Sunell Security SN-TPC2553DRT-F User Manual

Bi-spectrum network camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Bi-spectrum
Network Camera
User Manual
Issue: V 1.0
Data: 2023-05-24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SN-TPC2553DRT-F and is the answer not in the manual?

Questions and answers

Related Manuals for Sunell Security SN-TPC2553DRT-F

Summary of Contents for Sunell Security SN-TPC2553DRT-F

  • Page 1 Bi-spectrum Network Camera User Manual Issue: V 1.0 Data: 2023-05-24...

  • Page 3: Precautions

    Bi-spectrum network camera User Manual Precautions Precautions Precautions Fully understand this document before using this device, and strictly observe rules in this document when using this device. If you install this device in public places, provide the tip "You have entered the area of electronic surveillance" in an eye-catching place. Failure to correctly use electrical products may cause fire and severe injuries.
  • Page 4 Bi-spectrum network camera Precautions User Manual ⚫ Strictly conform to local electrical safety standards and use power adapters which are marked with the LPS standard when installing and using this device. Otherwise, this device may be damaged. ⚫ Use accessories delivered with this device. The voltage must meet input voltage requirements for this device.
  • Page 5 Bi-spectrum network camera User Manual Precautions the device, and then dry it again. Pay special attention to the front window of the thermal imaging camera because this is precision optics. If the front window has water spots, use a clean and soft cloth moistened with water to wipe it. If the front window needs further cleaning, use a soft cloth dampened with isopropyl alcohol or detergent.

  • Page 6: Table Of Contents

    Bi-spectrum network camera Contents User Manual Contents Precautions ........................I Contents ........................IV 1 Product Overview ....................7 1.1 About Product ......................... 7 1.2 Device Dimension ......................7 1.3 Installation ........................9 1.4 Cable Connection ......................11 2 Quick Configuration ..................... 13 2.1 Login and Logout ......................
  • Page 7 Bi-spectrum network camera User Manual Contents 4.5 Exposure ........................54 4.6 WB ..........................56 4.7 DayNight ........................58 4.8 Noise Reduction ......................61 4.9 Enhance Image ......................62 5 Thermal Channel Image Settings ............... 65 5.1 Accessing the Image Settings Interface ................ 65 5.2 Mode ..........................
  • Page 8 Bi-spectrum network camera Contents User Manual 10.2.1 Base Stream ....................112 10.2.2 ROI ........................ 113 10.2.3 Snapshot ......................114 10.3 Device ........................115 10.4 External Device ......................115 10.5 Privacy Masking ......................117 10.6 Network Service ......................117 10.6.1 QOS ......................117 10.7 Privacy Manager .......................

  • Page 9: Product Overview

    Bi-spectrum network camera User Manual Product Overview Product Overview 1.1 About Product ⚫ The Bi-spectrum network camera is integrated with the thermal imaging and temperature measuring, visible fusion, core image intelligent analysis, etc. ⚫ Unique double registration mechanism, visible light and thermal imaging is reflecting the same scene.
  • Page 10 Bi-spectrum network camera Product Overview User Manual Figure 1-1 Dimensions (unit: mm) 273~~303 Adjustable Issue V 1.0（2023-05-24）...

  • Page 11: Installation

    Bi-spectrum network camera User Manual Product Overview Reset : Reset button, long press for 5s to restore to factory settings. Power : If the power is normal, the red light is on. NET: Network indicator, if the data is transiting, the green light is flash. SD: SD card indicator, if the card is plugged, the blue light is on.
  • Page 12 Bi-spectrum network camera Product Overview User Manual Figure 1-2 Adjust Direction Screw 1 Step 3 Install the camera on the ceiling or wall and fixe the screws as shown in Figure 1-3. Figure 1-3 Fix Camera Step 4 Connect the multi-connector cable and monitor, loosen the screw 2 to adjust the position so that the camera face the monitored area, as shown in Figure 1-4.

