Performance Tool M658 Owner's Manual page 3

AIR SOURCE
Clean air of correct air pressure is recommended for the power
supply for this tool. A maximum of 90 PSI at the tool is recom-
mended for most air tools of this class. Check specifications sec-
tion for recommended pressure. (Depending on length of air hose
and other circumstances, air pressure at compressor may need to
be increased to 100 PSI to ensure 90 PSI at the tool.)
Water in the air hose and compressor tank contributes to reduced
performance and damage of the air tool. Drain the air tank and fil-
ters before each use and as necessary to keep the air supply dry.
Hose length over 25' causes loss in line pressure. Increase hose
I.D. or increase compressor pressure to compensate for the pres-
sure loss. Use an in-line pressure regulator with gauge if air inlet
pressure is critical.
LUBRICATION & MAINTENANCE
oil tool before each use. 4 to 5 drops of a good grade Air Tool Oil
placed in the air inlet is sufficient. Use proper air pressure and
CFM rating listed for this tool.
Drain water from hoses and compressor tank. Water in the
air supply line will cause gumming and loss of power. Clean the
air filter on the supply line and flush the tool with gum solvent or
a 50/50 mix of air tool oil and kerosene. It may be necessary to
disassemble the tool to properly clean and re-lubricate.
IMPORTANT SAFETY INFORMATION
WARNING!
ReAD, uNDeRstAND AND foLLoW ALL INstRuctIoNs AND
WARNINGs BefoRe oPeRAtING tHIs tooL. fAILuRe to Do
so MAY ResuLt IN PeRsoNAL INJuRY AND/oR PRoPeRtY
DAMAGe AND WILL VoID WARRANtY.
1. Use only 4 in. grinding wheels with a 5/8 in. arbor and depressed center.
Do Not use 4-1/2 in. oR LARGeR DIAMeteR GRINDING WHeeLs
oR You MAY cAuse DAMAGe to tooL oR INJuRY to useR.
2. Make sure sanding pad RPM rating matches Free Speed rating
of this tool.
3. Wear a dust mask while operating this tool. Read, follow and un-
derstand manufacturers instructions on paint, primer, paint preps,
glazing, body filler, etc. for additional respirator and ventilating
requirements.
4. Always use approved eye and ear protection when using air powered
tools. If raising dust/debris, wear a suitable mask. Do not wear loose
clothing or jewelry.
5. Always operate tool a safe distance from yourself and others in the
work area. Keep footing and balance at all times.
6. Make sure work piece is secure to allow safe operation of the tool with
both hands. Do not hold the work piece in your hand, lap or against
any part of your body.
7. Make sure trigger is in the "off" position before connecting or discon-
necting the tool from air source. Disconnect tool from air source
before changing accessories, performing service and when not in use.
8. Follow air source manufacturer's directions for connection of regula-
tors, filters and other accessories to air source. Do not install quick
couplers directly at tool air inlet. This causes inlet failure due to
excess weight and vibration. Use a whip hose between tool and quick
couplers.
9. Do Not oVeRLoAD! Do not force tool. Match tool capacity to work
load requirement. Use tool within its rated capacity and only for its
designated purpose. Overloading air tools will cause premature wear
and/or permanent damage of internal and external drive parts and will
void warranty.
10. Inspect hoses and fittings for wear and damage prior to using tool.
Do not carry or drag tool by the air hose. Keep air hose free from
obstruction, twisting and binding.
