1/2" Composite Air Reversible Drill
Specification:
Free Speed
Drilling Cap
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
With Keyless Chuck
ST-AD2004C
500 r/min
1/2" (13 mm)
17 CFM (480 L/min)
9" (230 mm)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
2.64 lbs (1.2 kg)
Noise and Vibration:
Vibration
EN ISO 28927-5
Sound Pressure Level
Load:
3.5 m/s²
Uncertainty
K= 1.5 m/s
²
Noise
EN ISO 15744
Please always
No load: 87.5 dB(A)
Sound power level
No load: 98.5 dB(A)
noise level > 80
risk of impaired
Uncertainty
K= 3dB
ST-AD2004C-S-2311A-JUF
Remark
wear ear
protector at
environment
dB(A) due to
hearing!
Advertisement
Table of Contents
Related Manuals for Sumake ST-AD2004C
Summary of Contents for Sumake ST-AD2004C
- Page 1 3/8” (10 mm) dB(A) due to risk of impaired Air Pressure 90 psi (6.3 bar) Uncertainty Uncertainty hearing! K= 1.5 m/s K= 3dB ² Net Weight 2.64 lbs (1.2 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-AD2004C-S-2311A-JUF...
- Page 2 DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： 1/2" COMPOSITE AIR REVERSIBLE DRILL WITH KEYLESS CHUCK Model/ Serial No.： ST-AD2004C to which this declaration applies, complies with these normative documents: ...
- Page 3 Leader Water 3.2 Change the drill bit Sumake is a manufacturer and exporter of air hose separation supply the tool or the service division of our company. Disconnect the tool before attemping to put a tools since established.
- Page 4 Q'ty AD2004-01 Housing AD2004-25 Rear Plate Spacer AD2004-02 Screw AD2004-26 Reverse Lever AD2004K-03 1/2" Drill Chuck [ST-AD2004K] AD2004-27 Screw (M4x16) AD2004C-03 1/2" Keyless Chuck [ST-AD2004C] AD2004-28 AD2004-04 Washer AD2004-29 Spring AD2004-05 Front Casing AD2004-30 E-Ring AD2004-06 Ball Bearing AD2004-31 Trigger...
- Page 5 DRILL Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 Safety precautions for repetitive motions hazards 1. When using a drill to perform work-related activities, the operator can experience discomfort in the hands, arms, shoulders, neck or other parts of the body. 2. While using a drill, the operator should adopt a comfortable posture whilst maintaining a secure footing and avoiding awkward or off-balanced postures.
- Page 8 Specific safety instructions Warnings shall be given about any specific or unusual hazards associated with the use of the drill. Such warnings shall indicate the nature of the hazard, the risk of injury and the avoidance action to take. General preparation and connection: Before connecting the air hose, apply 4 to 5 drops of SAE#10-20 spindle oil at the air inlet.