  • Page 13: Cable Connection

    Bi-spectrum network camera User Manual Product Overview Figure 1-4 Adjust Image 1.4 Cable Connection The different models may have different cables, please refer to actual product. Figure 1-5 Multi-connector Combination Cables Issue V 1.0（2023-05-24）...
  • Page 14 Bi-spectrum network camera Product Overview User Manual Table 1-1 Multi-connector Combination Cables Core of Cable Functions Network interface Connect to the standard Ethernet cable. Support PoE power supply. ALARM1 Alarm in/ alarm out 1 Brown: alarm OUT COM 1 Blue: alarm OUT 1 White: alarm IN COM 1 Green: alarm IN 1 ALARM 2...

  • Page 15: Quick Configuration

    Bi-spectrum network camera User Manual Quick Configuration Quick Configuration 2.1 Login and Logout To access the web interface through Edge browser (IE Mode); Otherwise, some functions may be unavailable. Login system Step 1 Open the Microsoft Edge, enter the IP address of IP camera (default value: 192.168.0.121) in the address box, and press Enter.

  • Page 16: Homepage Layout

    Bi-spectrum network camera Quick Configuration User Manual ⚫ Access the web at Edge browser which the mode should switch to Reload in Internet Explorer mode. At browser “Setting > Default browser” page, Let Internet Explorer open sites in Microsoft Edge choose “Always (Recommenced)”; Allow sites to be reloaded in Internet Explorer mode (IE mode) choose “Allow”.
  • Page 17 Bi-spectrum network camera User Manual Quick Configuration logout of the system. Figure 2-3 is shown the homepage layout. Table 2-1 lists the elements on the homepage layout. Figure 2-3 Homepage Layout Table 2-1 Elements on the Homepage Element Description Real-time Real-time videos are played in this area.

  • Page 18: Changing The Password

    Bi-spectrum network camera Quick Configuration User Manual Element Description : Play / pause. : Switch the mode. : Audio. : Interphone. : Sensor, or click right mouse button, more details please refer to chapter 4 and 5 : Snapshot. : Record video to local storage. : Intelligent analysis, Choose the stream to stream 2, click to open the intelligent analysis, it will show target information and video stream draw line after you have...

  • Page 19: Browse Video

    Bi-spectrum network camera User Manual Quick Configuration Figure 2-4 Change Password Dialog Box ⚫ The change password page will be displayed if you don’t change the default password when you login the system for the first time. Step 2 Input the old password, new password, and confirm password. Step 3 Click OK.
  • Page 20 Bi-spectrum network camera Quick Configuration User Manual In the display dialog box, click Add, as shown in Figure 2-5. Figure 2-5 Adding a Trusted Site Step 2 In Microsoft Edge, choose Control Panel > Internet Options > Security > Customer level, and set Download unsigned ActiveX control and initialize and script ActiveX controls not marked as safe for scripting under ActiveX controls and plug-ins to Enable, as shown in Figure 2-6.

  • Page 21: Install Plugins

    Bi-spectrum network camera User Manual Quick Configuration Figure 2-6 Configuring ActiveX Control and Plug-ins Step 3 Download and install the player control as prompted. ⚫ The login page is displayed when the control is loaded. ⚫ If you can view the live video immediately, you can ignore the steps of adding trust site. 2.4.1 Install Plugins You will be prompted with a message “Download and install the new plugin”...

  • Page 22: People Counting

    Bi-spectrum network camera Quick Configuration User Manual ⚫ Channel switch, click the live video, the red frame means the chosen channel. ⚫ During installing plugins, you need to close the browser, finish the installation, login the device again. ----End 2.5 People Counting At People Counting interface, you can view the people counting data throughout setting query condition (choose the detail time at date’s pop up window).

  • Page 23: Setting Local Network Parameters

    Bi-spectrum network camera User Manual Quick Configuration 2.6 Setting Local Network Parameters Description Local network parameters include: ⚫ IP protocol ⚫ IP address ⚫ Subnet mask ⚫ Default gateway ⚫ Dynamic Host Configuration Protocol (DHCP) ⚫ Preferred Domain Name System (DNS) server ⚫...
  • Page 24 Bi-spectrum network camera Quick Configuration User Manual Step 2 Set the parameters according to Table 2-2. Table 2-2 Local Network Parameters Parameter Description Setting IP Protocol IPv4 is the IP protocol that uses [Setting method] an address length of 32 bits. Select a value from the drop-down list box.
  • Page 25 Bi-spectrum network camera User Manual Quick Configuration Parameter Description Setting Preferred DNS IP address of a DNS server. [Setting method] Server Enter a value manually. [Default value] 192.168.0.1 Alternate DNS IP address of a domain server. [Setting method] Server If the preferred DNS server is Enter a value manually.

