Befaco Chopping Kinky V1 Assembly Manual

Advertisement

Quick Links

CHOPPING KINKY V1 - ASSEMBLY GUIDE – Rev. Oct 2022
THANKS FOR CHOOSING ONE OF OUR KITS!
This manual has been written taking into account the common issues that we often find people experience in our
workshops. The order in which the components are placed on the board is meant to make assembly as easy as possible.
Some steps are not obvious, so even if you're an experienced DIYer please read the steps thoroughly before starting. You
will be soldering both boards at the same time.
If this is your first project, please read this article before you start assembling the kit:
www.befaco.org/howto/
ENJOY!
RESISTORS
Color code can be difficult to identify, we strongly recommend to use a multimeter.
Qty
Value
Code
44
100k
Brown, black, black, orange, brown
6
1M
Brown, black, black, yellow, brown
4
560R
Green, Blue, black, black, brown
4
1k
Brown, black, black, brown, brown
4
10k
Brown, black, black, red, brown
3
43k
Yellow, orange, black, red, Brown
2
20k
Red, black, black, red, brown
2
30k
Orange, black, black, red, brown
2
47k
Yellow, violet, black, red, brown
2
82K
Grey, red, black, red, brown
2
120k
Brown, red, black, orange, brown
2
200k
Red, black, black, orange, brown
2
300k
Orange, black, black, orange, brown
2
10M
Brown, black, black, green, brown
1
1k8
Brown, gray, black, brown, brown
1
4k7
Yellow, violet, black, brown, brown
1
33k
Orange, orange, black, red, brown
1
150k
Brown, green, black, orange, Brown
Name on PCB
R1, R2, R11, R12, R19, R20, R21, R22, R23, R24, R25, R27,
R28, R29, R30, R31, R32, R33, R34, R35, R36, R37, R38,
R40, R41, R42, R48, R101, R106, R108, R111, R115, R118,
R119, R120, R121, R122, R123, R124, R125, R126, R127,
R128, R129
R13, R14, R46, R50, R102, R110
R4, R7, R15, R18
R45, R49, R51, R130
R39, R43, R105, R107
R17, R116, R117
R9, R10
R5, R6
R16, R52
R103, R113
R104, R114
R3, R8
R44, R47
R100, R131
R112
R109
R53
R26
1

Advertisement

loading

Summary of Contents for Befaco Chopping Kinky V1

  • Page 1 CHOPPING KINKY V1 - ASSEMBLY GUIDE – Rev. Oct 2022 THANKS FOR CHOOSING ONE OF OUR KITS! This manual has been written taking into account the common issues that we often find people experience in our workshops. The order in which the components are placed on the board is meant to make assembly as easy as possible.
  • Page 2 CHOPPING KINKY V1 - ASSEMBLY GUIDE – Rev. Oct 2022 DIODES Solder the diodes observing their polarity. The black or white line on the diode (which indicates the cathode – the negative side) must match with the white line on the diode symbol on the PCB silkscreen.
  • Page 3: Electrolytic Capacitors

    CHOPPING KINKY V1 - ASSEMBLY GUIDE – Rev. Oct 2022 CAPACITORS Identifying capacitors can be quite tricky. Codes stated are indicative, please take a look at this guide for help identifying capacitors: http://www.wikihow.com/Read-a-Capacitor Value Code Name on PCB 100n C1, C2,C102, C103, C3, C4, C5, C6, C7, C8, C9, C10, C11, C12, C16, C17, C18, C19, C104,...
  • Page 4: Power Connector

    CHOPPING KINKY V1 - ASSEMBLY GUIDE – Rev. Oct 2022 TRIMMERS Solder the trimmers to the PCB where it is indicated by the silkscreen. CAL_A1, CAL_A2, CAL_B1, CAL_B2 POWER CONNECTOR Solder the power connector at “POWER1”, ensuring it is facing out from the edge of the PCB. The small arrow on the connectors must be on the side with the thick white line.
  • Page 5: Front Panel

    CHOPPING KINKY V1 - ASSEMBLY GUIDE – Rev. Oct 2022 LEDs Place the LEDs onto the PCB minding, their polarity, but don't solder them until the front panel is in place. This is the only way to solder them in the right position.
  • Page 6 CHOPPING KINKY V1 - ASSEMBLY GUIDE – Rev. Oct 2022 CALIBRATION We are now going to calibrate the VCA offsets and the internal analog switch to ensure the noise floor is at a minimum. A: VCA OFFSET 1) Turn both channels’ waveform level knobs so that they are at zero.
  • Page 7 CHOPPING KINKY V1 - ASSEMBLY GUIDE – Rev. Oct 2022...
  • Page 8 CHOPPING KINKY V1 - ASSEMBLY GUIDE – Rev. Oct 2022...
