BLAUBERG Ventilatoren HRV H 200 Operation Manual

Heat recovery ventilator

Advertisement

Quick Links

HEAT RECOVERY VENTILATOR
HRV H 200
ERV H 200
HRV H 300
ERV H 300
EN
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HRV H 200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BLAUBERG Ventilatoren HRV H 200

  • Page 1 HEAT RECOVERY VENTILATOR HRV H 200 ERV H 200 HRV H 300 ERV H 300 OPERATION MANUAL...
  • Page 2: Table Of Contents

    HRV /ERV H 200(300) www.blaubergventilatoren.de CONTENTS Application ....................2 Delivery set ....................3 Unit designation key ................3 Basic unit dimensions ................3 Technical data ....................3 Safety requirements ................4 Structure and operating logic ...............4 Mounting and setting-up ...............5 Condensate drainage ................5 Unit connection to power mains ............6 Unit control ....................7 Servicing and maintenance ..............8 Troubleshooting ..................8...
  • Page 3: Delivery Set

    HRV /ERV H 200(300) www.blaubergventilatoren.de DELIVERY SET Unit HRV/ERV H 200(300) - 1 pc; User’s manual - 1 pc; Drain hose - 1 pc; Oil filter - 1 pc; Packing box - 1 pc. UNIT DESIGNATION KEY HRV/ERV H 200(300) Air capacity [CFM] Unit type: HRV - Heat Recovery Ventilator...
  • Page 4: Safety Requirements

    HRV /ERV H 200(300) www.blaubergventilatoren.de SAFETY REQUIREMENTS While operating and mounting unit fulfill the requirements of the present operation manual as well as general requirements of all applicable codes and standards valid in USA and Canada. Ground the unit! Before connecting the unit to power mains make sure that the unit is free of any visible damages or any other foreign objects inside the casing that can damage the impeller blades.
  • Page 5: Mounting And Setting-Up

    CONDENSATE DRAINAGE The unit is equipped with a condensate drain hose for condensate drainage (fig. 4), applicable only for HRV H 200(300). Connect the drain hose (1), U-trap (3) and drain system (5) with metal, plastic or rubber pipes (2 and 4). The pipes must be sloped down at least by 3°. Before starting operation of the unit fill the system with water and check that U-trap is always filled with water.
  • Page 6: Unit Connection To Power Mains

    HRV /ERV H 200(300) www.blaubergventilatoren.de min 3° fig. 4. Condensate drainage CONNECTION TO POWER MAINS CUT POWER SUPPLY OFF BEFORE ANY OPERATIONS WITH THE UNIT. THE UNIT SHALL BE CONNECTED TO POWER MAINS BY A DULY QUALIFIED ELECTRICIAN ONLY. RATED VALUES OF THE ELECTRICAL PARAMETERS ARE SHOWN ON THE RATING PLATE.
  • Page 7: Unit Control

    HRV /ERV H 200(300) www.blaubergventilatoren.de UNIT CONTROL The unit is controlled by a three-position speed switch that enables low-speed modes «Low» as well as «Med» and «Stand by» mode which enables total air quality control (fig. 6). Up to five external control devices may be connected to the terminals 2-11 (fig. 7) that turn the unit to high-speed ventilation in case of activation of any of the control devices.
  • Page 8: Servicing And Maintenance

    Clean the fans with a soft brush or dry cloth. No water and abrasive detergent, sharp objects or solvents are allowed for cleaning to prevent the impeller damage. Condensate drainage system maintenance (once per year), applicable only for HRV H 200(300). The drain hose can get clogged with the extracted particles. Clean the drain hose is required. Check proper functioning of the drain system by pouring some water into the drain pan at the unit bottom.
  • Page 9: Storage And Transportation Rules

    HRV /ERV H 200(300) www.blaubergventilatoren.de STORAGE AND TRANSPORTATION RULES • Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range from +5 ˚С (+41 ˚F) to +40 ˚С (+104 ˚F) and relative humidity up to 70 %. •...
  • Page 10 HRV /ERV H 200(300) www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Single-room reversible energy recovery ventilator Model HRV/ERV H 200(300) Serial Number Manufacture Date We hereby declare that the product complies with the protection requirements of Electromagnetic Council Directive 2014/30/EU, Low Voltage Directive 2014/35/EU and CE-marking Directive 93/68/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility.
  • Page 11 www.blaubergventilatoren.de HRV/ERV_H_200(300)_EN-01...
