200 CFM/6.5 Sones @ 0.10"WG. Vertical, 120 Volts, 1.5 amps, 60hz
• Dimensions
Overall bottom projection - 18
Overall top projection -12"
Height - 6". Available widths: 30" & 36"
• Hood Body
23 gauge cold rolled steel, auto welded, coated with a baked
enamel finish.
• Motor
Variable speed, single coil, thermally protected, permanently
lubricated. Rated 120 volts, 60 hz., 1.5 amps. Complete with
200˚C lead wires.
• Lighting
Single 60 watt cook light capacity
night light setting.
• Ducting Options
Horizontal ducting: 3
1 / 4
Vertical ducting: 3
1 / 4
"x10"
Vertical ducting: 7" round
Ductless: removable front vent
• Fan Blade
One piece polymeric, electronically balanced blade. 6
diameter with 5 paddles.
• Electrical connection
Hood top -
7 / 8
" electrical knockout.
Hood back -
7 / 8
" electrical knockout.
Air Flow - CFM
Vertical Ducting
233
Horizontal Ducting
233
PROJECT
LOCATION
CONTRACTOR
FAN
MODEL
CFM
NUMBER NUMBER
C
US
Specifications subject to change without notice.
200 CFM/6.5 Sones @ 0.10" WG. Horizontal,
3 / 8
"
complete with
(bulb not included)
"x10"
(duct adapter and damper included).
(duct adapter and damper included).
(duct adapter and damper not included).
(charcoal filter not included)
Static Pressure (inches of w.g.)
0
0.05
0.1
0.15
218
200
181
218
200
181
IN
RPM
WATTS
W.G.
.
• Filters
UL rated, class 2 filter.
5 / 8
"
Grease Filter: RF35 - 8
Charcoal Filter: RF34
Combo Grease/Charcoal: RF55
• Available Finishes
White, Biscuit, Almond, Black & Stainless Steel.
PERFORMANCE
0.2
0.25
0.3
158
132
111
158
132
111
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS
SONES
QTY
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
DS SERIES
RANGE HOODS
DS SERIES
1 / 4
2
3
1 / 4
duct connection
7 / 8
"
6
11 / 16
5
"
29
7 / 8
", 35
7 / 8
"
7 / 8
"x10
3 / 8
"
.
(included)
.
(not included)
.
(not included)
HVI Sones
Fan Speed
@ .1 SP
RPM
0.35
100
6.5
100
6.5
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: (905) 456-2033
Fax: (905) 456-1015
" x 10" knock-out for
" x 10" rectangular
7" round
knock-out
6
3 / 8
"
12"
Power
Watts
2847
91
2847
91
Updated 7-06
