POWER VENT SYSTEM KIT
Inline Power Vent Kit # 666-945
End of Line Power Vent Kit # 946-535
Power Vent System
Installation Instruction
Approved for use with the following
City 40 Series, City 50 Series, City 60 Series, City 72 Series
WARNING:
Improper installation, adjustment, alteration, service
or maintenance can cause injury or property damage.
Refer to this manual. For assistance or additional
information consult an authorized installer, service
agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapours
and liquids in the vicinity of this or any other appliance.
Installation and service must be performed by an
authorized installer, service agency or the gas supplier.
Tested by: Intertek
C#4001172
920-544a
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
www.regency-fire.com
Gas Fireplace
FOR YOUR SAFETY
What to do if you smell gas:
* Do not try to light any appliance
* Do not touch any electrical switch: do not
use any phone in your building.
* Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
* If you cannot reach your gas supplier,
call the fire department.
Manufactured by:
FPI Fireplace Products International Ltd.
6988 Venture St.,
Delta, B.C. Canada, V4G 1H4
Models only:
06.30.23

Advertisement

Table of Contents
loading

Summary of Contents for Regency Fireplace Products 666-945

  • Page 1 POWER VENT SYSTEM KIT Inline Power Vent Kit # 666-945 End of Line Power Vent Kit # 946-535 www.regency-fire.com Power Vent System Installation Instruction Gas Fireplace Approved for use with the following Models only: City 40 Series, City 50 Series, City 60 Series, City 72 Series...
  • Page 2: Table Of Contents

    Power Vent System Kit TABLE OF CONTENTS LISTINGS AND CODE APPROVALS ........3 GENERAL INFORMATION ............3 IMPORTANT INSTALLATION NOTES ........3 INTRODUCTION ..............4 VENT RESTRICTOR POSITION ..........4 HORIZONTAL TERMINATIONS - INLINE HORIZONTAL VENT CHART ................5 HORIZONTAL TERMINATIONS - END OF LINE HORIZONTAL VENT CHART ..............6 HORIZONTAL TERMINATIONS - INLINE POWER VENT 4'' X 6-5/8'' FLEX VENT ............7...
  • Page 3: Listings And Code Approvals

    Power Vent System Kit LISTINGS AND CODE GENERAL 3) This kit is tested and safe when installed APPROVALS INFORMATION in accordance with this installation manual. Please read all instructions before starting installation and follow all instructions care- This Kit has been approved for use with the This installation manual covers Regency In-line fully during installation.
  • Page 4 Power Vent System Kit 4"X 6-5/8" (102 MM X 168 MM) RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not All Rigid Pipe components are available directly from FPI. IMPORTANT : When using the inline Power Vent system & rigid pipe: Vertical Terminations : Only Simpson Duravent rigid pipe is approved for use.
  • Page 5 Power Vent System Kit Description Selkirk American Metal Security ICC Excel Olympia Simpson Metal-Fab™ Ventis DV* Direct Temp™ Secure- Vent® Direct Direct Vent Pro ® Products® Sure Seal Amerivent Direct Offset Support 46DVA-ES 4DT-OS SV4SU TM-SOS Wall Thimble-Black 46DVA-WT 4DT-WT 4DWT 4DWT SV4RSM...
  • Page 6: Introduction

    • End of line flush horizontal power vent system (Part #946-535): flush power vent fan acts as the termination cap and sits flush to the outside wall. Allowed for horizontal termination only. • Inline power vent system (Part #666-945): power vent fan terminal is incorporated into the vent run - allows for both horizontal and vertical termination.
  • Page 7: Horizontal Terminations - Inline Horizontal Vent Chart

    Inline Horizontal Vent Chart HORIZONTAL TERMINATIONS - INLINE HORIZONTAL VENT CHART INLINE POWER VENT KIT # 666-945 RIGID PIPE: MUST USE RIGID PIPE ADAPTOR 770-994 AND 946-606 PIPE REDUCER TO 4" X 6 5/8" (102 mm x 168 mm). FLEX VENT: MUST USE REDUCER 946-758 TO 4" X 6 5/8" (102 mm x 168 mm).
  • Page 8: Horizontal Terminations - End Of Line Horizontal Vent Chart