  • Page 26: Configuring Thermal

    Bi-spectrum network camera Configuring Thermal User Manual Configuring Thermal 3.1 Temperature Parameters Temperature parameters include temperature unit, ambient type, ambient temperature, cavity temperature, correctional coefficient, area temperature display mode, area temperature type, measure mode, area alarm interval and so on. Operation Procedure Step 1 Choose Configuration >Thermal >Temperature Parameters.
  • Page 27 Bi-spectrum network camera User Manual Configuring Thermal Figure 3-1 Temperature Parameters Interface Step 2 Set the parameters according to Table 3-1. Table 3-1 Temperature Parameters Parameter Description Setting Temperature Unit Celsius and Fahrenheit [Setting method] temperature units are available. Select a value from the drop-down list box.
  • Page 28 Bi-spectrum network camera Configuring Thermal User Manual Parameter Description Setting Length units Meters and feet length units are [Setting method] available. Select a value from the drop-down list box. [Default value] Meters Cavity The cavity temperature of Temperature camera. Correction Correction coefficient is refer to [Setting method] Coefficient...
  • Page 29 Bi-spectrum network camera User Manual Configuring Thermal Parameter Description Setting Font size There are there font size can be [Setting method] chosen, small/mid/big Enable or disable [Default value] Area Temperature There are three types of area [Setting method] Type temperature. Select a value from the drop-down list box.
  • Page 30 Bi-spectrum network camera Configuring Thermal User Manual Parameter Description Setting Prevent Open, if temperature of the [Setting method] Overheating testing area is too high, you can Select a value from the enable it to prevent over heat drop-down list box. function.
  • Page 31 Bi-spectrum network camera User Manual Configuring Thermal Parameter Description Setting Greater Prominent Enable that, the image will [Setting method] show the setting color if the Enter a value manually. temperature is higher than set Choose one color to value. show. Section Prominent Enable that, the image will [Setting method]...

  • Page 32: Ambient Temperature

    Bi-spectrum network camera Configuring Thermal User Manual 3.2 Ambient Temperature Figure 3-3 Ambient Temperature Table 3-3 Parameter of Ambient Temperature Parameter Description Setting Ambient Environment temperature of [Setting method] Temperature camera. Enter the temperature of ambient environment. [Default value] Cavity Temperature Set the ambient temperature, click “Apply”, click “Refresh”...
  • Page 33 Bi-spectrum network camera User Manual Configuring Thermal Figure 3-4 Temperature Area and Alarm Configuration Step 2 Set the parameters according to Table 3-4. Table 3-4 Temperature Area and Alarm Configuration Parameter Description Setting Channel Channel 1 is visible channel. [Setting method] Channel 2 is thermal channel.
  • Page 34 Bi-spectrum network camera Configuring Thermal User Manual Parameter Description Setting Measure Mode Set at temperature parameter interface. Enable Tick the ID to enable the area [Setting method] measuring. Tick Name Area name of temperature area. [Setting method] Enter a value manually. Type Type of temperature area.
  • Page 35 Bi-spectrum network camera User Manual Configuring Thermal Parameter Description Setting Emission Rate The emission rate is the [Setting method] capability of an object to emit or Enter a value manually. absorb energy. [Default value] The emission rate should be set 0.95 only when the target is special material.
  • Page 36 Bi-spectrum network camera Configuring Thermal User Manual Parameter Description Setting Group ID The ID can be chosen into one of [Setting method] six groups, or no group. The Select a value from the group will be alarm following as drop-down list box. the next rules: A=The highest temperature of groups (the highest temperature...
  • Page 37 Bi-spectrum network camera User Manual Configuring Thermal Figure 3-5 Temperature Area Setting Interface 3. Click Apply, the message “Apply success” is displayed, the temperature area is set successfully. ID 0 is the full screen; The area cannot be changed. : the lowest temperature of the full screen. :the highest temperature of the full screen.

