Linear Technology DC1817B Demo Manual page 6

DEMO MANUAL DC1817B
parts List
ITEM QTY REFERENCE
40 1 T1
41 1 U1
42 1 V1
Additional Circuit Components
1 0 R23
Hardware/Components (For Demo Board Only)
1 2 J1, J2
2 4 MH1 TO MH4
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
XFMR, FLYBACK
IC, ISOLATED FLYBACK CONTROLLER
VARISTOR, 320V RMS 13.5MM RADIAL
RES, 0805, OPTION
TERMINAL BLOCK, 2 POSITION
STAND-OFF, NYLON, 0.25"
MANUFACTURER/PART NUMBER
WÜRTH ELECTONIK, 750811248
LINEAR TECHNOLOGY LT3798EMSE#PBF
VISHAY VDRS10P320BSE
OPTION
WEIDMULLER, 1715250000
KEYSTONE, 8831 (SNAP-ON)
dc1817bfa
