Centronic SensorControl
SC811A
Assembly and Operating Instructions
en
Radio sun/wind sensor
Important information for:
• Fitters / • Electricians / • Users
Please forward accordingly!
These instructions must be kept safe for future reference.
4033 630 177 0 03/11/2022
Becker-Antriebe GmbH
Friedrich-Ebert-Straße 2-4
35764 Sinn/Germany
www.becker-antriebe.com
Advertisement
Table of Contents
Related Manuals for Becker Centronic SensorControl SC811A
Summary of Contents for Becker Centronic SensorControl SC811A
- Page 1 Assembly and Operating Instructions Radio sun/wind sensor Important information for: • Fitters / • Electricians / • Users Please forward accordingly! These instructions must be kept safe for future reference. 4033 630 177 0 03/11/2022 Becker-Antriebe GmbH Friedrich-Ebert-Straße 2-4 35764 Sinn/Germany www.becker-antriebe.com...
-
Page 2: Table Of Contents
Table of contents General .................... 3 Warranty .................... 3 Safety instructions ................... 4 Intended use ................... 4 Explanation of displays and buttons ............ 5 Explanation of functions ................ 6 Programming the transmitter .............. 7 Assembly .................... 8 Wiring ..................... 9 Cleaning.................... -
Page 3: General
General You can control one or more sun protection systems with the sensor. The thresholds for sun protection and wind monitoring can be set with the Centronic SunWindControl transmitters. This device is exceptionally easy to use. Explanation of pictograms CAUTION indicates a hazardous situation CAUTION which, if not avoided, could result in in- jury. -
Page 4: Safety Instructions
Safety instructions General information • Please keep the instruction manual safe! • Only use unmodified original parts from the control unit manufacturer. • Keep children away from control units. • Observe all pertinent country-specific regulations. Caution • Risk of injury due to electric shock. •... -
Page 5: Explanation Of Displays And Buttons
• Ensure that the control unit is not installed or operated close to metal surfaces or magnetic fields. • Radio-controlled systems transmitting on the same fre- quency may cause reception interference. • Note that the range of the radio signal is limited by legis- lation as well as by design. -
Page 6: Explanation Of Functions
Explanation of functions Transmission pilot light A radio signal is indicated by the transmission pilot light lighting up. Control button The button commands are executed in the following order RETRACT - STOP - EXTEND - STOP, etc. Wind sensor If the wind threshold is exceeded, the system retracts as standard. Exceptions are described in the relevant instructions for the receiver. -
Page 7: Programming The Transmitter
Programming the transmitter Before programming the sensor, a master transmitter suit- able for adjusting sensors must be programmed into the ra- dio receiver and the limit positions must be programmed. Up to three sensors can be programmed into the radio re- ceiver. -
Page 8: Assembly
Assembly In order to ensure the correct functioning of the sensor, the sensor surfaces must not be covered. • Check that the transmitter and receiver are functioning per- fectly prior to installation in the desired location. • Fix the sensor to the wall using the three enclosed screws. -
Page 9: Wiring
Wiring Rain sensor (optional) Contact closed: It is raining (awning retracts) Contact open: It is not raining Caution Secure the connecting cable against slipping out with the strain relief. Cleaning Only clean the device with a suitable cloth. Do not use aggressive cleaning agents that may damage the surface. -
Page 10: Disposal
Disposal The crossed-out bin symbol on the product indicates that the device is subject to mandatory disposal separate from household waste. This product must be handed over to a collection point for electrical and electronic equipment at the end of its service life. The packaging material must be disposed of properly. -
Page 11: What To Do If
What to do if...? Problem Remedy The drive is not functioning. Reduce the distance from the re- ceiver. The transmission pilot light on the sensor lights up. Program the sensor in the receiver. Automatic drive commands are not Set the slide switch of the hand-held/ executed.
