- Page 1 TRANSOM MOUNT TRANSOM MOUNT ELECTRIC MOTOR OWNERS MANUAL ASP T18-SW (55043) ASP T24-SW (55199) Watersnake Asp Transom Motor User Manual (Ver.3)
- Page 2 Please read this manual completely before starting installation and using the electric motor. Disclaimer: The information provided in this Watersnake Motor Manual is correct at time of printing. For the most up to date information, check for the latest version on our website at...
-
Page 3: Table Of Contents
HEAD UNIT AND SPEED CONTROL ............ 14 RECOMMENDATIONS WHEN USING YOUR MOTOR ......15 AFTER EVERY USE ................15 MOTOR MAINTENANCE AND STORAGE ..........16 TROUBLESHOOTING ................17 OPTIONAL ACCESSORIES ..............18 MOTOR SPECIFICATIONS ..............19 MOTOR SCHEMATICS AND PARTS LISTS ........... 20 www.watersnake.com.au... -
Page 4: Know Your Boat
KNOW YOUR BOAT Starboard Gunwale Stern Port Keel Gunwale Stern Hull Outboard Inboard Starboard Port Stern / Transom Watersnake Asp Transom Motor User Manual (Ver.3) -
Page 5: Features Of Your Motor
Motor unit Motor unit Please note: the ASP T18 model does not have a tilting feature. PLEASE NOTE: Specifications are subject to change without notice. Diagram of motor is for reference only and may be different from your actual motor. www.watersnake.com.au... -
Page 6: Installation
Watersnake motor. 2. Select desired mounting location on boat/kayak. 3. 12V deep cycle or 12V LiFePO4 battery (your Watersnake motor IS NOT designed for use with car / truck /motorcycle type batteries) – for more information about appropriate batteries for your Watersnake motor, refer to page 7. -
Page 7: Battery And Power
BEST PRACTICES INSTALLING AND CONNECTING YOUR MOTOR 1. Your Watersnake motor is designed to be powered by a 12v deep cycle or LifePO4 battery that should output no more than 14.5v. If the voltage input to your Watersnake motor exceeds 14.5v it may damage the sensitive electronics and void your warranty. -
Page 8: Inline Fuse Or Circuit Breaker
INLINE FUSE OR CIRCUIT BREAKER An inline fuse or circuit breaker is required when connecting your Watersnake Asp motor to the battery. This is a connection that joins the motor battery cable to the battery and protects the motor by shutting off power in the event of an overload or short circuit. -
Page 9: Extending Battery Leads
BOXES WITH BUILT-IN CIRCUITRY Battery Boxes use low quality electrical components that cannot handle the high current loads that trolling motors draw. We recommend connecting your Watersnake motor directly to a deep cycle or LiFePO4 battery using the provided battery leads. SIMPLE BATTERY... -
Page 10: Connecting Your Motor To The Battery
• Your Watersnake comes factory-fitted with a standard length of twin flex wiring with alligator clips to attach to the battery. • Before connecting the motor’s cables to the battery terminals, ensure all switches are in the OFF position and stand clear of the propeller. -
Page 11: Attaching The Propeller
Shaft, making sure the Pin sits in the groove. 3. While holding the Propeller, tighten the Propeller Nut firmly with the provided tool. Shear pin Propeller Nut Propeller Shaft Propeller Tool to tighten the Propeller Nut. www.watersnake.com.au... -
Page 12: Attaching The Motor To Your Boat
Check fuse assembly / circuit breaker – clean if any signs of corrosion or debris. Replace fuse if necessary. ( If your motor is equiped with one. ) NOTE: Please ensure this Watersnake motor is not your only means of propulsion. Please follow the marine safety guide lines set by your state or country of use. -
Page 13: Depth Adjustment
(B). ASP T18 BRACKET STOWING Depth collar height adjustment When your Watersnake motor is not Steering Counter- in use always Force adjustment stow and store it properly. -
Page 14: Head Unit And Speed Control
This makes the motor more compact and easier to store away when not in use. Pull the Pull the button button and and the handle push the will extend handle in. automatically. Watersnake Asp Transom Motor User Manual (Ver.3) -
Page 15: Recommendations When Using Your Motor
Of course once you engage your Watersnake motor for use make sure that it is in the right place, not too low or too high. Once you are in deep water, you should make sure that you gradually increase the speed of your trolling motor, do not accelerate it up to full speed right away. -
Page 16: Motor Maintenance And Storage
Inspect battery terminals and cables for signs of corrosion. Remove buildup with a wire brush and treat with anti-corrosion spray. • Remove motor from boat and store in a cool, dry place away from temperature extremes. Watersnake Asp Transom Motor User Manual (Ver.3) -
Page 17: Troubleshooting
Watersnake spare parts and motor repair videos can support page. be found on our Watersnake motor support webpage: https://www.watersnake.com.au/pages/electric-motor-servicing For more help you can also contact the Watersnake distributor for your region. ( Please see the back cover. ) www.watersnake.com.au... -
Page 18: Optional Accessories
2 Springs. 2 Brushes 2 Holders 2 Screws PLEASE NOTE: Spare parts may not be available in all areas. Please check with your local stockist. Online ordering available please see back page for details. Watersnake Asp Transom Motor User Manual (Ver.3) -
Page 19: Motor Specifications
MOTOR SPECIFICATIONS MODEL CODE: 55043 NAME: ASP T18-SW ( White Saltwater ) VOLTAGE (V) MAX.THRUST (LB) 18lb SHAFT LENGTH (IN) 24" MIN. / MAX. AMP DRAW (A) MIN.7A MAX.15A MAX. PROP RPM (NO LOAD) 1400rpm SPEEDS 2 FORWARD AND 2 REVERSE... -
Page 20: Motor Schematics And Parts Lists
SCHEMATIC & PARTS LIST 55043 ASP T18-SW Watersnake Asp Transom Motor User Manual (Ver.3) - Page 21 SCHEMATIC & PARTS LIST 55199 ASP T24-SW www.watersnake.com.au...
- Page 22 THE BELOW INFORMATION IS FOR THE USA ONLY. Watersnake Limited One Year Warranty (USA) All watersnake products are covered by a one year Limited Warranty covering faults in workmanship and materials from the date of original retail purchase. The purchaser shoud return...
- Page 23 NOTES: www.watersnake.com.au...
- Page 24 297-305 South Gippsland Highway Dandenong South, Victoria 3175 Australia ACN: 143 230 175 Watersnake and Jarvis Marine are registered ® ® trademarks of Watersnake Distribution Pty. Ltd. © Watersnake Distribution Pty. Ltd. All Rights Reserved. Specifications are subject to change without notice.