    Power Vent System Kit HORIZONTAL TERMINATIONS - END OF LINE HORIZONTAL VENT CHART END OF LINE POWER VENT KIT # 946-535 • Rigid pipe is approved for up to 72 feet (21.95 m). • Flex pipe is approved for up to 40 feet (12.19 m) using 2 X 946-756-- 20 foot (6.10 m) flex kits. The gas power vent system is designed to allow the installation of a gas appliance when typical vent configurations (Non-Power Vent Direct Vent Systems With no Fan Assist) are not possible.
  • Page 9: Horizontal Terminations - Inline Power Vent

    • • Maximum total vent length (based on overall Maximum total vent length (based on overall Power Vent Kit (Part 666-945) length of combined chimney components) length of combined chimney components) 2 Max. 946-756...
  • Page 10: Horizontal Terminations - Inline Power Vent 4" X 6-5/8" Rigid Pipe

    Minimum 4' (1.2 m) from the unit prior to terminating. NOTE: The 40 series has a 4" inner x 6 5/8" outer (102 mm x 168 mm) collar already and does not require to be reduced in size. Power Vent Kit (Part 666-945) Power Vent Kit (Part 666-945)
  • Page 11: Horizontal Terminations - End Of Line Power Vent

    Power Vent System Kit HORIZONTAL TERMINATIONS - END OF LINE POWER VENT RIGID PIPE 4" X 6-5/8" (102 MM X 168 MM) The minimum components required for a basic horizontal termination are: Power Vent Kit Rigid Pipe Adaptor Vent Reducer (Required for 50, 60 & 72 series only) Length of pipe to suit wall thickness and total vent run (see Table 1) Wall thickness is measured from the back standoffs to the inside mounting...
  • Page 12: Gas Power Vent Installation - End Of Line Power Vent Flex Pipe

    Power Vent System Kit GAS POWER VENT INSTALLATION - END OF LINE POWER VENT FLEX PIPE The Power Vent System is a Direct Vent Terminal designed to allow installation of gas appliances where typical vent configurations cannot be achieved. These installation instructions must be used in conjunction with the appliance and appropriate Power Vent components installation instructions. 120 Volt power supply is required to operate this system.
  • Page 13: Horizontal Termination 4'' X 6-5/8'' Venting

    Power Vent System Kit HORIZONTAL 5. Assemble the desired combination of pipe 7. Ensure that the pipe clearances to and elbows to the appliance adaptor and combustible materials are maintained TERMINATION twist lock for a solid connection. (Diagram 3). Install the termination cap. 4"...
  • Page 14: Venting Arrangement For Vertical Terminations Inline Power Vent

    Power Vent System Kit CV72EPV/CB72EPV/CB40EPV/CC40EPV/CV40EPV/CV60EPV Inline Power Vent Vertical or Hortizontal Installation Instructions VENTING ARRANGEMENT FOR VERTICAL TERMINATIONS Venting Arrangement for Vertical Terminations-Inline Power Vent INLINE POWER VENT Vertical venting with straight vertical venting and/or with a max. of six (6) 90 Elbows (1 - 90 2 - 45 RIGID PIPE: MUST USE RIGID PIPE ADAPTOR 770-994 AND 946-606 PIPE REDUCER TO 4"...
  • Page 15: Vertical Inline Power Vent Terminations Rigid Pipe

    Power Vent System Kit CV72EPV/CB72EPVCB40EPV/CC40EPV/CV40EPV/CV60EPV Inline Power Vent Vertical or Hortizontal Installation Instructions Vertical Inline Power Vent Terminations VERTICAL INLINE POWER VENT TERMINATIONS - RIGID PIPE Rigid Pipe The minimum components required when using inline power vent are: High Wind Cap The minimum components required when using inline power vent are: High Wind Cap...
  • Page 16: Vertical Terminations - Flex Pipe

