- Page 1 Dishwasher / User Manual AJ12600E - AJ12600EX...
- Page 2 Thank you for choosing this product. This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this user manual before using your appliance and keep this book for future reference.
-
Page 3: Table Of Contents
CONTENTS 1 SAFETY INSTRUCTIONS ................4 1.1 General Safety Warnings ....................4 1.2 Installation Warnings .....................5 1.3 During Usage........................6 2 INSTALLATION ....................9 2.1 Machine Positioning .......................9 2.2 Water Connection ......................9 2.3 Water Inlet Hose ......................9 2.4 Drain Hose (Model Depending) ..................10 2.5 Electrical Connection ....................10 2.6 Fitting The Machine Undercounter ................11 3 TECHNICAL SPECIFICATIONS .............. -
Page 4: Safety Instructions
1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened. -
Page 5: Installation Warnings
There may be some residue left in the machine after washing. Keep children away from the machine when it is open. 1.2 Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine. -
Page 6: During Usage
Always use the coated plug supplied with your machine. If the electrical cable is damaged, it should only be replaced by a qualified electrician. • Connect the hose directly to the water inlet tap. The pressure supplied by the tap should be a minimum of 0.03 MPa and a maximum of 1 MPa. - Page 7 Do not open the door while the machine is in operation, hot water may spill out. Safety devices ensure the machine stops if the door is opened. The machine door should not be left open. It may cause accidents. Place knives and other sharp objects in the cutlery basket in a blade-down position.
- Page 8 Pull the plug to disconnect the machine from the mains, never pull on the cord. EN - 8...
-
Page 9: Installation
2 INSTALLATION 2.3 Water Inlet Hose 2.1 Machine Positioning When positioning the machine, place it in an area where dishes can be easily loaded and unloaded. Do not put the machine in an area where the ambient temperature falls below 0°C. Read all warnings located on the packaging before removing the packaging and positioning the machine. -
Page 10: Drain Hose (Model Depending)
2.4 Drain Hose (Model Depending) 2.5 Electrical Connection WARNING: Your machine is set to operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection. Connect the product to a grounded outlet protected by a fuse complying with the values in the... -
Page 11: Fitting The Machine Undercounter
2.6 Fitting The Machine Undercounter If you wish to fit your machine undercounter, there must be sufficient space to do so and the wiring-plumbing must be suitable to do so (1). If the space under the countertop is suitable for fitting your machine, remove the worktop as shown in the illustration (2). -
Page 12: Technical Specifications
3 TECHNICAL SPECIFICATIONS 3.2 Technical Specifications 12 place Capacity settings Dimensions Height 850(mm) Width 598(mm) Depth 598(mm) Net weight 41 kg Operating 220-240V voltage / 50 Hz frequency Total current 10(A) Total power 1900(W) Maximum: Water supply 1 (Mpa) pressure Minimum: 0.03 (Mpa) 3.1 General Appearance... - Page 13 RECYCLING • Some machine components and packaging consist of recyclable materials. • Plastics are marked with the international abbreviations:(>PE<, >PP<, etc. ) • The cardboard parts consist of recycled paper. They can be put into waste paper containers for recycling. •...
