PLEASE RETAIN
Solis F1100 Panoramic
INSTALLATION AND OPERATING INSTRUCTIONS
This appliance is hot while in operation and retains its heat for a long period of time after use. Children,
aged or infirm persons should be supervised at all times and should not be allowed to touch the hot
working surfaces while in use or until the appliance has thoroughly cooled.
When using the stove in situations where children, aged and/or infirm persons are present a fireguard
must be used to prevent accidental contact with the stove. The fireguard should be manufactured in
accordance with BS 8423:2010.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Solis F1100 Panoramic and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Stanley Solis F1100 Panoramic

  • Page 1 PLEASE RETAIN Solis F1100 Panoramic INSTALLATION AND OPERATING INSTRUCTIONS This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged or infirm persons should be supervised at all times and should not be allowed to touch the hot working surfaces while in use or until the appliance has thoroughly cooled.
  • Page 2: Table Of Contents

    Stanley Wood Stove Warranty ........
  • Page 3: Stanley Wood Stove Warranty

    WS Service Department. All warranty claims must be reported to the Waterford Stanley Service Department and must be submitted with the prod- uct serial number (located on the back of the fire door), date of purchase, proof of purchase (if requested) and details of the specific nature of the problem.
  • Page 4: Installation Checklist

    INSTALLATION CHECK LIST Tick Flue System 1. Minimum Flue Height of 4.6 metres (15 feet). 2. Appliance should be connected to a minimum of 1.8 metres (6 feet) of 150mm (6”) flue pipe. 3. The horizontal flue run should not exceed 150mm (6”) 4.
  • Page 5: Important Operation/ Maintenance Notes

    IMPORTANT OPERATION / MAINTENANCE NOTES Now that your Stanley Wood Stove is installed and no doubt you are looking forward to the many comforts it will provide, we would like to give you some tips on how to get the best results from your stove.
  • Page 6: Installation & Operating Instructions

    INSTALLATION & OPERATING INSTRUCTIONS GENERAL Please refer to the current standards, BS EN 15287- 1:2007 Design, Installation and Commissioning of When installing, operating and maintaining your chimneys. Solis Stove respect basic standards of fire safety. Read these instructions carefully before commenc- Your Solis stove is supplied with the following items: ing the installation.
  • Page 7: Flue Exit - Top And Rear

    Fig.2 A chimney / flue termination must be located to min- Flue Liner imise wind effects, a basic guide is that the distance from the termination to the roof should be at be at Sleeve least 2300mm when measured horizontally and at Flue Flue Pipe least 1000mm when measured vertically, (see...
  • Page 8: Down Draughts

    Fit the flue blanking plate to the top outlet Fig.7 connection using the nuts & bolts and place the top outlet blanking plate in position on the hob - see Fig 6. Fit the flue spigot to the back outlet connection.
  • Page 9: External Ducted Air

    NOTE: EXTERNAL DUCTED AIR There must not be an extractor fan fitted in the same Where required the combustion air supply can be room as the stove as this can cause the stove to emit ducted from outside. smoke and fumes into the room. All materials used in the manufacture of air vents should be such that the It is recommended to bring the air supply for the vent is dimensionally stable, corrosion resistant, and...
  • Page 10: Location

    There are several conditions to be considered in When installing this heater on a combustible floor, a selecting a location for your Stanley Solis Stove. floor protector consisting of a layer of non com- bustible material at least 310mm thick covered with a.
  • Page 11: Stove Dimensions

    STOVE DIMENSIONS Fig.10 Note: Dimensions stated are in millimetres unless otherwise stated and may be subject to a slight +/- variation. COMMISSIONING AND HANDOVER AIR CONTROLS On completion of the installation allow a suitable The stove has two independent air controls (see period of time for any fire cement and mortar to dry Fig 11): out, when a small fire may be lit and checked to...
  • Page 12: Recommended Fuels

    RECOMMENDED FUELS Fig.11 All fuels should be stored under cover and kept as dry as possible prior to use. This appliance has been tested using seasoned wood logs. ONLY WOOD LOGS WITH A MOISTURE % OF LESS THAN 20% MUST BE USED IN THIS APPLI- ANCE.
  • Page 13: Lighting

    LIGHTING Ashes should be placed in a metal or other non- Before lighting the stove check with the installer, that combustible container with a tight fitting lid. The the installation work and commissioning checks closed container of ashes should be placed on a described previously have been carried out correct- non-combustible material, pending final disposal.
  • Page 14: Chimney Cleaning

    CHIMNEY CLEANING WARNING:- The chimney should be cleaned twice annually or if If the CO Alarm sounds unexpectedly:- the stove is not used for a prolonged period during the summer period, it should be cleaned prior to 1. Open Doors and windows to ventilate the commencement of usage.
  • Page 15: Exploded View

    EXPLODED VIEW GRATE - 30006478 12. TOP PLATE - 30008618 TOP BAFFLE - H00237AXX 13. SIDE PANEL - 30008619 FIRE DOOR GLASS - 30008613 15. FIRE DOOR - 30009492 SIDE GLASS - 30008614 16. BACK BRICK - H00236AXX 17. SIDE BRICK - H00240AXX HANDLE ASSEMBLY - 30008615...
  • Page 16 Supplied by Waterford Stanley Ltd., Unit 401-403, IDA Industrial Estate, Cork Road, Waterford, Ireland. Tel: (051) 302300 Fax (051) 302315 Item No: N00785AXX Rev:001 SG260518...