    • No negative runs. Power Vent Kit (Part #666-945) Ceiling Firestop 666-945 Power vent kit sold separately. Inner Pipe Adaptor (shown inside flex pipe) 946-219/P Adaptor pipe included w/power vent kit. Inline Power Vent Terminal 946-755 20' (6.1 m) Vertical Flex Kit (sold separately) includes: 20 ft. (6.10 m) flex pipe with 10 spacers (inner &...
  • Page 17: Inline Power Vent Dimensions

    Power Vent System Kit INLINE POWER VENT DIMENSIONS 24-3/16" (614 MM) 17-1/16" (433 MM) 3-1/4" (62 MM) 16-1/16" (406 MM) 10" (254 MM) 4-1/2" (114 MM) 14-1/4" (362 MM) 11" (279 MM) 12-1/4" (312 MM) 4-3/8" (111 MM) 5-7/8" (149 MM) 14-1/4"...
  • Page 18: Gas Power Vent Installation - Framing Inline Power Vent Terminations

    Power Vent System Kit CV72EPV/CB72EPV/CB40EPV/CC40EPV/CV40EPV/CV60EPV Inline Power Vent Vertical or Hortizontal Installation Instructions GAS POWER VENT INSTALLATION - FRAMING INLINE POWER VENT TERMINATIONS Gas Power Vent Installation-Framing Inline Power Vent Terminations • The inline power vent can be mounted directly onto a wall, ceiling, stud or truss. Additional supports can be built to support the power vent if needed.
  • Page 19: Power Vent Terminal Installation Inline Power Vent Terminations

    Power Vent System Kit CV72EPV/CB72EPVCB40EPV/CC40EPV/CV40EPV/CV60EPV Inline Power Vent Vertical or Hortizontal Installation Instructions POWER VENT TERMINAL INSTALLATION INLINE POWER VENT TERMINATIONS Power Vent Terminal Installation • • Pressure switch (Part # 911-112) must always be oriented vertically inside the inline power vent. Pressure switch (Part # 911-112) must always be oriented vertically inside the inline power vent.
  • Page 20: Gas Power Vent Installation Clearance Requirements Inline Power Vent Terminations

    CV72EPV/CB72EPV/CB40EPV/CC40EPV/CV40EPV/CV60EPV CV72EPV/CB72EPV/CB40EPV/CC40EPV/CV40EPV/CV60EPV Power Vent System Kit Inline Power Vent Vertical or Hortizontal Installation Instructions Inline Power Vent Vertical or Hortizontal Installation Instructions GAS POWER VENT INSTALLATION CLEARANCE REQUIREMENTS Gas Power Vent Installation Clearance Requirements Gas Power Vent Installation Clearance Requirements Inline Power Vent Terminations INLINE POWER VENT TERMINATIONS Inline Power Vent Terminations...
  • Page 21: Horizontal Termination - End Of Line Power Vent

    Power Vent System Kit HORIZONTAL TERMINATION - END OF LINE POWER VENT 4" X 6-5/8" (102 MM X 168 MM) RIGID VENTING Minimum Vent Clearances to 5. Assemble the desired combination of pipe and elbows to the appliance adaptor and twist lock Combustibles for a solid connection.
  • Page 22: Horizontal Termination - End Of Line Power Vent

    Power Vent System Kit HORIZONTAL TERMINATION - END OF LINE POWER VENT 4" X 6-5/8" (102 MM X 168 MM) FLEX VENTING Minimum Vent Clearances Horizontal sections must be supported at to Combustibles intervals not exceeding 3 feet (0.9 meter). Flame picture and performance will be affected * Clearances noted below must be maintained, by sags in the liner.
  • Page 23: Vertical Inline Power Vent Terminations Rigid Pipe

    Power Vent System Kit VERTICAL INLINE POWER VENT TERMINATIONS - RIGID PIPE 4) Assemble the desired pipes and elbows. A top clearance of 3" (76 mm) and side Ensure all pipes and elbow connections are bottom clearance of 2" (51 mm) must be twist-locked and sealed.
  • Page 24: Vertical Inline Power Vent Terminations Flex Pipe (Part # 946-755)

