6 in. Bench Grinder
with Worklight
W50001
SPECIFICATIONS
Maximum HP developed
Volts
Hertz
RPM
GRINDING WHEEL SIZE
GRINDING WHEEL GRIT
LEFT & RIGHT TOOL RESTS
LEFT & RIGHT EYE SHIELDS AND ASSEMBLIES
LEFT & RIGHT SPARK GUARDS
PROTECT YOUR EYES.
The operation of any power tool can
result in foreign objects being thrown
into the eyes which can result in
severe eye damage. Always wear eye
protection during power tool operation.
Table of Contents
Safety Instructions_________________________________________2
Bench Grinder Safety_______________________________________3
Electrical Requirements_____________________________________3
Replacement Parts List______________________________________4
Bench Grinder Assembly ____________________________________4
Maintenance_______________________________________________5
Warranty__________________________________________________6
1/2
115
60
345 0(no load speed)
6 in. X 3/4 in. X 1/2 in.
36, 60
PLEASE WEAR
SAFETY GLASSES
FORESIGHT IS BETTER
THAN NO SIGHT
OWNER'S MANUAL
SAVE THIS MANUAL
To avoid electrical shock to yourself and
damage to the bench grinder, use proper
circuit protection.
The Bench grinder is factory wired for 115V,
60 Hz operation. Connect to a 115V, 15 amp
branch circuit and use a 15 amp time delay
fuse or circuit breaker. The electrical circuit
can not have any wire size less than #12. To
avoid shock or fire, replace power cord
immediately if it is damaged in any way.
Advertisement
Table of Contents
Related Manuals for Performance Tool W50001
Summary of Contents for Performance Tool W50001
-
Page 1: Table Of Contents
6 in. Bench Grinder with Worklight OWNER’S MANUAL W50001 SAVE THIS MANUAL Table of Contents Safety Instructions_________________________________________2 Bench Grinder Safety_______________________________________3 Electrical Requirements_____________________________________3 Replacement Parts List______________________________________4 Bench Grinder Assembly ____________________________________4 Maintenance_______________________________________________5 Warranty__________________________________________________6 SPECIFICATIONS Maximum HP developed Volts Hertz 345 0(no load speed) GRINDING WHEEL SIZE 6 in. -
