Becker SC211A-II Manual

Radio awning movement sensor
Hide thumbs

Advertisement

Quick Links

Download this manual
Centronic SensorControl
SC211A-II
Assembly and Operating Instructions
en
Radio awning movement sensor
Important information for:
• Fitters / • Electricians / • Users
Please forward accordingly!
These instructions must be kept safe for future reference.
4033 630 276 0     02/02/2022
Becker-Antriebe GmbH
Friedrich-Ebert-Straße 2-4
35764 Sinn/Germany
www.becker-antriebe.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the SC211A-II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Becker SC211A-II

Summary of Contents for Becker SC211A-II

  • Page 1 Centronic SensorControl SC211A-II Assembly and Operating Instructions Radio awning movement sensor Important information for: • Fitters / • Electricians / • Users Please forward accordingly! These instructions must be kept safe for future reference. 4033 630 276 0     02/02/2022    Becker-Antriebe GmbH Friedrich-Ebert-Straße 2-4...

  • Page 2: Table Of Contents

    Table of contents General .................... 3 Warranty .................... 4 Safety instructions ...................  4 Intended use ...................  5 Explanation of displays and buttons ............ 6 Explanation of functions ................ 6 Commissioning.................. 8 Changing batteries.................. 12 Technical data .................. 13 What to do if...?.................. 14 2 - en...

  • Page 3: General

    The threshold for monitoring wind and vibration can be set using any Centronic hand-held or wall transmitter with a wind threshold-adjustment fea- ture. The SC211A-II detects two kinds of awning motion and evaluates them separ- ately: • Wind • Increase or decrease in the awning’s angle of inclination (adjustable) This device is exceptionally easy to use.

  • Page 4: Warranty

    Warranty Structural modifications and incorrect installation which are not in accordance with these and our other instructions can result in serious injuries, e.g., crush- ing of limbs. Therefore, structural modifications may only be carried out with our prior approval and strictly in accordance with our instructions, particularly the information contained in these Assembly and Operating Instructions.

  • Page 5: Intended Use

    The SC211A-II is intended solely for the operation of an open, half-closed (semi-cassette), or fully closed (cassette) articulated-arm awning. For safety reasons, the SC211A-II may only be operated with one sun protec- tion drive with integrated radio receiver. The operation of two or more articu- lated-arm awnings with one SC211A-II is not permitted.

  • Page 6: Explanation Of Displays And Buttons

    Transmission pilot light A green transmission pilot light indicates that there is a radio signal when a button is pressed. A red transmission pilot light indicates that the SC211A-II has not yet been programmed. Control button The button commands are executed in the following order RETRACT/EXTEND - STOP - EXTEND/RETRACT - STOP, etc.
  • Page 7 Wind Angle of inclination / Release angle (optional) The SC211A-II detects a gradual increase or decrease in the awning’s angle of inclination relative to the initial angle of inclination e.g., due to rain (formation of water pools). If the awning reaches the release angle, a retract command is sent to the receiver.

  • Page 8: Commissioning

    Commissioning Caution It is essential to follow the steps in the correct order. 1. Open the housing and carefully remove the PCB 2. Insert batteries correctly. 3. Setting the release angle (optional) Caution The release angle may only be set by a specialist in accord- ance with the specific features of the articulated-arm awn- ing.
  • Page 9 4. Assembly of the housing Attention Take care not to damage the controller when extending and retracting the articulated-arm awning. Use the fasteners supplied to mount the controller in the T-slot at the end of the front section. 5. Completely push in the PCB 9 - en...

  • Page 10: Programming The Transmitter

    3. Press the programming button of the SC211A-II until the receiver confirms. 4. Now press the programming button of the SC211A-II that is to be pro- grammed again until the receiver confirms.
  • Page 11 1. Extend the articulated-arm awning to the point where you can reach the SC211A-II. 2. Turn off the power to the system. 3. Open the SC211A-II and carefully remove the PCB. 4. Turn the rotary switch to position 0. 5. Slide the PCB back into the SC211A-II.

  • Page 12: Changing Batteries

    Changing batteries Caution Extend the articulated-arm awning to the best position for changing the batteries and then turn off the power to the system. After you have changed the batteries, turn the power back on. 1. Undo the housing screw and carefully pull back the cover as far as it will 2.

  • Page 13: Technical Data

    Technical data Rated voltage 3 V DC Battery type FR03 (AAA) Lithium Degree of protection IP 44 Angle of inclination range 0° to 90° Permissible ambient temperature -25 to +55 °C Maximum emitted transmission output ≤ 3 mW Radio frequency 915.3 MHz Type of mounting on the front section The maximum radio range on and in the building is up to 10 m, and up to 100...

  • Page 14: What To Do If

    Adjust the wind pite calm conditions. threshold on the master transmitter. Awning does not react to wind. Program the SC211A-II. Adjust the wind threshold on the master transmitter. An increase or decrease in the awn- The rotary switch for the release ing’s angle of inclination is not detec-...
