Channel 15 – Spot 4: blue
Value:
000 – 255

OPERATION VIA FOOT SWITCH

Connect the foot switch with the LED KLS-200 RGB DMX device via the 5-pin connection cable with plug.
The foot switch can be operated in sound controlled (*SND) or in DMX-controlled (*512) mode.
The default mode is AUTO; every time you start the device, the mode is what you set last time.
Pedal functions are as follows:
Pedal 1: Preset
Pedal 2: Sound controlled
Pedal 3: Freeze
Pedal 4: Black Out

CLEANING AND MAINTENANCE

The operator has to make sure that safety-relating and machine-technical installations are inspected by an
expert after every four years in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are inspected by a
skilled person once a year.
The following points have to be considered during the inspection:
1) All screws used for installing the devices or parts of the device have to be tightly connected and must not
be corroded.
2) There must not be any deformations on housings, fixations and installation spots (ceiling, suspension,
trussing).
3) The electric power supply cables must not show any damages, material fatigue (e.g. porous cables) or
sediments. Further instructions depending on the installation spot and usage have to be adhered by a
skilled installer and any safety problems have to be removed.
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device except for the fuse. Maintenance and service operations are
only to be carried out by authorized dealers.
Function:
Dimming from 0 – 100%
- 1 x press = White
- 2 x press = Red
- 3 x press = Green
- 4 x press = Blue
- 5 x press = Cyan
- 6 x press = Yellow
- 7 x press = Violet
- 8 x press = Color change every second in a continuous loop as described above.
- 9 x press = Color fade every 3 seconds in a continuous loop as described above.
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
19/20 00037747.DOC, Version 1.2
