Step 1
Install the rear wheel
Installing the other side wheel is the same as step 1.
Step 2
Install front wheel
Gasket
Nut
Gasket
As shown in the arrow,insert the shaft into the front fork, pass through the gasket X2, the front
wheel, the gasket X2 and the nut (as shown in the figure), and tighten the nut clockwise
INSTALLATION STEPS
As shown in the arrow, insert the shaft frame into
the car body, pass the gasket, rear wheel, gasket
and nut (as shown in Figure 1) through the axle, and
tighten the nut clockwise (as shown in Figure 2).
Rear wheel
Gasket
A rear axle
Nut
Gasket
Gasket
Nut
Rear wheel
Gasket
Gasket
Gasket
Nut
