Owner's &
Installation
f i r e - p a r t s . c o m
E33 GAS INSERT
ZERO CLEARANCE KIT
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Refer to this manual. For assistance
or additional information consult an
authorized installer, service agency
or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
fl ammable vapours and liquids in
the vicinity of this or any other ap-
pliance.
FPI Fireplace Products International Ltd.
6988 Venture St., Delta, BC
Canada, V4G 1H4
918-432a
KIT # 340-900
FOR YOUR SAFETY
What to do if you smell
gas:
Do not try to light any
appliance
Do not touch any electri-
cal switch: do not use
any phone in your build-
ing.
Immediately call your
gas supplier from a
neighbour's phone. Fol-
low the gas supplier's
instructions.
If you cannot reach your
gas supplier, call the fi re
department.
09/06/05
Advertisement
Table of Contents
Related Manuals for Regency Fireplace Products 340-900
Summary of Contents for Regency Fireplace Products 340-900
- Page 1 E33 GAS INSERT ZERO CLEARANCE KIT KIT # 340-900 Owner's & Installation f i r e - p a r t s . c o m PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment,...
-
Page 2: Table Of Contents
TABLE OF CONTENTS GAS INSERT ZERO CLEARANCE KIT CONTENTS PAGE General Information ................3 E33 Insert Zero Clearance Kit Specifications........3 Clearances to Combustibles..............4 Combustible Mantle Clearances ............5 f i r e - p a r t s . c o m Framing.....................6 Zero Clearance Kit Assembly..........6 Assemble the Cabinet............6... -
Page 3: General Information
INSTALLATION GENERAL INFORMATION This kit consists of factory built parts that require minimal assembly to form the Zero Clearance enclosure for the E33 Gas Insert. The enclosure can then be fi xed into a framed combustible construction, and a standard Simpson Dura-Vent Direct Vent GS System installed on the assembly for the required venting. -
Page 4: Clearances To Combustibles
INSTALLATION CLEARANCES TO COMBUSTIBLES The clearances for the Zero Clearance Kit are 0" to combustibles (back, side and fl oor) but when planning your installation review the clearances required for the Insert (see below) after it is installed in the Zero Clearance Kit. Warning: Combustible facing materials must not extend inside the 1/2"... -
Page 5: Combustible Mantle Clearances
INSTALLATION COMBUSTIBLE MANTEL CLEARANCES f i r e - p a r t s . c o m Because of the extreme heat this fi replace emits, the mantel clearances are critical. Combustible mantel clearances from top of unit are shown in the above diagrams. Note: A non-combustible mantel may be installed at a lower height if the framing is made of metal studs covered with a non-combustible board. -
Page 6: Framing
INSTALLATION FRAMING The cabinet face panels have a 1/2" (13mm) lip to defi ne the zones for combustible and non-combustible facing materials: outside the lip, any material up to 1/2" (13mm) may be used; inside the lip, only non-combus- tible materials may be used (with a maximum thickness of 1-1/2" (38mm)). The kit may be installed directly on and/or against standard combustible building materials. - Page 7 INSTALLATION Set the assembled Side and Base sections upright. Slide Slide the Upper Back Section down the inside of the Side the Lower Back (the section with 4 holes) down the inside fl anges. of Side fl anges (make sure the 4 holes are closest to the fl...
- Page 8 INSTALLATION Secure with 6 screws on the back. Leave the top screw holes until the top is attached. Assemble the 2 top Standoffs. The Top Standoffs are shipped fl at and must be folded at the bend lines into the correct shape.
- Page 9 INSTALLATION Assemble the Face Panels (left, right, and top), all 3 Face Assemble the fl ue adaptor box. Slide the fl ex vent pipe panels are installed loosely, and then attached to the over the small vent opening on the base of the adaptor cabinet body.
-
Page 10: Attach The Cabinet To The Framing
INSTALLATION Install the Insert Attach the Cabinet to the Framing Slide the unit into the cabinet on top of the bottom stand- Slide the cabinet into the frame constructed previously and offs. secure with nails or sheet rock screws, installing a fastener into at least every other hole. -
Page 11: Venting Introduction
INSTALLATION VENTING INTRODUCTION The E33 Insert uses the "balanced fl ue" technology Co. Axial system. The inner liner vents products of combustion to the outside while the outer liner draws outside combustion air into the combustion chamber thereby eliminating the need to use heated room air for combustion and losing warm room air up the chimney. - Page 12 NOTES _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ f i r e - p a r t s . c o m _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ E33 Gas Insert Zero Clearance Kit...
- Page 13 NOTES _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ f i r e - p a r t s . c o m _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ E33 Gas Insert Zero Clearance Kit...
- Page 14 NOTES _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ f i r e - p a r t s . c o m _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ E33 Gas Insert Zero Clearance Kit...
- Page 15 NOTES _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ f i r e - p a r t s . c o m _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ _________________________________________________ E33 Gas Insert Zero Clearance Kit...
- Page 16 f i r e - p a r t s . c o m © Copyright 2005, FPI Fireplace Products International Ltd. All rights reserved. Printed in Canada...
