Lexmark 520-sheet Printing Manual

Printing guide

Get the most from the printer by properly loading the trays and setting the types and sizes for media.

Loading the standard or optional 520-sheet tray

The printer has one standard 520-sheet tray (Tray 1), and may have one or more optional 520-sheet trays. All 520-sheet trays

support the same paper sizes and types.

CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each paper drawer or tray separately. Keep

all other drawers or trays closed until needed.

Pull the tray out.

Notice the size indicators at the bottom of the tray. Use these indicators to help position the length and width guides.

Printing guide

Page 1 of 3

Table of Contents

Do you have a question about the 520-sheet and is the answer not in the manual?

Page 1 Get the most from the printer by properly loading the trays and setting the types and sizes for media. Loading the standard or optional 520-sheet tray The printer has one standard 520-sheet tray (Tray 1), and may have one or more optional 520-sheet trays. All 520-sheet trays support the same paper sizes and types.
Page 2 Printing guide Page 2 of 3 Squeeze and then slide the width guide to the correct position for the paper size loaded. Squeeze and then slide the length guide to the correct position for the paper size loaded. Note: The length guide has a locking device. To unlock, slide the button on top of the length guide down. To lock, slide the button up when a length has been selected.
Page 3 Printing guide Page 3 of 3 Notes: • Place print side facedown for duplex printing. • Place pre-punched paper with the holes toward the front of the tray. • Place letterheads with the header on the left side of the tray. •...