    Termination Cap Power Vent System Kit Storm Collar Flashing VERTICAL INLINE POWER VENT TERMINATIONS FLEX PIPE (PART # 946-755) Firestop spacer to prevent Roof support Must choose 1 of the following: debris from falling into the Part # Description ceiling firestop 46DVA-F12 Flashing 7/12 - 12/12 46DVA-F6...
  • Page 25 Power Vent System Kit VERTICAL INLINE POWER VENT TERMINATIONS - FLEX PIPE 19. Slide the finished length up towards the flashing. Ensure the length Termination Cap of pipe is a minimum of 2 feet (610 mm) measured from the top of the roof.
  • Page 26: Vertical Flue Extension Kit - Horizontal Power Vent Kit (Part # 946-756)

    Power Vent System Kit VERTICAL FLUE EXTENSION KIT - HORIZONTAL POWER VENT KIT VERTICAL FLUE EXTENSION KIT (APPROVED MODELS) (PART # 946-756) HORIZONTAL POWER VENT KIT (CV72EPV, CB72EPV, CB40EPV, CV40EPV, & CC40EPV ONLY) (PART # 946-756) Used in conjunction with the 946-755 Vertical Flex kit for vertical installations or for horizontal installations when using the power vent option only where a 4"...
  • Page 27: Top Vent Reducer Installation 5'' X 8'' To 4'' X 6-5/8

    Power Vent System Kit TOP VENT REDUCER INSTALLATION (FLEX VENT) 5" X 8" (127 MM X 203 MM) TO 4" X 6-5/8" (102 MM X 168 MM) B36XTE/B36XTCE (PART # 946-758) TOP VENT REDUCER INSTALLATION—FROM 5" X 8" TO 4' X 6-5/8" Used in applications where flex venting is used.
  • Page 28: Gas Power Vent Installation - Wiring The Inline Power Vent To The Unit

    Power Vent System Kit CV72EPV/CB72EPVCB40EPV/CC40EPV/CV40EPV/CV60EPV Inline Power Vent Vertical or Hortizontal Installation Instructions GAS POWER VENT INSTALLATION - WIRING THE INLINE POWER VENT TO THE UNIT Gas Power Vent Installation--Wiring the Inline Power Vent to the Unit Connect ground wire to ground lug located on the side wall of the •...
  • Page 29: Gas Power Vent Installation - Wiring End Of Line Power Vent

    Power Vent System Kit GAS POWER VENT INSTALLATION - WIRING END OF LINE POWER VENT 6. Determine the building finishing material thickness. • Electrical connections should only be carried out by a licensed electrician. 7. Depending on the building material thickness, install the frame onto the power vent mount using four screws.
  • Page 30 Power Vent System Kit GAS POWER VENT INSTALLATION - WIRING END OF LINE POWER VENT 10. Remove front faceplate from power vent unit by removing four 15. Connect ground wire to ground lug located at back of the power screws as shown below. vent box.
  • Page 31: Gas Power Vent Installation - Wiring The Power Vent To The Unit

    Power Vent System Kit GAS POWER VENT INSTALLATION WIRING THE POWER VENT TO THE UNIT CST60E - Gas Power Vent Installation-Wiring-End of Line Power Vent BOTH INLINE/END OF LINE POWER VENT SYSTEMS 1. Remove exterior side panels and bottom panels (if installed) to gain 4.
  • Page 32 Power Vent System Kit CST60E - Gas Power Vent Installation-Wiring-End of Line Power Vent 12. Locate the power vent switch cover. 7. Join the Pressure switch and BX cable wires by splicing 1" off wires- -join red to red and blue to blue (Diagram 7). Diagram 7 8.
  • Page 33: Wiring Diagram - Power Vent Application

    Power Vent System Kit WIRING DIAGRAM - POWER VENT APPLICATION While the burner does not require a 120 V A.C. power supply, it is highly recommended as a primary power source. Batteries (4 AA) should be used as a secondary power source only. •...
  • Page 34 Power Vent System Kit Printed in Canada © Copyright 2023, FPI Fireplace Products International Ltd. All rights reserved.
