AROLLA AQUA
INSTRUCTION MANUAL
INDEX
Congratulations on choosing a Claypaky product!
We thank you for your custom.
Please note that this product, as all the others in the
rich Claypaky range, has been designed and made with
total quality to ensure excellent performance and best
meet your expectations and requirements.
CL3027
Advertisement
Table of Contents
Related Manuals for ARRI Claypaky Arolla Aqua
Summary of Contents for ARRI Claypaky Arolla Aqua
-
Page 1: Table Of Contents
AROLLA AQUA CL3027 INSTRUCTION MANUAL INDEX Congratulations on choosing a Claypaky product! Page Contents We thank you for your custom. Safety information Please note that this product, as all the others in the rich Claypaky range, has been designed and made with Unpacking and preparation total quality to ensure excellent performance and best Installation and start-up... -
Page 2: Safety Information
1. SAFETY INFORMATION SAFETY INFORMATION IMPORTANT: Claypaky recommend you to carefully read and keep the safety information on this product, also available in digital format at the following link: www.claypaky.com Ref: [FIS02M - Safety Information Arolla Aqua] INFORMAZIONI DI SICUREZZA IMPORTANTE: Claypaky raccomanda di leggere accuratamente e conservare le informazioni di sicurezza relative a questo prodotto, sempre reperibili in versione digitale al seguente link: www.claypaky.com... -
Page 3: Unpacking And Preparation
2. UNPACKING AND PREPARATION Omega bracket Wi-fi receiver IP 65 connector Packing contents - Fig. 1 LOCKED UNLOCKED PAN Mechanism Lock and Release (every 90°) - Fig. 2 TILT Mechanism Lock and Release (every 45°) - Fig. 3 AROLLA AQUA... -
Page 4: Installation And Start-Up
3. INSTALLATION AND START-UP 3.1 Installing the fixture Light collimation system This product contains internal light collimation system. Avoid intense light from any angle. Installing the projector - Fig. 4 The projector can be installed on the floor resting on special rubber feet, on a tr<uss or on the ceiling or wall. WARNING: with the exception of when the projector is positioned on the floor, the safety cable must be fitted. -
Page 5: Connecting The Signal Control Line: Dmx / Art-Net
Mains Connecting to the mains supply - Fig. 7 3.3 Connecting the signal control line: DMX / Art-Net Connecting to the control signal line (DMX) - Fig. 8 Use a cable compliant to the EIA RS-485 specifications: 2-pole twisted, shielded, 120Ohm characteristic impedance, 22-24 AWG, low capacity. Do not use microphone cables or other cables with characteristics differing from those specified. - Page 6 Reversal of the display - Fig. 10 To activate this function, press UP and DOWN keys simultaneously while the display is in the rest mode. This status will be memorised and maintained even for the next time it will be switched on. To return to the initial state, repeat the operation all over again. Setting the projector starting address On each projector, the starting address must be set for the control signal (addresses from 1 to 512).
-
Page 7: Maintenance
4. MAINTENANCE 4.1 Opening the covers WARNING - IP66 fixture - Failure to completely remove power from fixture prior to servicing can lead to serious injury or death. For additonal service information please contact service@claypaky.it IMPORTANT To maintain IP66 rating each cover has rubber gasket on it. If any rubber gasket is lost or damaged, it must be replaced by an original equipment (OE) part. -
Page 8: Periodical Cleaning
4.2 Periodical cleaning Upper Side Lower Side Periodical cleaning - Fig. 13 To ensure optimal operation and performance for a long time it is essential to periodically clean the parts subject to dust and grease deposits. The frequency with which the following operations are to be carried out depends on various factors, such as the amount of the effects and the quality of the working environment (air humidity, presence of dust, salinity, etc.). -
Page 9: Effect Module Removal
4.3 Effect module removal Extraction of the effect modules - Fig. 14. IMPORTANT: Grasp the modules using the support structure and not the details which could get damaged. Insertion of the effect modules: Repeat the operations indicated in Fig. 14, 15 and 16 in reverse order. NOTE: - Do not disconnect wiring harnesses when the fixture is switched on, to avoid to damage electronic boards. - Page 10 Extraction of the effect modules - Fig. 15. IMPORTANT: Grasp the modules using the support structure and not the details which could get damaged. Insertion of the effect modules: Repeat the operations indicated in Fig. 14, 15 and 16 in reverse order. NOTE: - Do not disconnect wiring harnesses when the fixture is switched on, to avoid to damage electronic boards.
- Page 11 Extraction of the effect modules - Fig. 16. IMPORTANT: Grasp the modules using the support structure and not the details which could get damaged. Insertion of the effect modules: Repeat the operations indicated in Fig. 14, 15 and 16 in reverse order. NOTE: - Do not disconnect wiring harnesses when the fixture is switched on, to avoid to damage electronic boards.
-
Page 12: Rotating Gobos
4.4 - Rotating gobos Gobo holder replacement - Fig. 17 COATED GLASS GOBOS TYPE 1 COATED GLASS GOBOS TYPE 2 Coated side Coated side towards Grey/Black side light source away from light source Uncoated side Reflective side towards light source To determine which side of a godo is coated, hold an odject up to it. - Page 13 INDEX Replacing rotating gobos - Fig. 19 - Original gobos have a special coating designed specifically to resist to high temperatures; - IMPORTANT The rotating gobo wheel only uses dichroic glass gobos. Do not use metal gobos. - For any additional information please contact Claypaky service center. Static gobo - Fig.
-
Page 14: Battery Removal
4.5 Battery removal Battery removal - Fig. 21 This product contains a rechargeable battery. To preserve the environment, please dispose the battery at the end of its life according to the regulation in force. AROLLA AQUA... -
Page 15: Dimensions
5. DIMENSIONS (22.76") (21.22") (16.93") (29.25") (23.35") (17.72") (12.80") Cause and solution of problems THE PROJECTOR WILL NOT SWITCH ON ELECTRONICS NON-OPERATIONAL PROBLEMS DEFECTIVE PROJECTION REDUCED LUMINOSITY POSSIBLE CAUSES CHECKS AND REMEDIES No mains supply. Check the power supply voltage. LED source exhausted or defective. - Page 16 www.claypaky.com – Service support & Helpdesk: https://e-assist.tech...
