FXBOY V1 - ASSEMBLY GUIDE – Rev. Sepl. 2023
THANKS FOR CHOOSING ONE OF OUR KITS!
This manual has been written taking into account the common issues that we often find people experience in our
workshops. The order in which the components are placed on the board is meant to make assembly as easy as possible.
Some steps are not obvious, so even if you're an experienced DIYer please read the steps thoroughly before starting.
If this is your first project, please read this article before you start assembling the kit:
www.befaco.org/howto/
You will be soldering both boards at the same time. Keeping them in the panel together might help you through the build.
Check last pages of the Build for PCB pics to help you identify components.
HAVE FUN!
RESISTORS
Color code can be difficult to identify, we strongly recommend to use a multimeter.
Qty
Value
Code
66
100k
Brown, black, black, orange, brown
8
18k
Brown, gray, black, red, brown
6
20k
Red, black, black, red, brown
4
150k
Brown, green, black, orange, brown
4
68k
Blue, gray, black, red, brown
4
47k
Yellow, violet, black, red, brown
3
200k
Red, black, black, orange, brown
3
1k
Brown, black, black, brown, brown
2
56k
Green, blue, black, red, brown
2
33k
Orange, orange, black, red, brown
2
16k
Brown, blue, black, red, brown
2
2k7
Red, violet, black, brown, brown
1
820K
Gray, red, black, orange, brown
1
330k
Orange, orange, black, orange, brown
1
300k
Orange, black, black, orange, brown
1
220k
Red, red, black, orange, brown
1
22k
Red, red, black, red, brown
1
3k3
Orange, orange, black, brown, brown
Name on PCB
R1, R2, R6, R7, R9, R10, R11, R13, R14, R15, R16, R21,
R22, R23, R24, R25, R28, R29, R30, R31, R34, R39, R40,
R41, R42, R43, R44, R45, R46, R47, R48, R49, R50, R51,
R52, R53, R55, R56, R61, R64, R67, R68, R69, R70, R72,
R74, R76, R78, R81, R83, R84, R85, R88, R93, R94, R95,
R97, R98, R99, R100, R102, R103, R105, R106, R107,
R108
R12, R27, R35, R36, R37, R38, R101, R104
R4, R17, R109, R110, R111, R112
R63, R89, R91, R92
R58, R60, R62, R80
R33, R57, R87, R96
R26, R32, R71
R18, R19, R54
R3, R5
R59, R66
R75, R82
R77, R79
R20
R90
R73
R86
R65
R8
1

Advertisement

loading

Summary of Contents for Befaco FXBOY V1

  • Page 1 FXBOY V1 - ASSEMBLY GUIDE – Rev. Sepl. 2023 THANKS FOR CHOOSING ONE OF OUR KITS! This manual has been written taking into account the common issues that we often find people experience in our workshops. The order in which the components are placed on the board is meant to make assembly as easy as possible.
  • Page 2 FXBOY V1 - ASSEMBLY GUIDE – Rev. Sepl. 2023 DIODES Solder the diodes observing their polarity. The black or white line on the diode must match with the white line on the diode symbol on the PCB silkscreen. Value Name on PCB...
  • Page 3 FXBOY V1 - ASSEMBLY GUIDE – Rev. Sepl. 2023 ELECTROLYTIC CAPACITORS Values are written on the side of the capacitor. Mind their polarity (The long leg of the capacitor is the positive (+)). Value Code Name on PCB 10uF 10uF...
  • Page 4 FXBOY V1 - ASSEMBLY GUIDE – Rev. Sepl. 2023 Place the ICs in their respective sockets taking note of their orientation – the notch or dot on the top of the IC must match that of the socket and silkscreen.
  • Page 5: Front Panel

    FXBOY V1 - ASSEMBLY GUIDE – Rev. Sepl. 2023 SWITCHES Place the switches in their right places. Don't solder them yet! Type Name on PCB Mini. One circuits two position SWPP Mini. 2 circuits two position MINI-JACKS Place the mini-jacks on the PCB ensuring they are on the side with the silkscreen. Don't solder them until the front panel is in place with all nuts screwed to it.
  • Page 6 FXBOY V1 - ASSEMBLY GUIDE – Rev. Sepl. 2023...
  • Page 7 FXBOY V1 - ASSEMBLY GUIDE – Rev. Sepl. 2023...
  • Page 8 FXBOY V1 - ASSEMBLY GUIDE – Rev. Sepl. 2023...
  • Page 9 FXBOY V1 - ASSEMBLY GUIDE – Rev. Sepl. 2023...
