8" Bench Grinder
Stock Number W50058
¤
C
US
E154499
LISTED
TABLE OF CONTENTS
Safety Instructions .................................................................2
Bench Grinder Safety .............................................................3
Electrical Requirements .........................................................3
Replacement Parts List ..........................................................4
Bench Grinder Assembly .......................................................4
Maintenance ............................................................................5
Warranty ..................................................................................6
PROTECT YOUR EYES.
The operation of any power tool can
result in foreign objects being thrown
into the eyes which can result in severe
eye damage. Always wear eye protection
during power tool operation.
OWNER'S MANUAL
PLEASE WEAR
SAFETY GLASSES
FORESIGHT IS BETTER
THAN NO SIGHT
SPECIFICATIONS
Maximum HP developed ...............3/4
Volts ....................................................115
Hertz ...................................................60
RPM ......................................................3450 (no load speed)
GRINDING WHEEL SIZE ................8" X 1" X 5/8"
GRINDING WHEEL GRIT ...............36 & 60
LEFT & RIGHT TOOL RESTS
LEFT & RIGHT EYE SHIELDS AND ASSEMBLIES
LEFT & RIGHT SPARK GUARDS
To avoid electrical shock to yourself and
damage to the bench grinder, use proper
circuit protection.
The Bench grinder is factory wired for 115V,
60 Hz operation. Connect to a 115V, 15 amp
branch circuit and use a 15 amp time delay
fuse or curcuit breaker. The electrical circuit
can not have any wire size less than #12. To
avoid shock or fire, replace power cord
immediately if it is damaged in any way.
Advertisement
Related Manuals for Performance Tool W50058
Summary of Contents for Performance Tool W50058
-
Page 1: Table Of Contents
8" Bench Grinder Stock Number W50058 OWNER’S MANUAL ¤ E154499 LISTED TABLE OF CONTENTS SPECIFICATIONS Maximum HP developed ....3/4 Safety Instructions ..............2 Volts ............115 Bench Grinder Safety .............3 Hertz ...........60 Electrical Requirements ............3 RPM ............3450 (no load speed) Replacement Parts List ............4 GRINDING WHEEL SIZE ....8"... -
Page 2: Safety Instructions
SAFETY INFORMATION Carefully read through the entire owner’s manual before operating WARNING: When using electrical tools, machines or your bench grinder. Keep manual with important records for safety equipment, basic safety precautions should always be instructions, operating procedures and warranty. followed to minimize the risk of fire, electrical shock or personal injury to yourself and others. -
Page 3: Bench Grinder Safety
ELECTRICAL REQUIREMENTS CONNECTING TOOL TO POWER SOURCE OUTLET Fig. A This machine source must be grounded while in use to protect the operator from electric shock. In the event of a malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. -
Page 4: Replacement Parts List
BENCH GRINDER ASSEMBLY LOOSE PARTS CONTENTS: INSTALLING TOOL RESTS Fig. 1 Remove the tool rests from the Tool Rest ................2 each package and install them to the Mounting rods ..............2 each wheel guards as shown in Figure 1. Eye Shields ................ -
Page 5: Maintenance
MAINTENANCE WARNING: For your own safety, turn switch “OFF” and remove CLEAN your bench grinder only after the power switch is in the plug from power source outlet before adjusting and maintaining “OFF” position and unplugged from the power source. Turn the your bench grinder. -
Page 6: Warranty
PERFORMANCE TOOL shall not be liable for consequential, incidental or special damages resulting from or in any manner related to any product, or to the design, use, or any inability to use the product.
