BLAUBERG Ventilatoren Freshbox 100 ERV WiFi User Manual

Heat recovery air handling unit
Hide thumbs Also See for Freshbox 100 ERV WiFi:
Table of Contents

Advertisement

Quick Links

Download this manual
Heat recovery air Handling unit
Freshbox 100 WiFi
EN
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Freshbox 100 ERV WiFi and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BLAUBERG Ventilatoren Freshbox 100 ERV WiFi

Summary of Contents for BLAUBERG Ventilatoren Freshbox 100 ERV WiFi

  • Page 1 Heat recovery air Handling unit Freshbox 100 WiFi USER’S MANUAL...

  • Page 2: Table Of Contents

    Freshbox 100 WiFi www.blaubergventilatoren.de CONTENTS Safety requirements ..................................3 Purpose ........................................ 5 Delivery set ......................................5 Designation key ....................................5 Technical data ....................................6 Design and operating principle ............................7 Installation and set-up................................8 Connection to power mains ..............................12 Control .........................................

  • Page 3: Safety Requirements

    Freshbox 100 WiFi www.blaubergventilatoren.de SAFETY REQUIREMENTS • Please read the user’s manual carefully prior to installing and operating the unit. • All user’s manual requirements as well as the provisions of all the applicable local and national construction, electrical, and technical norms and standards must be observed when installing and operating the unit.
  • Page 4 Freshbox 100 WiFi www.blaubergventilatoren.de • Do not touch the unit controls • Do not wash the unit with with wet hands. water. • Do not carry out the • Protect the electric parts of the installation and maintenance unit against ingress of water. operations with wet hands.

  • Page 5: Purpose

    Freshbox 100 WiFi www.blaubergventilatoren.de PURPOSE The unit is designed to ensure continuous mechanical air exchange in houses, offices, hotels, cafes, conference halls, and other utility and public spaces as well as to recover the heat energy contained in the air extracted from the premises to warm up the filtered stream of intake air.

  • Page 6: Technical Data

    THE EXTRACT AIR TEMPERATURE SHOULD BE NO HIGHER THAN +40 °C AND RELATIVE HUMIDITY SHOULD NOT EXCEED 70 % OVER THE ENTIRE TEMPERATURE RANGE. " " " Parameter Freshbox 100 WiFi Freshbox 100 ERV WiFi Speed Maximum air capacity [m /h] [CFM] 30 (18) 44 (26) 60 (35)

  • Page 7: Design And Operating Principle

    Freshbox 100 WiFi www.blaubergventilatoren.de DESIGN AND OPERATING PRINCIPLE Control panel Extract grille Extract spigot for a bathroom (optional)* Supply fan Humidity sensor or CO sensor (available separately) Limit switch MERV 8 extract filter MERV 14 supply filter Counter-flow heat exchanger Lock Control unit MERV 8 supply filter...

  • Page 8: Installation And Set-Up

    Freshbox 100 WiFi www.blaubergventilatoren.de INSTALLATION AND SET-UP READ THE USER'S MANUAL BEFORE INSTALLING THE UNIT. WHILE INSTALLING THE UNIT ENSURE CONVENIENT ACCESS FOR SUBSEQUENT MAINTENANCE AND REPAIR. Minimum distances from the unit to the surfaces min 300 mm min 300 mm min 11 / "...
  • Page 9 Freshbox 100 WiFi www.blaubergventilatoren.de Hole spacing template ADDITIONAL HOLE! DRILL UPON CUSTOMER’S REQUEST ONLY! ADDITIONAL HOLE! DRILL UPON CUSTOMER’S REQUEST ONLY! Ø 120 mm ( 4 / ") hole for Ø 100 mm (3 / ") air ductFill the Ø 120 mm (4 / ") hole for Ø 100 mm (3 / ") air duct gaps between the wall and the air ducts with a mounting foam Fill the gaps between the wall and the air ducts with a...
  • Page 10 Freshbox 100 WiFi www.blaubergventilatoren.de 2.1. Remove the mounting template and drill two through holes Ø 120 mm (Ø 4 3/4”) for round air ducts. When mounting the unit with an additional extract spigot prepare a hole in the wall for a connecting bend and for laying of a rectangular air duct.
  • Page 11 Freshbox 100 WiFi www.blaubergventilatoren.de 5. To install an additional extract spigot, remove the plug on the rear part of the unit. Undo the screws, remove the plug and fix a spigot on its place using screws. 6. Insert the connecting cables external humidity sensor or CO sensor into the control unit through the corresponding holes on the back wall of the unit.

