- Page 1 INSTALLATION, OPERATING & MAINTENANCE INSTRUCTIONS M1-5475 SINGLE 20” DECO SHOWER DOOR HANDLE/TOWEL RAIL...
-
Page 2: Table Of Contents
Contents Dimensions Instal ation Procedure Parts List Fault Finder Safety Tips, Care and Maintenance Guarantee... -
Page 3: Dimensions
Dimensions in Inches (& Millimetres) 18 13/16" (478mm) Ø1/2" (Ø12mm) Ø7/8" (Ø21.5mm) Ø1 1/8" (Ø28mm) Ø1 1/8" (Ø28mm) 20" (508mm) Whilst every effort is made to ensure accuracy, design and dimensions are subject to change without notice as part of the company’s product development process. -
Page 4: Instal Ation Procedure
Installation Procedure Steps 1-2 Lefroy Brooks always recommends that plumbing products be installed by a licensed professional. Shut off main water supply before installation. 20 5/8" 1/16"~1 1/8" (524±0.5mm) (1mm~28mm) Before installation, make sure the dimensions for the shower door are as indicated above. - Page 5 Installation Procedure Steps 3-4 Lefroy Brooks always recommends that plumbing products be installed by a licensed professional. Shut off main water supply before installation. Adjust the direction of the Stud Bolts and tighten the nuts. Attach the door handle on to the nuts and fix the handle tightly with set screws.
- Page 6 Installation Procedure Steps 5-7 Lefroy Brooks always recommends that plumbing products be installed by a licensed professional. Shut off main water supply before installation. In case you are buying two sets of this product and want to convert them into a double shower door handle, please take the following steps: Firstly, screw the stud bolts into the nuts.
-
Page 7: Parts List
Parts List Exploded view Rail (254139) Screw (008678) Adaptor (077527) Set Screw (075038) Adapter (067531) Adaptor (255346) Bracket (244177) Washer (013826) Allen key (031000) Rail Holder (240113) Nut (054870) Stud Bolt (017094) Washer (013266) Adaptor (067293) -
Page 8: Fault Finder
Fault Finder Fault Cause Rectification Loose handle. The fixing screw is not tightened Check and tighten properly the properly. fixing screw. -
Page 9: Safety Tips, Care And Maintenance
Safety Tips, Care and Maintenance Safety Tips If you are soldering during faucet installation,remove cartridges, seats, gaskets and washers prior to applying flame, otherwise you will void the warranty. Cover drain openings to avoid losing small parts. When cutting or soldering pipe, use safety glasses to protect your eyes. Important Points Prior to beginning installation. -
Page 10: Guarantee
Not Covered by this Guarantee Damage or defects arising from incorrect installation, improper use or lack of maintenance. Installed product damaged in transit Consequential loss, damage or product removal and installation costs. Lefroy Brooks is not responsible for any on site labour charges. - Page 11 TELEPHONE: 718-302-5292. FAX: 718-302-4177 The use of trademarks, product design and artwork is subject to licence or agreement with Christo A. Lefroy Brooks. The design registrations, trademark registrations and copyrights are protected by law and the use or reproduction outside the terms of an agreement is prohibited.
