- Page 1 Dishwasher / User Manual AJ14600BD - AJ14600BDX...
- Page 2 Thank you for choosing this product. This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this user manual before using your appliance and keep this book for future reference.
-
Page 3: Table Of Contents
CONTENTS 1 SAFETY INSTRUCTIONS ................4 1.1 General Safety Warnings ....................4 1.2 Installation Warnings .....................5 1.3 During Usage........................6 2 INSTALLATION ....................8 2.1 Machine Positioning .......................8 2.2 Water Connection ......................8 2.3 Water Inlet Hose ......................8 2.4 Drain Hose (Model Depending) ..................9 2.5 Electrical Connection .....................9 2.6 Fitting The Machine Undercounter ................10 3 TECHNICAL SPECIFICATIONS .............. -
Page 4: Safety Instructions
1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened. -
Page 5: Installation Warnings
There may be some residue left in the machine after washing. Keep children away from the machine when it is open. 1.2 Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine. -
Page 6: During Usage
Always use the coated plug supplied with your machine. If the electrical cable is damaged, it should only be replaced by a qualified electrician. • Connect the hose directly to the water inlet tap. The pressure supplied by the tap should be a minimum of 0.03 MPa and a maximum of 1 MPa. - Page 7 Do not open the door while the machine is in operation, hot water may spill out. Safety devices ensure the machine stops if the door is opened. The machine door should not be left open. It may cause accidents. Place knives and other sharp objects in the cutlery basket in a blade-down position.
-
Page 8: Installation
2 INSTALLATION 2.3 Water Inlet Hose 2.1 Machine Positioning When positioning the machine, place it in an area where dishes can be easily loaded and unloaded. Do not put the machine in an area where the ambient temperature falls below 0°C. Read all warnings located on the packaging before removing the packaging and positioning the machine. -
Page 9: Drain Hose (Model Depending)
2.4 Drain Hose (Model Depending) 2.5 Electrical Connection WARNING: Your machine is set to operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection. Connect the product to a grounded outlet protected by a fuse complying with the values in the... -
Page 10: Fitting The Machine Undercounter
2.6 Fitting The Machine Undercounter If you wish to fit your machine undercounter, there must be sufficient space to do so and the wiring-plumbing must be suitable to do so (1). If the space under the countertop is suitable for fitting your machine, remove the worktop as shown in the illustration (2). -
Page 11: Technical Specifications
3 TECHNICAL SPECIFICATIONS 3.2 Technical Specifications 14 place Capacity settings Dimensions 850(mm) Height 598(mm) Width 598(mm) Depth Net weight 47,5 kg Operating 220-240V voltage / 50 Hz frequency Total current 10(A) Total power 1900(W) Maximum: Water supply 1 (Mpa) pressure Minimum: 0.03 (Mpa) 3.1 General Appearance... - Page 12 RECYCLING • Some machine components and packaging consist of recyclable materials. • Plastics are marked with the international abbreviations:(>PE<, >PP<, etc. ) • The cardboard parts consist of recycled paper. They can be put into waste paper containers for recycling. •...
-
Page 13: Before Using The Appliance
4 BEFORE USING THE 4.3 Fill The Salt (IF AVAILABLE) APPLIANCE To add softener salt, open the salt compartment cap by turning it counter 4.1 Preparing Your Dishwasher For First clockwise. (1) (2) At first use, fill the compartment with 1 kg salt and water (3) until it is almost overflowing. -
Page 14: Test Strip
4.4 Test Strip Run water Keep the Shake the Wait Set the hardness level of through the strip in the strip. (1min.) your machine. tap (1min.) water (1sec) second munite munite NOTE: The level is set to 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices. -
Page 15: Detergent Usage
4.8 Detergent Usage 4.10 Using Combined Detergents Only use detergents specifically designed These products should be used according for domestic dishwashers. Keep your to the manufacturer’s instructions. detergents in cool, dry places out of reach Never put combined detergents into the of children. - Page 16 In order to change the rinse aid level, follow the below steps before turning on the machine: • Turn on the machine by pressing the On/ Off button. • Press the Programme button for at least 5 seconds immediately after the machine is turned on.
