- Page 1 ADVANCE TRANSOM MOUNT BRUSHLESS ELECTRIC MOTOR OWNERS MANUAL...
- Page 2 12 volt deep cycle marine battery that will be appropriate for your situation. Please note 2 x 12v batteries need to be conneted together in series confi guration to form a 24v battery power supply. Watersnake...
- Page 3 Watersnake motor • Select desired mounting location on boat • Deep cycle marine battery (your Watersnake motor is not designed for use with car / truck / motorcycle type batteries) – for more information about appropriate batteries for your Watersnake motor, refer to page 10 •...
- Page 4 WATERSNAKE ELECTRIC MOTORS Congratulations and welcome to a world of silent motoring. Powerful yet silent, the Watersnake electric motors are built to suit all angling conditions. High quality materials, superior design and precision engineering make these motors longwearing and reliable.
- Page 5 Power indicator with extreme sport mode button Control box Extendable control handle featuring variable forward reverse speeds USB Charging port in head unit Multi adjustable depth collar Quick tilt device Heavy Duty Alloy Bracket Corrosion resistant shaft Weedless propeller Motor assembly unit www.watersnake.com.au...
- Page 6 2: Align the propeller against the shear pin on the shaft (there is a groove on the back of the propeller which the shear pin needs to slot into) and then tighten the propeller nut securely. Shear pin Propeller Propeller shaft Propeller Watersnake...
- Page 7 To adjust steering counter-force, simply loosen or tighten the counterforce bolt. The ideal setting is one where the counterforce bolt is just tight enough so that the boat will steer in the direction you are aiming without need for continual correction. Steering counter force adjustment Depth collar adjustment www.watersnake.com.au...
- Page 8 USB charging port. DIGITAL VOLTAGE METER PLEASE NOTE: Phone not included. SPEED CONTROL Shows the voltage going into the motor unit from the battery. Also features Forward and reverse an extreme sports mode button. variable speed settings. Watersnake...
- Page 9 50 amps. Anderson plugs are a popular choice amongst many Watersnake motor owners and are readily available. A Watersnake circuit breaker is highly recommended. Attach to the red power cable to protect the circuit boards of the motor.
- Page 10 Hold the motor shaft with one hand, loosen the depth collar adjustment screw and set the motor to the desired depth. Then retighten the adjusting screw on the depth collar securely. STOWING When your Watersnake motor is not in use always stow and store it properly. Watersnake...
- Page 11 ADVANCE BRUSHLESS MAINTENANCE Your Watersnake Electric Motor should provide many seasons of dependable service. However, like any tool, electric motors must be cared for. After each day of fi shing, the motor should be cleaned thoroughly. A light rinse with fresh water (do not direct a high pressure stream of water at the motor) and wash with warm soapy water to remove any remaining salt / debris particles should be completed.
- Page 12 If your boat is not stored under cover, it is recommended to remove your Watersnake motor and store separately under cover, out of direct sunlight and away from wet or damp areas. If you are not able to remove your Watersnake from the boat, we recommend covering your Watersnake with a weatherproof cover to protect the electronics.
- Page 13 TROUBELSHOOTING QUICK REFERENCE GUIDE A signifi cant number of issues can be caused by a disruption of power supplied to your Watersnake motor. Careful inspection of your deep cycle battery, wiring and fuse / circuit breaker set up should be completed before assuming that there is a fault with your motor.
- Page 14 MAINTENANCE Your Watersnake Electric Motor should provide many seasons of dependable service. However, like any tool, electric motors must be cared for. After each day of fishing, the motor should be cleaned thoroughly. If you have been fishing in saltwater, it is suggested that you wash the motor with warm fresh soapy water until all salt deposits are washed away.
- Page 15 A number of service videos are available on the Jarvis Walker Brands Youtube channel – search “Jarvis Walker Brands” from the Youtube search function. Please contact Jarvis Walker or your nearest service agent should issues persist. www.watersnake.com.au...
- Page 16 Alloy Transom Extend Hand Tiller Variable 3 Blade Model range and specifications are correct at time of printing. For new models not listed here find specifications at: www.jarvismarine.com.au MOTOR SELECTION GUIDE WATERSNAKE Transom Mount Suggested Transom Mount Measurement SHAFT LENGTH...
- Page 17 ADVANCE BRUSHLESS SERVICING YOUR WATERSNAKE ELECTRIC MOTOR When it’s time for your Watersnake electric motor to be serviced, it is recommended you choose to use an Authorised Service Agent such as Anglers’ Central Service Centre to perform the service. Watersnake electric motors are precision instruments that rely on exacting alignment of numerous components;...
- Page 18 55236 ADVANCE BRUSHLESS SWBL95 MOTOR PARTS LIST Watersnake...
- Page 19 55236 ADVANCE BRUSHLESS SWBL95 MAIN PARTS LIST www.watersnake.com.au...
- Page 20 55236 ADVANCE BRUSHLESS SWBL95 BRACKET PARTS LIST Watersnake...
- Page 21 55239 ADVANCE BRUSHLESS SWBL70 MOTOR PARTS LIST www.watersnake.com.au...
- Page 22 55239 ADVANCE BRUSHLESS SWBL70 MAIN PARTS LIST Watersnake...
- Page 23 55239 ADVANCE BRUSHLESS SWBL70 BRACKET PARTS LIST www.watersnake.com.au...
- Page 24 55267 ADVANCE BRUSHLESS SWS70 MOTOR PARTS LIST Watersnake...
- Page 25 55267 ADVANCE BRUSHLESS SWS70 MAIN PARTS LIST www.watersnake.com.au...
- Page 26 55267 ADVANCE BRUSHLESS SWS70 BRACKET PARTS LIST Watersnake...
- Page 27 Watersnake Propeller Kits (Sold Separately) Watersnake Propeller kits contain a propeller, nut and shear pins. It is recommended you keep a spare propeller on your boat at all times. The Mini 2- Bladed Kit is suitable for the T-18 and T-24 motors. The 2-Bladed Propeller Kit is suitable for 28lb, 30lb and 34lb motors.
- Page 28 Watersnake Trolling Motor Connectors Watersnake Motor Connector Plugs makes it very quick and simple to remove and replace your motor from the boat as well as providing a better connection to your power source. Available in a 12v plug. 55505...
- Page 29 Watersnake offers an extensive range of PFDs for both adult’s and children. They come in a range of styles and sizes and they all meet the Australian and New Zealand safety standard. See your nearest Watersnake stockist for the full range or visit our website:www.watersnake.com.au for more information.
- Page 30 NOTES: Watersnake...
- Page 31 NOTES: www.watersnake.com.au...
- Page 32 +0303 798 744 Watersnake ® and Jarvis Marine ® are registered trademarks of Watersnake Distribution Pty. Ltd. United Kingdom Masterline Walker +44 0 1684 299 000 © Watersnake Distribution Pty. Ltd. All Rights Reserved. Specifications are subject to change without notice.
