INSTRUCTION MANUAL
INDEX
Midi-B FX
Congratulations on choosing a Claypaky product!
We thank you for your custom.
Please note that this product, as all the others in the
rich Claypaky range, has been designed and made with
total quality to ensure excellent performance and best
meet your expectations and requirements.
1
CL3028
Advertisement
Table of Contents
Related Manuals for ARRI Claypaky Midi-B FX
Summary of Contents for ARRI Claypaky Midi-B FX
-
Page 1: Table Of Contents
Midi-B FX CL3028 INSTRUCTION MANUAL INDEX Congratulations on choosing a Claypaky product! Page Contents We thank you for your custom. Safety information Please note that this product, as all the others in the rich Claypaky range, has been designed and made with Unpacking and preparation total quality to ensure excellent performance and best Installation and start-up... -
Page 2: Safety Information
1. SAFETY INFORMATION SAFETY INFORMATION IMPORTANT: Claypaky recommends you carefully read and keep the safety information on this product, also available in digital format at the following link: www.claypaky.com Ref: [FIS02Q - Safety Information Midi-B FX] INFORMAZIONI DI SICUREZZA IMPORTANTE: Claypaky raccomanda di leggere accuratamente e conservare le informazioni di sicurezza relative a questo prodotto, sempre reperibili in versione digitale al seguente link: www.claypaky.com Rif: [FIS02Q - Safety Information Midi-B FX]... -
Page 3: Unpacking And Preparation
2. UNPACKING AND PREPARATION 2 x 183102/805 Packing contents - Fig. 1 UNLOCKED LOCKED LOCKED UNLOCKED PAN Mechanism Lock and Release (every 90°) - Fig. 2 TILT Mechanism Lock and Release (every 45°) - Fig. 3 Midi-B FX... -
Page 4: Installation And Start-Up
3. INSTALLATION AND START-UP 3.1 Installing the fixture Installing the projector - Fig. 4 The projector can be installed on the floor resting on special rubber feet, on a truss or on the ceiling or wall. WARNING: with the exception of when the projector is positioned on the floor, the safety cable must be fitted. (Cod. 105041/003 available on request). This must be securely fixed to the support structure of the projector and then connected to the fixing point at the centre of the base. -
Page 5: Connecting To Manis Supply
3.2 Connecting to manis supply Connecting and disconnecting power cable - Fig. 6 Mains Connecting to the mains supply - Fig. 7 3.3 Connecting the control signal line: DMX / Art-Net DMX 512 5 PIN SCREEN SIGNAL SIGNAL Ethernet Connecting to the control signal line (DMX) - Fig. 8 Use a cable conforming to specifications EIA RS-485: 2-pole twisted, shielded, 120Ohm characteristic impedance, 22-24 AWG, low capacity. -
Page 6: Switching On The Fixture And Basic Setup
3.4 Switching on the fixture and basic SetUp Dmx Address Warning Message Switching on the projector - Fig. 9 Switch-on the fixture. The projector starts resetting the effects. At the same time, the following information scrolls on the display: Model Midi-B FX On conclusion of resetting in case of absence of the dmx signal, Pan and Tilt move to the “Home”... - Page 7 Functions of the buttons - Using the menu Confirms the displayed value, or activates the displayed function, or enters the successive menu. Decreases the value displayed (with auto-repetitions) or passes to the next item in the menu. DOWN Increases the value displayed (with auto-repetitions) or passes to the previous item in a menu. Return to the top level LEFT Enters the successive menu.
-
Page 8: Maintenance
4. MAINTENANCE 4.1 Maintenance and Caution WARNING: no alcohol Light collimation system This product contains internal light collimation system. Avoid intense light from any angle. CAUTION: • To avoid damage to the internal parts of the fixture when the fixture is not working, is recommended to turn the head down before turning the fixture off, so that the front lenses of the fixture are invested as little as possible from the sun. -
Page 9: Battery Removal
4.2 Battery removal Battery removal - Fig. 12 This product contains a rechargeable battery. To preserve the environment, please dispose the battery at the end of its life according to the regulation in force. ‘ Continue Midi-B FX... -
Page 10: Opening The Covers
4.3 Opening the covers Opening the covers - Fig. 13 Midi-B FX... - Page 11 Cleaning the filters - Fig. 14 Midi-B FX...
-
Page 12: Dimensions
5. DIMENSIONS Midi-B FX (19.45") (10.24") (14.25") (14.57") (23.62") (15.75") (18.66") (15.35") (9.92") 6. CAUSE AND SOLUTION OF PROBLEMS THE PROJECTOR WILL NOT SWITCH ON ELECTRONICS NON-OPERATIONAL PROBLEMS DEFECTIVE PROJECTION REDUCED LUMINOSITY POSSIBLE CAUSES CHECKS AND REMEDIES No mains supply. Check the power supply voltage.
