at a standstill. The On/Off switch is blocked when
the slide switch is in centre position.

On/Off switch (4)

Infinitely variable speed control is possible with the
On/Off switch. The further you press the switch, the
higher the speed of the battery-powered
drill/screwdriver.
Changing over from 1st gear to 2nd
gear (7)
You can work at a higher or lower speed depending
on the position of the selector switch. To avoid
damaging the gear unit you should only change over
gears when the tool has stopped.
Screwdriving
We recommend using self-centering screws (e.g.
Torx screws, recessed head screws) designed for
reliable working. Be sure to use a bit that matches
the screw in shape and size. Set the torque, as
described elsewhere in these operating instructions,
to suit the size of screw.

Technical data

Voltage supply
Speed 0-350/0-900 rpm
Torque
Forward and reverse rotation
Chuck clamping width
Battery charging voltage
Battery charging current
Mains voltage for charger 230 V ~ 50 Hz
Sound pressure level LPA:
Sound power level LWA:
–
Vibration
a
w
Weight
03.04.2006 6:39 Uhr

Ordering replacement parts

Please quote the following data when ordering
replacement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
18 V =
16 levels
yes
1 - 10 mm
18 V =
2.5 A
69 dB(A)
80 dB(A)
< 2.5 m/s 2
1.75 kg