-
Page 14: Before Using The Appliance
4 BEFORE USING THE 4.3 Fill The Salt (IF AVAILABLE) APPLIANCE To add softener salt, open the salt compartment cap by turning it counter 4.1 Preparing Your Dishwasher For First clockwise. (1) (2) At first use, fill the compartment with 1 kg salt and water (3) until it is almost overflowing. -
Page 15: Test Strip
4.4 Test Strip Run water Keep the Shake the Wait Set the hardness level of through the strip in the strip. (1min.) your machine. tap (1min.) water (1sec) second munite munite NOTE: The level is set to 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices. -
Page 16: Detergent Usage
4.8 Detergent Usage 4.10 Using Combined Detergents Only use detergents specifically designed These products should be used according for domestic dishwashers. Keep your to the manufacturer’s instructions. detergents in cool, dry places out of reach Never put combined detergents into the of children. -
Page 17: Filling The Rinse-Aid And Setting
4.12 Filling The Rinse-aid And Setting To fill the rinse aid compartment, open the rinse-aid compartment cap. Fill the compartment with rinse aid to the MAX level and then close the cap. Be careful not to overfill the rinse aid compartment and wipe up any spills. -
Page 18: Loading Your Dishwasher
5 LOADING YOUR DISHWASHER 5.1 Recommendations Remove any coarse residue on dishes For best results, follow these loading before placing the dishes in the machine. guidelines. Start the machine with full load. Loading the household dishwasher up to the capacity indicated by the manufacturer will contribute to energy and water savings. - Page 19 Upper Basket Height Adjustable Rack (peg type) Height Adjustment The height adjustable racks enable glasses Turn the Rail Stop Clips, at the ends of the and cups to be placed on or under the rails, to the sides to open them (as shown racks.
-
Page 20: Alternative Basket Loads
5.2 Alternative Basket Loads Unsuitable Items For Dishwashing Lower Basket • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-alloy materials. • Forks, spoons and knives with wooden, bone, ivory or nacrecoated handles; glued items, items soiled with abrasive, acidic or base chemicals. •... -
Page 21: Programme Table
EN - 21... - Page 22 • The program duration may change according to the amount of dishes, the water temperature, the ambient temperature and selected additional functions. • Values given for programmes other than the eco programme are indicative only • If your model has turbidity sensor, it has Auto program instead of Intensive program. •...
-
Page 23: The Control Panel
7 THE CONTROL PANEL 5. Delay Button It is used for activation of delay timer. When it is pushed once, 3h timer is activated. 6h and 9h delay timer is activated during consecutive pushes, respectively. If both delay leds are active, it means that 9h delay timer is active. -
Page 24: Changing A Programme
7.1 Changing a Programme Follow the steps below to change a programme while in operation. 7.3 Switching The Machine Off NOTE: Do not open the door before the programme is complete. NOTE: Leave the door slightly open at the end of a wash programme to speed up the drying process. - Page 25 NOTE: Buzzer sounds 5 times each at 5 minutes intervals (in 0, 5, 10 and 15th minutes) in total 4 different times at the end of the program.(model depending) Save Power Mode To activate or deactivate save power mode, follow the below steps: 1.
-
Page 26: Cleaning And Maintenance
8 CLEANING AND 8.1 Filters MAINTENANCE Clean the filters and spray arms at least once a week. If any food waste remains Cleaning your dishwasher is important to maintain the machine’s service life or foreign objects on the coarse and Make sure that the water softening setting fine filters, remove them and clean them (If available) is done correctly and correct... -
Page 27: Spray Arms
8.2 Spray Arms 8.3 Drain Pump Make sure that the spray holes are not Large food residues or foreign objects which clogged and that no food waste or foreign were not captured by the filters may block object is stuck to the spray arms. If there is the waste water pump. -
Page 28: Troubleshooting
9 TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start. - Page 29 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.
- Page 30 AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE CODE POSSIBLE FAULT WHAT TO DO Start / Wash Pause Make sure the water inlet tap is open and water is flowing. *Water inlet system Separate the inlet hose from the tap and failure clean the filter of the hose.
- Page 31 *Note: The led showing water inlet system failure varies depending on the model. The installation and repairing procedures should always carried out by the Authorised Service Agent in order to avoid possible risks. The manufacturer shall not be held liable for damages that may arise from procedures carried out by unauthorised persons.
- Page 32 Imported by B73737553 Av. Altos Hornos S/N. Pto. Sagunto (46520). Valencia, España. www.aspes.es aspes@sareteknika.es; 902 99 69 01 / 944 04 14 08 5XXXXXXX...
