EN Dishwasher / User Manual
ALV136 / X

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALV136/X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aspes ALV136/X

Summary of Contents for Aspes ALV136/X

  • Page 1 EN Dishwasher / User Manual ALV136 / X...
  • Page 2 Thank you for choosing this product. This User Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.

  • Page 3: Table Of Contents

    CONTENTS 1.SAFETY INSTRUCTIONS ....................1 1.1. General Safety Warnings ....................1 1.2. Installation Warnings .....................1 1.3. During Use........................2 2.INSTALLATION ......................... 6 2.1. Machine Positioning .....................6 2.2. Water Connection ......................6 2.3. Water Inlet Hose ......................6 2.4. Drain Hose........................6 2.5. Electrical Connection ....................7 2.6.
  • Page 4 8.CLEANING AND MAINTENANCE ................. 18 8.1. Cleaning the Machine and Filters ................18 8.2. Spray Arms ........................18 9.TROUBLESHOOTING ....................19 10.PRACTICAL INFORMATION ..................21...

  • Page 5: Safety Instructions

    1. SAFETY INSTRUCTIONS 1.1. General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed.

  • Page 6: Installation Warnings

    1.2. Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine. Unplug the machine before installation. Your machine must only be installed by an authorised service agent. Installation by anyone other than an authorised agent may cause your warranty to be void.
  • Page 7 • it for other purposes. Commercial use will void the guarantee. Do not stand, sit or place loads on the open door of the dishwasher. Only use detergents and rinse aids produced specifically for dishwashers. Our company is not responsible for any damage that may occur due to misuse.
  • Page 8 be performed by an authorised service company, otherwise the warranty will be void. Before repair work, the machine should be disconnected from the mains. Do not pull the cable to unplug the machine. Switch off the water tap. Operation at a low voltage will cause a decline in performance levels.
  • Page 9 CE Declaration of Conformity We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. Disposal of your old machine The symbol on the product or on its packaging indicates that this product may not be treated as household waste.

  • Page 10: Installation

    2. INSTALLATION new hose before connecting. 2.1. Machine positioning WARNING: Connect the hose directly to the water inlet tap. The pressure When positioning the machine, place it in supplied by the tap should be a minimum an area where dishes can be easily loaded of 0.03 MPa and a maximum of 1 MPa.

  • Page 11: Electrical Connection

    WARNING: After removing the top panel of your dishwasher, the machine should be placed in a space of the dimensions shown in the figure below. 2.5. Electrical connection WARNING: Your machine is set to operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection.

  • Page 12: Technical Specifications

    3. TECHNICAL SPECIFICATIONS 3.2. Technical specifications 15 place Capacity settings Dimensions (mm) Height 850(mm) Width 598(mm) Depth 598(mm) 53,600 kg Net weight Operating 220-240V voltage / 50 Hz, frequency Total current 10(A) 3.1. General appearance 1. Worktop 2. Upper basket with racks Total power 3.

  • Page 13: Before Using The Appliance

    4. BEFORE USING machine against corrosion. THE APPLIANCE 4.1. Preparing your Dishwasher for first use • Make sure the electricity and supply water specifications match the values indicated in the installation instructions for the machine. • Remove all packaging material inside the machine.

  • Page 14: Test Strip

    4.3. Test Strip Run water Keep the Shake the Wait Set the hardness level of through the strip in the strip. (1min.) your machine. tap (1min.) water (1sec) NOTE: The level is set to 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices.

  • Page 15: Filling The Detergent

    Keep your detergents in cool, dry places up any spills. out of reach of children. In order to change the rinse aid level, follow the below steps before turning on See the detergent manufacturer’s the machine: instructions for further information. •...

  • Page 16: Loading Your Dishwasher

    5. LOADING YOUR DISHWASHER For best results, follow these loading guidelines. We recommend that you place large items (pots, pans, lids, plates and bowls) which are heavily soiled in the lower basket. The upper basket is designed for delicate and lighter dishware such as glasses, coffee and tea cups and saucers.
  • Page 17 Upper Cutlery Basket Four Folding Racks The upper cutlery basket is designed for the (15 pc) placement of large and small cutlery and The folding racks allow easier placement of utensils. larger items, such as pots and pans. Each section can be folded separately. The racks can be raised up, or folded down, as shown in the images.

  • Page 18: Alternative Basket Loads

    5.2. Alternative Basket Loads Lower Basket Top basket Incorrect loads EN - 14...

  • Page 19: Programme Table

    6. PROGRAMME TABLE Duration Programme Description (min) Jetwash 14’ To rinse dishes that you plan to wash later. Quick 40°C For lightly soiled dishes and a quick wash. Eco (Reference) Standard programme for normally soiled, daily-used dishes. For both lightly soiled delicate glassware and heavily soiled crockery at Dual Pro Wash the same time.

  • Page 20: The Control Panel

    7. THE CONTROL PANEL 7. Start/Pause Button Press the Start/Pause button to start the programme. The wash lamp turns on and the Remaining Time Indicator shows the programme duration. It also indicates the remaining time during the programme flow. If you open the door of your machine when the programme is running the duration of the programme pauses,and the Start/Pause led blinks.

  • Page 21: Changing A Programme

    NOTE: Child lock is activated/deacti- vated by pressing the select button (5) for about 3 seconds. When it is activated, all leds blink and “CL” is shown on the Re Press the Start/Pause button for 3 seconds. During cancellation, the NOTE: If you switch the machine to off End light blinks.

  • Page 22: Cleaning And Maintenance

    8. CLEANING AND the filters. Replace the filter insert, and MAINTENANCE rotate it clockwise (4). • Never use your Dishwasher without a Cleaning your Dishwasher is important filter. to maintain the machine’s service life. • Incorrect fitting of the filter will reduce Oil and lime may build up in your the washing effectiveness.

  • Page 23: Troubleshooting

    9. TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start.
  • Page 24 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.

  • Page 25: Practical Information

    AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing Separate the inlet hose from the tap and clean the filter of Insufficient water the hose.
  • Page 26 11. THE PRODUCT FICHE Supplier's trade mark ASPES ALV136 / X Supplier's model Capacity of dishwasher The energy efficiency class A+++ Annual energy consumption in kWh per year (AEc) ( 280 Cycle )* Energy consumption (Et) (kWh per cycle) 0,84...
  • Page 27 55555555...
