4-1/2 IN. ANGLE GRINDER Item Number W50044 OWNER’S MANUAL WARNING It is the owner and/or operators’ responsibility to study all WARNINGS, operating, and maintenance instructions contained on the product label and instruction manual prior to operation of this product. The owner/operator shall retain product instructions for future reference.
SAFETY GUIDELINES / DEFINITIONS This instruction manual is intended for your benefit. Please read and follow the safety, installation, maintenance and troubleshooting steps described within to ensure your safety and satisfaction. The contents of this instruction manual are based upon the latest product information available at the time of publication.
IMPORTANT SAFETY INFORMATION 6. Dress properly. Do not wear loose clothing or jewelry. a cord suitable for outdoor use reduces the risk of Keep your hair, clothing and gloves away from mov- electric shock. ing parts. Loose clothes, jewelry or long hair can be 17.
Page 4
49. Maintain labels and nameplates on the Angle Grinder. These carry important information. If parts will become live and could seriously shock unreadable or missing, contact Performance Tool® the user. for a replacement. 39. When using the Angle Grinder, always maintain a firm grip on the tool.
GROUNDING WARNING: Improperly connecting the grounding wire can result in the risk of electric shock. Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. Do not modify the power cord plug provided with the tool. Never remove the grounding prong from the plug.
GROUNDING RECOMMENDED SIZES OF EXTENSTION CORDS FOR 120 VOLT AC 60 HZ TOOLS CURRENT RATINGS IN AMPS CONDUCTOR SIZE IN A.W.G. MORE THAN LESS THAN 10 ft. 25 ft. 50 ft. 100 ft. SYMBOL DEFINITIONS IMPORTANT: Some of the following symbols may be used on your tool. Please study them and learn their meaning.
CONTROLS AND COMPONENTS 1. ON/OFF Switch with lock-on feature 2. Protective Guard 3. Grinding Wheel 4. Spindle Lock Button 5. Side Handle 6. Power Cord ASSEMBLY ATTACHING AUXILIARY HANDLE This tool comes with an auxiliary handle which can be attached to different sides of the Angle Grinder, depending on the preference of the operator.
ASSEMBLY ATTACHING GRINDING WHEEL OR CUTTING DISC 1. Unplug the grinder. 6. Fit the two prongs of the wrench into the holes in the outer flange nut. 2. Turn the tool upside down. 7. Depress the spindle lock button and firmly 3.
OPERATION USING THE ANGLE GRINDER NOTE For best tool control, material re- This angle grinder is designed to accept only 4-1/2" abrasive discs with a 5/8" bore. moval and minimal loading, keep the Check to ensure that any discs used on angle between the disc and the work this machine are rated for the 12,000 /min surface at approximately 30°...
After 90 days and up to one year from date of purchase, PERFORMANCE TOOL® will replace at no charge any parts which our examination shall disclose to be defective and under warranty.
