CentronicPLUS
SC811A PLUS
Assembly and Operating Instructions
en
Radio sun/wind sensor, bidirectional
Important information for:
• Fitters / • Electricians / • Users
Please forward accordingly!
These instructions must be kept safe for future reference.
4036 630 291 0 23/01/2023
Becker-Antriebe GmbH
Friedrich-Ebert-Straße 2-4
35764 Sinn/Germany
www.becker-antriebe.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Becker CentronicPLUS SC811A PLUS
Summary of Contents for Becker CentronicPLUS SC811A PLUS
- Page 1 Assembly and Operating Instructions Radio sun/wind sensor, bidirectional Important information for: • Fitters / • Electricians / • Users Please forward accordingly! These instructions must be kept safe for future reference. 4036 630 291 0 23/01/2023 Becker-Antriebe GmbH Friedrich-Ebert-Straße 2-4 35764 Sinn/Germany www.becker-antriebe.com...
-
Page 2: Table Of Contents
Table of contents General ........................ 3 Licensing information for open source software............ 3 Warranty ...................... 4 Safety instructions .................... 4 Intended use ...................... 5 Explanation of displays and buttons ................ 6 Explanation of functions .................. 7 Program sensor .................... 7 Establish programming mode ................ -
Page 3: General
Written request for the licence texts: Becker-Antriebe will, on request, provide the licence texts for the licensed software be- ing used at cost price, either on a USB stick or a similar data carrier. Please send an email to the following email address for more information: licenses@becker‑antriebe.com... -
Page 4: Warranty
Warranty Structural modifications and incorrect installation which are not in accordance with these and our other instructions can result in serious injuries, e.g., crushing of limbs. Therefore, structural modifications may only be carried out with our prior approval and strictly in accordance with our instructions, particularly the information contained in these Assembly and Operating Instructions. -
Page 5: Intended Use
Intended use The sensor described in these instructions must only be used for CentronicPlus-com- patible radio drives and radio control units. • Please note that radio-controlled systems may not be used in areas with a high risk of interference (e.g. hospitals, airports). •... -
Page 6: Explanation Of Displays And Buttons
Explanation of displays and buttons Sun sensor Wind sensor Function/ control button Indicator lamp Programming button Indicator lamp on Lights up green for The sensor has started up and is still start-up 1–6 seconds booting up. Indicator lamp dur- Briefly lights up yel- The sensor is sending sensor data to its ing operation receiver. -
Page 7: Explanation Of Functions
Explanation of functions The sensor continually transmits the current measured sensor values. The reaction to the thresholds set in the receiver being exceeded or not met depends on the receiver being used and on the particular settings on this receiver. Indicator lamp The indicator lamp provides visual feedback such as radio transmissions. - Page 8 Press the programming button for 3 seconds when it is ready to pro- gram. The sensor performs a search and the indicator lamp continuously changes colour. The sensor then switches to receiver selection and se- lects the receiver with the best connection quality. ▻...
- Page 9 With an SWCxxxPLUS transmitter With brand new products, devices from another installa- tion or products that have been restored to factory set- tings, programming mode must be established before- hand (see Establishing programming mode). Bring the transmitter as close as possible to the sensor to be pro- grammed.
-
Page 10: Sensor Assignment With The Hand-Held Transmitter
Sensor assignment with the hand-held transmitter Bring the transmitter as close as possible to the required sensor. Press the programming button on the transmitter for 3 seconds. The transmitter performs a search and the LED ring continuously changes colour. The transmitter then switches to receiver selection and selects the sensor/receiver with the best connection quality. - Page 11 Briefly press the programming button on the transmitter to change to the setting mode. ▻ The receiver with the best connection quality to the transmitter confirms. ▻ The LED ring lights up white in the lower area and shows the current assignment status of the selected sensor in the upper area.
-
Page 12: Restoring The Factory Settings Of The Sensor
Restoring the factory settings of the sensor Press the programming button and the function/control button for 10 seconds. ▻ The indicator lamp flashes red. Once the data has been deleted, the indicator lamp will flash green twice, and the device will reboot. ►... -
Page 13: Wiring
Wiring Caution Secure the connecting cable against slipping out with the strain relief. Cleaning Only clean the device with a suitable cloth. Do not use aggressive cleaning agents that may damage the surface. Disposal The crossed-out bin symbol on the product indicates that the device is subject to man- datory disposal separate from household waste. -
Page 14: Technical Data
Technical data Rated voltage 230-240 V AC / 50-60 Hz Degree of protection IP 44 Permissible ambient temperature -25 to +55 °C Maximum emitted transmission output ≤ 3 mW Radio frequency 915.3 MHz The maximum transmitter range on and in the building is up to 15 m, and up to 150 m in the open.
