Toto AP WASHLET CWT4263046CMFG Quick Start Manual

AP WASHLET
FEATURES
AP Bowl
• DYNAMAX TORNADO FLUSH
efficiency (1.28GPF/0.9GPF)
• CEFIONTECT ceramic glaze - prevents debris, mold
®
from sticking to ceramic surfaces
• Universal Height
• Elongated shape front bowl
S500e WASHLET
• Contemporary lid design
• Elongated front WASHLET toilet with seat cover
• Mounting hardware included
DuoFit In-Wall Tank
• Dual flushing system, high-efficiency
(1.28 GPF/4.8 LPF & 0.9 GPF/3.4 LPF) Avg. flush 1.03 GPF
• Adjustable 15"-19" mounting height
• Saves up to 9" of floor space compared to standard
floor-mounted toilet
• Supports up to 880lbs
• Commercial 2" x 6" or optional residential installation
with 2" x 4" wall studs with waste outlet kit
• Copper supply line
Push Plate
• YT930#MS
Matte Silver Basic Round Push Plate
KIT COMPONENTS
• CT426CFGT40#01
AP Wall-Hung Toilet
• WT173M
In-Wall Tank System (Copper Pipe)
• SW3046AT40#01
S500e WASHLET
Elongated WASHLET
• THU805
WASHLET connection kit
• YT930#MS
Matte Silver Basic Round Push Plate
Available Options
• YT920#WH - White Matte Basic Square Push Plate
• YT920#MS - Matte Silver Basic Square Push Plate
• YT930#WH - White Matte Basic Round Push Plate
• YT970#SS - Stainless Steel Wall Round Push Plate
• YT980#SS - Stainless Steel Wall Round Push Plate
CWT4263046CMFG
+ S500e Wall-Hung Toilet, 1.28GPF & 0.9GPF
®
system, high
®
DYNAMAX
TORNADO FLUSH
CEFIONTECT
COLORS/FINISHES
• Standard
#01 Cotton
CODES/STANDARDS
• Meets or exceeds:
-Bowl: ASME A112.19.2/CSA B45.1, ASME A112.19.14
-Carrier System: ASME A112.6.2
-Tank Trim: IAPMO PS50, CSA B125.3, ASSE1002
• Certifications: IAPMO (cUPC), EPA WaterSense State
of Massachusetts, City of Los Angeles and others
• Legislative compliance: California AB715, California
Green Building Code, City of Los Angeles Water
Efficiency Ordinance
• Code Compliance: UPC, IPC, NSPC, NPC Canada,
and others
• Complies with CA Prop 65 warning requirements
Certified by
IAPMO R&T
Skirted Design
