Cyclops Lighting LEDE 320S Manual

300w led spot moving head

Advertisement

Quick Links

LEDE 320S
300W LED Spot Moving Head

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LEDE 320S and is the answer not in the manual?

Questions and answers

Summary of Contents for Cyclops Lighting LEDE 320S

  • Page 1 LEDE 320S 300W LED Spot Moving Head...
  • Page 2: Table Of Contents

    Table of contents Caution! ������������������������������������������������������������������������������������������������������������������ 3 Introduction ������������������������������������������������������������������������������������������������������������ 3 Safety instructions ������������������������������������������������������������������������������������������������� 3 Fxiture overview ����������������������������������������������������������������������������������������������������� 3 Installation �������������������������������������������������������������������������������������������������������������� 4 Read ‘Safety information’ before installing the fixture ���������������������������������������������������������������������������������4 Fastening the fixture to a flat surface �����������������������������������������������������������������������������������������������������������4 Mounting the fixture on a truss ���������������������������������������������������������������������������������������������������������������������4 Securing with a safety cable �������������������������������������������������������������������������������������������������������������������������5 DMX-512 connection/connection between fixtures ������������������������������������������������������������������������������������5 Operation ����������������������������������������������������������������������������������������������������������������...
  • Page 3: Caution

    Caution! • Be careful with your operations� With a dangerous voltage you can suffer a dangerous electric shock when touching the wires! • Avoid looking directly into the light source! • Indoor use only, keep this device away from rain and moisture! •...
  • Page 4: Installation

    3-pin DMX input socket 3-pin DMX output socket Powercon in Fuse On/Off switch 13 14 15 The head should be locked for transportation- the tilt lock latch (3) and the pan lock latch (4) have to be in the locked positions�...
  • Page 5: Securing With A Safety Cable

    securely� 5� Secure the fixture with a safety cable as directed below� Securing with a safety cable Secure the fixture with a safety cable (or other secondary attachment) that is approved for the weight of the fixture so that the safety cable will hold the fixture if a primary attachment fails� Loop the safety cable through the eyebolt in the back of the fixture and around a secure anchoring point�...
  • Page 6: Operation

    Operation The LEDE320S can operate in three different modes� In each mode you can run the fixture as a stand alone fixture or in a master/slave confiugration� This next section will detail the dif-ferences in the operating modes� Addressing All fixtures should be given a DMX starting address when using a DMX signal, so that the correct fixture responds to the correct control signals�...
  • Page 7: Master-Slave Operation

    2� Select the Fixture Set tab� 3� Press Up or Down button and select Run Mode and select Host� 4� The fixture will run internal programs� Master-Slave Operation This function will allow you to link up to 16 units together and operate without a controller� In a Master- Slave set up one unit will act as the controlling unit and the others will react to the controlling units programs�...
  • Page 8 Language, Chinese Language Language, English Close Display Display Flip Display Reverse 180° Open Show Display blacklight, always on Display Mode Display blacklight, 60 seconds Cancel XY Reset Pan Tilt reset Cancel Moto Reset Motos reset Reset Cancel All reset Reset all Cancel Factory Factory default...
  • Page 9: Dmx Protocol

    Advanced settings/calibration(Only qualified technicians should perform Password this function� Inqure your local dealer for password�) Tilt Iris Color Rot Gobo Factory Gobo Rot Fix Gobo Input correct password for calibration Frost Effect Prism Prism Rot Zoom Focus DMX Protocol MODE/CHANNEL DMX value Function STD 24...
  • Page 10 Marco Function 000-129 No function 130-149 Pan/Tilt reset 150-159 No function 160-179 Effect reset 180-189 No function 190-209 All reset 210-255 No function Strobe 000-003 Closed 004-103 Strobe slow to fast 104-107 Open 108-207 Pulse strobe fast to slow 208-212 Open 213-240 Pulse strobe slow to fast...
  • Page 11 Gobo Wheel 1(Fixed gobo) 000-009 Open/hole 010-019 Gobo 1 020-029 Gobo 2 030-039 Gobo 3 040-049 Gobo 4 050-059 Gobo 5 060-069 Gobo 6 070-079 Gobo 7 080-089 Gobo 8 090-112 Backwards rotation from fast to slow 113-120 Stop 121-143 Forwards rotation from slow to fast Shaking gobos from slow to fast 144-157...
  • Page 12 Gobo Wheel 2(Rotating gobo wheel) 000-009 Open/hole 010-019 Gobo 1 020-029 Gobo 2 030-039 Gobo 3 040-049 Gobo 4 050-059 Gobo 5 060-069 Gobo 6 700-079 Gobo 7 080-0129 Backwards rotation from fast to slow 130-135 Stop 136-185 Forwards rotation from slow to fast Shaking gobos from slow to fast 186-195 Gobo 1...
  • Page 13: Fixture Cleaning

    Iris 0-134 Linear 135-164 Fast open, Slow close 165-194 Slow open, Fast close 195-224 Normal Rain Effect 225-255 Random Rain Effect Frost 0-127 Open/hole 128-255 Frost Focus 0-255 Continuous adjustment from far to near Focus fine 0-255 Fine focusing 0-255 Zoom Zoom fine 0-255...
  • Page 14: Specifications

    Specifications Model LEDE 320S Power supply: AC100 - 240V, 50/60Hz Light source: 300W white LED Color temperature: 6600K Color Rendition: CRI 70 Pan: 540° Tilt: 270° Zoom: 13° - 44° motorized Focus: Motrized focus Prism: 3 facet circular rotating indexable prism...
