- Page 1 All manuals and user guides at all-guides.com SHADOW MK II BOW MOUNT ELECTRIC MOTOR OWNERS MANUAL...
- Page 2 All manuals and user guides at all-guides.com MODEL SWNG 44/48 (SHADOW MK II) VOLTAGE (V) MAX.THURST (LB) SHAFT LENGTH (IN) MIN AMP DRAW (A/H) MAX AMP DRAW (A/H) PROP 3 BLADE FOOT CONTROL MOUNTING BOW MOUNT CIRCUIT BREAKER REQUIRED BATTERY 12v DEEP CYCLE MARINE MIN.
- Page 3 All manuals and user guides at all-guides.com SHADOW MK II MODEL SWNG 65/54 (SHADOW MK II) VOLTAGE (V) MAX.THURST (LB) SHAFT LENGTH (IN) MIN AMP DRAW (A/H) MAX AMP DRAW (A/H) PROP 3 BLADE FOOT CONTROL MOUNTING BOW MOUNT CIRCUIT BREAKER...
-
Page 4: Pre-Installation Checklist
Watersnake motor • Select desired mounting location on boat • 12 v deep cycle marine battery (your Watersnake motor is not designed for use with car / truck / motorcycle type batteries) – for more information about appropriate batteries for your Watersnake motor, refer to page 10 •... -
Page 5: Please Read Before Use
All manuals and user guides at all-guides.com SHADOW MK II IMPORTANT PLEASE READ BEFORE USE. HOW TO STOW AND DEPLOY YOUR WATERSNAKE BOW MOUNT ELECTRIC MOTOR. DEPLOYING YOUR MOTOR To deploy the motor press down on the pedal (A) and... - Page 6 WATERSNAKE ELECTRIC MOTORS Congratulations and welcome to a world of silent motoring. Powerful yet silent, the Watersnake electric motors are built to suit all angling conditions. High quality materials, superior design and precision engineering make these motors longwearing and reliable.
- Page 7 All manuals and user guides at all-guides.com SHADOW MK II Head unit with integrated digital voltage meter Remote Control Fob ( Only available with remote model) Depth collar height adjustment Quick lock and release lever Mounting bracket Composite shaft Motor Assembly...
- Page 8 2: Align the propeller against the shear pin on the shaft (there is a groove on the back of the propeller which the shear pin needs to slot into) and then tighten the propeller nut securely. Shear Pin Propeller Propeller Shaft Propeller Watersnake...
-
Page 9: Electrical Connections
50 amps. Anderson plugs are a popular choice amongst many Watersnake motor owners and are readily available. A Watersnake circuit breaker is supplied and attached to the red power cable to protect the circuit boards of the motor. -
Page 10: Deep Cycle Batteries
DEEP CYCLE BATTERIES A 12 v deep cycle marine battery is required for normal operation and continued use of your Watersnake motor. 12 v deep cycle marine batteries are constructed using thicker plates and a denser active material. They are built to withstand repeated charge and recharge cycles. - Page 11 SHADOW MK II STOWING When your Watersnake motor is not in use always stow and store it properly. Press the quick locking and release lever and raise the motor, pulling towards the stern of your boat until it is secure on the locking cradles and locked into the horizontal (stowed) position.
- Page 12 4. Check to see if remote is now working. If not repeat step 3 again. Screw Screw 5. Put side plate back on bow mount bracket and secure with the two screws. Receiver Remote Button Control Remote Control Receiver Board Watersnake...
- Page 13 All manuals and user guides at all-guides.com SHADOW MK II FOOT PEDAL CONTROL SYSTEM The low profile foot pedal control is used to adjust direction and speed. A variable speed dial control is located at the right side of the foot control box.
-
Page 14: Maintenance
All manuals and user guides at all-guides.com MAINTENANCE Your Watersnake Electric Motor should provide many seasons of dependable service. However, like any tool, electric motors must be cared for. After each day of fi shing, the motor should be cleaned thoroughly. A light... - Page 15 If your boat is not stored under cover, it is recommended to remove your Watersnake motor and store separately under cover, out of direct sunlight and away from wet or damp areas. If you are not able to remove your Watersnake from the boat, we recommend covering your Watersnake with a weatherproof cover to protect the electronics.
- Page 16 No power / Reduced power NOTE – your Watersnake motor is fi tted with a tilt switch that prevents the motor from running unless it is in the deployed (vertical) position. • Check that battery connection has not been reversed (reversed polarity) •...
- Page 17 SHADOW MK II All manuals and user guides at all-guides.com Noise or vibration coming from motor Check that propeller is securely tightened and shear pin is in place Remove propeller and check for any build up of fi shing line / weed or any other debris •...
-
Page 18: Model Specifications
All manuals and user guides at all-guides.com MODEL SPECIFICATIONS CODE MOTOR DESCRIPTION THRUST VOLT AMPS WATTS SHAFT COLOUR BRACKET STEERING SPEEDS PROP 55301 Shadow MK II 44lb 11-44 132-528 1300 48" White Composite Foot Control Variable 3-Blade 55302 Shadow MK II... - Page 19 All manuals and user guides at all-guides.com SHADOW MK II MOTOR SELECTION GUIDE WATERSNAKE Transom Mount Suggested Transom Mount Measurement SHAFT LENGTH to Water Level Shaft Length GUIDE Up to 8” 24” Up to 10” 26” With your boat in the Up to 12”...
- Page 20 All manuals and user guides at all-guides.com SERVICING YOUR WATERSNAKE ELECTRIC MOTOR When it’s time for your Watersnake electric motor to be serviced, it is recommended you choose to use an Authorised Service Agent such as Anglers’ Central Service Centre to perform the service.
- Page 21 Watersnake Propeller Kits (Sold Separately) Watersnake Propeller kits contain a propeller, nut and shear pins. It is recommended you keep a spare propeller on your boat at all times. The Mini 2- Bladed Kit is suitable for the T-18 and T-24 motors. The 2-Bladed Propeller Kit is suitable for 28lb, 30lb and 34lb motors.
- Page 22 All manuals and user guides at all-guides.com Watersnake Shadow MK II Watersnake...
- Page 23 All manuals and user guides at all-guides.com www.watersnake.com.au...
- Page 24 All manuals and user guides at all-guides.com Watersnake Shadow MK II Watersnake...
- Page 25 All manuals and user guides at all-guides.com www.watersnake.com.au...
- Page 26 All manuals and user guides at all-guides.com SHADOW MK II NGRC REMOTE MOTOR PART 1 Watersnake...
- Page 27 All manuals and user guides at all-guides.com www.watersnake.com.au...
- Page 28 All manuals and user guides at all-guides.com SHADOW MK II NGRC REMOTE MOTOR PART 2 Watersnake...
- Page 29 All manuals and user guides at all-guides.com www.watersnake.com.au...
- Page 30 Watersnake offers an extensive range of PFDs for both adult’s and children. They come in a range of styles and sizes and they all meet the Australian and New Zealand safety standard. See your nearest Watersnake stockist for the full range or visit our website:www.watersnake.com.au for more information.
- Page 31 SHADOW MK II All manuals and user guides at all-guides.com NOTES: www.watersnake.com.au...
- Page 32 +0303 798 744 Watersnake and Jarvis Marine are registered ® ® trademarks of Watersnake Distribution Pty. Ltd. United Kingdom Masterline Walker +44 0 1684 299 000 © Watersnake Distribution Pty. Ltd. All Rights Reserved. Specifications are subject to change without notice.