-
Page 17: Loading Your Dishwasher
5 LOADING YOUR DISHWASHER 5.1 Recommendations Remove any coarse residue on dishes For best results, follow these loading before placing the dishes in the machine. guidelines. Start the machine with full load. Loading the household dishwasher up to the capacity indicated by the manufacturer will contribute to energy and water savings. - Page 18 Four Folding Racks Height Adjustment The folding racks allow easier placement of The upper basket includes a mechanism larger items, such as pots and pans. Each which enables the height of the basket section can be folded separately. The to be adjusted up (1) or down (2) without racks can be raised up, or folded down, as having to remove the basket.
- Page 19 Height Adjustable Rack (peg type) Upper Cutlery Basket The foldable racks in the upper basket The upper cutlery basket is designed for enable the placement of large items such the placement of large and small cutlery as pots and pans. Each section can be folded separately.
-
Page 20: Alternative Basket Loads
5.2 Alternative Basket Loads Unsuitable Items For Dishwashing Lower Basket • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-alloy materials. • Forks, spoons and knives with wooden, bone, ivory or nacrecoated handles; glued items, items soiled with abrasive, acidic or base chemicals. •... -
Page 21: Programme Table
EN - 21... - Page 22 • The program duration may change according to the amount of dishes, the water temperature, the ambient temperature and selected additional functions. • Values given for programmes other than the eco programme are indicative only • Eco programme is suitable to clean normally soiled tableware, that for this use, it is the most efficient programme in terms of its combined energy and water consumption, and that it is used to assess compliance with the EU ecodesign legislation.
-
Page 23: The Control Panel
7 THE CONTROL PANEL 3. Delay Button You can delay the start time of the prog- ramme for 1-2...24 hours by pressing the delay button (3) before the programme starts. The delay indicator (3.1) will be on. If you want to change the delay time,first press the Start/Pause button and then the delay button to select a new delay time. -
Page 24: Changing A Programme
maximum hygiene washing operation. The NOTE: Child lock is activated/ Extra Hygiene Indicator will illuminate. deactiva-ted by pressing select button (7) for about 3 seconds. When it is activated, all leds blink and “CL” is shown on Remaning 12. Half Load Indicator Time Indicator (4) once. -
Page 25: Cancelling A Programme
7.2 Cancelling a programme Buzzer Sound Control (Model Depending) If you would like to cancel a programme To change the buzzer sound level, follow when it is running. the below steps: 1. Open the door and press Option (6) and Select (7) buttons at the same time for 3 seconds. - Page 26 Pure Beam (Model Depending) This technology which have Ion and Light Technology together, provides to extra hygi- ene. It prevents bad odor during a washing program that includes a drying step. Pure Beam function is activated or deacti- vated before starting program by pressing Options button (6) for 6 seconds.
-
Page 27: Cleaning And Maintenance
8 CLEANING AND To remove and clean the filter combination, turn it counter clockwise and remove it by MAINTENANCE lifting it upwards (1).Pull the coarse filter Cleaning your dishwasher is important to out of the micro filter (2).Then pull and maintain the machine’s service life remove the metal filter (3).Rinse the filter Make sure that the water softening setting... -
Page 28: Drain Pump
8.3 Drain Pump Large food residues or foreign objects which were not captured by the filters may block the waste water pump. The rinsing water will then be above the filter. Warning Risk of cuts! When cleaning the waste water pump, ensure that you do not injure yourself on p ieces of broken glass or pointed implements. -
Page 29: Troubleshooting
9 TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start. - Page 30 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.
- Page 31 AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of Water inlet system failure the hose.
- Page 32 Imported by B73737553 Av. Altos Hornos S/N. Pto. Sagunto (46520). Valencia, España. www.aspes.es aspes@sareteknika.es; 902 99 69 01 / 944 04 14 08 5xxxxx...
