PLEASE RETAIN
Solis I60 Single Sided
Woodburner Insert
INSTALLATION AND OPERATING INSTRUCTIONS
This appliance is hot while in operation and retains its heat for a long period of time after use. Children,
aged or infirm persons should be supervised at all times and should not be allowed to touch the hot
working surfaces while in use or until the appliance has thoroughly cooled.
When using the stove in situations where children, aged and/or infirm persons are present a fireguard
must be used to prevent accidental contact with the stove. The fireguard should be manufactured in
accordance with BS 8423:2010.
Advertisement
Table of Contents
Related Manuals for Stanley Solis I60
Summary of Contents for Stanley Solis I60
- Page 1 PLEASE RETAIN Solis I60 Single Sided Woodburner Insert INSTALLATION AND OPERATING INSTRUCTIONS This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged or infirm persons should be supervised at all times and should not be allowed to touch the hot working surfaces while in use or until the appliance has thoroughly cooled.
-
Page 2: Table Of Contents
Stanley Stove Warranty ........ -
Page 3: Stanley Stove Warranty
CONDITIONS OF WARRANTY Your Stanley Stove is guaranteed against any part that fails (under normal operating conditions) as detailed in the fol- lowing table with timelines specified from the date of installation of the appliance. If the unit is not installed within six months of date of purchase, the warranty will commence six months from the date of purchase. -
Page 4: Installation Checklist
INSTALLATION CHECK LIST Tick Flue System 1. Minimum Flue Height of 4.6 metres (15 feet). 2. Appliance should be connected to a minimum of 1.8 metres (6 feet) of 150mm (6”) flue pipe. 3. Any horizontal flue run should not exceed 150mm (6”) 4. -
Page 5: Important Operation/ Maintenance Notes
IMPORTANT OPERATION / MAINTENANCE NOTES Now that your Stanley Woodburning Stove is installed and no doubt you are looking forward to the many com- forts it will provide, we would like to give you some tips on how to get the best results from your stove. -
Page 6: Installation & Operating Instructions
INSTALLATION & OPERATING INSTRuCTIONS GENERAL The complete installation must be done in accor- dance with current Standards and Local Codes. It When installing, operating and maintaining your should be noted that the requirements and these Solis stove, respect basic standards of fire safety. publications may be superseded during the life of Read these instructions carefully before commenc- this manual. -
Page 7: Fitting Instructions
The stove must be connected to a chimney with a FITTING INSTRuCTIONS minimum continuous draught of 0.06” w.g. Poor draught conditions will result in poor performance. The stove is designed to allow the chimney be cleaned through the stove. All register plates, restricter plates, damper etc., Step 1 which could obstruct the flue at a future date should Ensure the opening is suitable for fitting of the stove. -
Page 8: Down Draughts
Step 6 DOWN DRAuGHTS Remove the fire door by opening the door approx 60 However well designed constructed and positioned, degrees & lifting it up to detach from the bottom the satisfactory performance of the flue can be hinge (see Fig. 3). adversely affected by down draught caused by near- by hills, adjacent tall buildings or trees. -
Page 9: Ventilation & Combustion Air Requirements
VENTILATION & COMBuSTION AIR REQuIRE- If there is an extraction fan fitted in adjacent rooms MENTS where this appliance is fitted, additional air vents may be required to alleviate the possibility of It is imperative that there is sufficient air supply to spillage of products of combustion from the appli- the stove in order to support correct combustion. -
Page 10: Heat Recovery Ventilation
Fig.8 Note: When Installing outside air pipe adhere to ‘Clearance to Combustible’ Section. 4” ALUMINIUM FLEXIBLE DUCT PIPE ENDS TO BE 4” OD CONNECTOR SADDLE COVERED WITH SUITABLE AIR INLET TERMINAL The area directly around the stove should not HEAT RECOVERY VENTILATION be filled with insulation such as vermiculite. -
Page 11: Warm Air Ducting System
Fig.10 POSITIONING OF THE WARM AIR DuCT The following must be adhered to when locating the warm air duct system: The air duct must not touch any combustible materials within 550mm of the back of the appliance. Take care when routing the duct to ensure it is not deformed and restricting the airflow. -
Page 12: Stove Dimensions
STOVE DIMENSIONS Solis I60 stove without frame. External air Inlet- A Diameter 80mm External Air Kit Optional extra. Part code: AOSAVKIT Note: Dimensions stated are in Centimetres unless otherwise stated and may be subject to a slight +/- variation. COMMISSIONING AND HANDOVER... -
Page 13: Recommended Fuels
RECOMMENDED FuELS All fuels should be stored under cover and kept as dry as possible prior to use. This appliance has been tested using seasoned wood logs and ONLY WOOD LOGS, WITH A MOIS- TuRE PERCENTAGE OF LESS THAN 20%, MuST BE uSED IN THIS APPLIANCE. -
Page 14: Lighting
DISPOSAL OF ASHES LIGHTING Your stove does not require an ashpan, best com- Before lighting the stove check with the installer that bustion when burning wood is achieved on a bed of the installation work and commissioning checks ash. It is not required to empty all of the ash. If there described previously have been carried out correct- is excess ash( greater than 15mm) in the stove it ly and that the chimney has been swept clean, is... -
Page 15: Periodic Maintenance
FIRE SAFETY PERIODIC MAINTENANCE To provide reasonable fire safety, the following Rope Seal Replacement should be given serious consideration. Over time, the fire door latch can loosen due to the 1. Do not over fire the stove. continued compression and hardening of the seal 2. -
Page 16: Main Exploded View
EXPLODED VIEW Item Code Description 03DEFSUPKR60 TOP BAFFLE 03ENTAIRI60 REAR BRICK RETAINER 03BFKR60 GRATE 20DEFVERI60 BOTTOM VERMICULITE BAFFLE 20LATVERIZI60 / 20LATVERDEI60 LEFT AND RIGHT SIDE VERMICULITE BRICKS (full set) 20TRAVERI60 BACK VERMICULITE BRICK (SET OF 2) -
Page 17: Door Exploded View
EXPLODED VIEW DOOR Item Code Description 04PTAI160 DOOR 04MANT DOOR HANDLE 04KITMAN DOOR HANDLE FIXINGS KIT 04XJUNBBI60 DOOR ROPE BRACKET SET 20JBMD6L16 DOOR ROPE (per meter) 20CRI60DEK DOOR GLASS 04JUNDEKI60 DOOR GLASS FIXING BRACKET... -
Page 18: Co Alarm
CLEANING A MATT BLACK/SENOTHERM CO ALARM STOVE The fitting of CO Alarms in the same room as the appliance is a compulsory requirement under cur- Cleaning should be done when the stove is cold by rent Building Regulations. For ROI an additional CO removing any dust or dirt using a dry cloth. - Page 20 Waterford Stanley Ltd., Unit 401-403, IDA Industrial Estate, Cork Road, Waterford, Ireland. www.waterfordstanley.com Rev: 001 NH 090621...