  • Page 12: Connection To Power Mains

    Freshbox 100 WiFi www.blaubergventilatoren.de CONNECTION TO POWER MAINS POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL.

  • Page 13: Control

    Freshbox 100 WiFi www.blaubergventilatoren.de CONTROL The unit is controlled by means of a control panel on the unit casing, a remote control or via mobile application. Control panel 1. The unit is switched on/off using 2. Ventilation modes can be controlled by the buttons.
  • Page 14 Freshbox 100 WiFi www.blaubergventilatoren.de 6. In emergency situations, the unit turns off and the indicator flashes an alarm code. Alarm code Alarm description 4 long flashes Outdoor sensor is missing 3 long, 1 short flash Outdoor sensor short circuit 2 long, 1 short, 1 long flash Sensor downstream of the heat exchanger is missing 2 long, 2 short flashes Short circuit of the sensor downstream of the heat exchanger...
  • Page 15 Freshbox 100 WiFi www.blaubergventilatoren.de Following message is displayed if launching an application without connection to the unit: After installing the application, connect the mobile device to the unit as to a Wi-Fi access point (FAN: + 16 characters of the ID number) indicated on the control board and on the unit casing.
  • Page 16 Freshbox 100 WiFi www.blaubergventilatoren.de Unit password change Go to Menu ( ) - Connection - At home. • • Choose the connection and press • Enter and confirm the password. Characters allowed: 0…9, a…z, A…Z. Press the “Change Password” button. •...
  • Page 17 Freshbox 100 WiFi www.blaubergventilatoren.de Client – the unit operates on the home router network. Enter the home router details and the IP address type for the Client mode: • Enter the name of the Wi-Fi home router access point. • Enter the password for the Wi-Fi home router access point.
  • Page 18 Freshbox 100 WiFi www.blaubergventilatoren.de Open the mobile app and go to MENU -> CONNECTION -> THROUGH CLOUD SERVER: Press the ADD NEW ACCOUNT button. • • Enter a login, a password and an e-mail address for password recovery. Confirm the updated details by pressing •...
  • Page 19 Freshbox 100 WiFi www.blaubergventilatoren.de Control buttons: — Unit on/Standby. — Selection of pre-set speed. — Timer activation. Timer settings are made in the Basic Settings - Timers menu. — Week-scheduled operation mode activation. The settings of this mode are made in the Basic settings - Schedule menu.
  • Page 20 Freshbox 100 WiFi www.blaubergventilatoren.de Date and time Current time and date are displayed and adjusted in this menu. Time display format: hh:mm:ss. Date format: dd.mm.yyyy. — To enter the time and date manually. — The same time as in the mobile device will be automatically set.
  • Page 21 Freshbox 100 WiFi www.blaubergventilatoren.de Engineering menu Air flow rate Air flow rate, preset speed 1-5 and Boost mode are set in this section. Sensors This section displays the current status of all sensors: — outdoor air temperature. — supply air temperature. —...
  • Page 22 Freshbox 100 WiFi www.blaubergventilatoren.de Factory settings In this section you can reset your settings to the factory settings. Communication with the unit may be lost after restoration. If necessary, reset your Wi-Fi connection. Alarms This section displays alarms and warnings. Alarms are highlighted in red, warnings are highlighted in black.

  • Page 23: Technical Maintenance

    Freshbox 100 WiFi www.blaubergventilatoren.de TECHNICAL MAINTENANCE DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE OPERATIONS! Maintenance operations of the unit are required 3-4 times per year. Maintenance includes periodic dust removal from surfaces, cleaning and replacement of filters and dry cleaning of fans. Maintenance includes general cleaning of the unit and the following operations: 1.

  • Page 24: Troubleshooting

    Freshbox 100 WiFi www.blaubergventilatoren.de 3. Fan maintenance (once a year). Even in case of regular maintenance of the filters, some dust may accumulate inside the fans and reduce the fan performance and supply air flow. Clean the fan with a cloth or a soft brush. Do not use water, aggressive solvents, or sharp objects as they may damage the impeller.

  • Page 25: Manufacturer's Warranty

    Freshbox 100 WiFi www.blaubergventilatoren.de MANUFACTURER’S WARRANTY Production meets standard operating requirements in the USA and Canada. Blauberg warrants to the original purchaser of the unit that it will be free from defects in materials or workmanship for a period of 24 months from the date of original purchase.

  • Page 26: Certificate Of Acceptance

    Freshbox 100 WiFi www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Heat recovery air handling unit Model Freshbox 100_____WiFi Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted.
  • Page 27 Freshbox 100 WiFi www.blaubergventilatoren.de...
  • Page 28 www.blaubergventilatoren.de BUSA73-9EN-05...
