 WiFi Kit Dongle + Cable: 911-323 Velcro to secure WIFI dongle (If required) • THE DONGLE ONLY CONNECTS TO 2.4 GHz WIFI NETWORKS. -
Page 4: Introduction
SIT WiFi Guide Instructions INTRODUCTION Fireplaces can be remotely controlled by Android/iOS Proflame Connect applications as long as the fireplace has a IFC control board that is WIFI capable. This WIFI guide will note which fireplaces are approved for use with this WIFI kit. The connectivity to the Proflame IFC is provided by Proflame WiFi Dongle. The dongle is connected to the IFC through X0A serial port and it connects to an existing WiFi network. The setup of Proflame WiFi Dongle is done creating a standalone WiFi network with a dedicated access point. The app allows to remotely control the fireplace using only the local connection: all data are exchanged in the local WiFi and no packets are exchanged with external servers. Only with virtual assistants Alexa and Google Assistant, the dongle has a connection outside the local WiFi, connecting to the Amazon Web Services (AWS). -
Page 5: Setting Up Your Fireplace
SIT WiFi Guide Instructions SETTING UP YOUR FIREPLACE 1. Find the Proflame Connect Plus App in the 3. Privacy Policy screen will pop up. Please 5. Tap ''Join''. App Store or Google Play Store. Download read through the document carefully and and open. tap “I HAVE READ AND UNDERSTOOD” to proceed. - Page 6 SIT WiFi Guide Instructions 7. Enter the name and password of your 9. Tap “Continue” to proceed once fireplace 11. Turn on the fireplace by pressing the home’s WIFI Network. is successfully added. If you have multiple power symbol on the top right corner of fireplaces, follow steps 4-9 again to set the block and then pressing “Confirm” on...
- Page 7 SIT WiFi Guide Instructions 12. Press the block to change fireplace levels 13. To turn the fireplace off, press the power and modes. symbol at the top right of the block and then press “Confirm”. The app will remember the last mode the fireplace was set to when turning back on. SIT WiFi Guide...
-
Page 8: Additional Menus And Advanced Settings
SIT WiFi Guide Instructions ADDITIONAL MENUS AND ADVANCED SETTINGS 1. Tap the hamburger symbol at the top right of the screen to access additional menus, options and features. 2. To configure features in the app, tap Advanced settings. Here you can choose which features are shown in the home screen. Note: The app cannot detect what features your fireplace has. You will have to toggle the unused features off manually if you do not want to see them on the home screen. Splitflow: Units with secondary burners available can have the secondary burners controlled by the Splitflow valve. Enabling Splitflow will allow the app to control the secondary burner. -
Page 9: Operation
SIT WiFi Guide Instructions OPERATION The fireplace can be operated using the app or the remote included with the unit. The remote needs to be synced to the unit in order to use thermostat (T-stat) and Smart thermostat (Smart) modes from the app. This is because the remote measures the ambient temperature in the room and transmits it to the app. Manual Mode: • To increase the flame height, drag the slider next to the flame symbol towards the right. • To decrease the flame height, drag the slider next to the flame symbol towards the left. • To increase the fan speed, drag the slider next to the fan symbol towards the right. - Page 10 SIT WiFi Guide Instructions Thermostat Mode (T-stat): Smart Thermostat Mode (Smart): • Set the temperature at which the fireplace will turn on at by • Set the temperature at which the fireplace will turn on at by dragging the slider next to the thermometer symbol left or right.
-
Page 11: Using The App In Conjunction With The Remote
SIT WiFi Guide Instructions USING THE APP IN CONJUNCTION WITH THE REMOTE • Please ensure your remote contains working batteries. The remote must still be supplied with power to measure your room temperature and transmit that measurement to the app. -
Page 12: Re-Pairing The Fireplace With The App
SIT WiFi Guide Instructions RE-PAIRING THE FIREPLACE WITH THE APP To re-pair your unit to your home network: 1. Locate the dongle in your fireplace. Note: Depending on where the WIFI dongle is placed, a qualified service technician may be required to re-pair the fireplace to your home. 2. Press and hold the yellow button on the dongle for 5-10 seconds. 3. The dongle should now be in Access Point (AP) mode as shown by a solid Red and Greed LED on the dongle. - Page 13 SIT WiFi Guide Instructions notes SIT WiFi Guide...
- Page 14 SIT WiFi Guide Instructions Printed in Canada © Copyright 2023, FPI Fireplace Products International Ltd. All rights reserved.