  • Page 38: Privacy Zone Masking

    Bi-spectrum network camera Configuring Thermal User Manual ----End 3.4 Privacy Zone Masking Privacy zone masking is meaning that the camera will do not detect the temperature of that area. The shield areas can be set up to eight areas. Operation Procedure Step 1 Choose Configuration >...

  • Page 39: Schedule Linkage

    Bi-spectrum network camera User Manual Configuring Thermal 3.5 Schedule Linkage Operation Procedure Step 1 Choose Configuration >Thermal > Schedule Linkage. The Schedule Linkage page is displayed, as shown in Figure 3-7. Figure 3-7 Schedule Linkage Step 2 Tick the output channel. Step 3 Enable wanted linkage: “Alarm Record”, “SMTP”,”FTP upload”, audible alarm, flashlight alarm.
  • Page 40 Bi-spectrum network camera Configuring Thermal User Manual ⚫ Alarm output: Users should connect the external alarm device (such as siren) to alarm output cables. The parameter can be set at “ Configuration > Alarm > Alarm Output” interface, as shown in Figure 3-8.
  • Page 41 Bi-spectrum network camera User Manual Configuring Thermal Parameter Description Setting Alarm Output When the device receives I/O alarm [Setting method] Mode signals, the device sends the alarm Select a value from the information to an external alarm device drop-down list box. in the mode specified by this parameter.
  • Page 42 Bi-spectrum network camera Configuring Thermal User Manual ⚫ Alarm Record: Users insert the SD card in camera. The recording time is set at “ Configuration > Device Record > Record Policy” interface. SMTP: At “ Configuration > Network > SMTP” interface, users should set the parameters of ⚫...
  • Page 43 Bi-spectrum network camera User Manual Configuring Thermal Parameter Description Setting Recipient_ (Mandatory) Email address of [Setting method] recipient 1. Enter a value manually. mail_Addre ss 1 Recipient_ (Optional) Email address of recipient 2. mail_Addre ss 2 Recipient_ (Optional) Email address of recipient 3.
  • Page 44 Bi-spectrum network camera Configuring Thermal User Manual FTP Upload: At “ Configuration > Network > FTP Upload” interface, users should set the ⚫ parameters of FTP upload in advance, as shown in Figure 3-10. Figure 3-10 FTP Upload Table 3-7 FTP Upload Parameters Parameter Description Setting...
  • Page 45 Bi-spectrum network camera User Manual Configuring Thermal Audio Detect Alarm: At “ Configuration > Alarm > Audible Alarm Output” interface, users ⚫ should set the parameters of audible Alarm output in advance, as shown in Figure 3-11. Figure 3-11 Audible Alarm Output User can set the audio file manually.

  • Page 46: Thermal Mapping

    Bi-spectrum network camera Configuring Thermal User Manual Figure 3-12 Upload Audio File Flashlight Alarm: At “Configuration > Thermal > Led Control Param” interface, set the flashlight alarm mode. The Display Mode choose mode 5 (When alarm triggered, the Led light will keep on for 20s), the Led light will be on when the alarm is triggered.
  • Page 47 Bi-spectrum network camera User Manual Configuring Thermal Figure 3-14 Thermal Mapping Interface Step 2 Settings please refer to Table 3-8. Table 3-8 Parameter of Thermal Mapping Parameter Description Setting Horizontal shift(%) Adjust horizontal position of area [Setting method] which is on visual image. Input value Vertical shift(%) Adjust vertical position of area which is...

  • Page 48: Defect Pixel Correction

    Bi-spectrum network camera Configuring Thermal User Manual ----End 3.7 Defect Pixel Correction Operation Procedure Step 1 Choose Configuration > Thermal > Defect Pixel Correction. The Defect Pixel Correction page is displayed, as shown in Figure 3-15. If the image has a white dot as shown in figure, user can test the function to recover the defect pixel.

  • Page 49: Led Control Param

    Bi-spectrum network camera User Manual Configuring Thermal Figure 3-16 Recover Defect Pixel Step 3 Click Apply. The message "Apply success" is displayed, the system saves the settings. ----End 3.8 LED Control Param Set the display mode and brightness of LED, as shown in Figure 3-17. Issue V 1.0（2023-05-24）...
  • Page 50 Bi-spectrum network camera Configuring Thermal User Manual Figure 3-17 LED Control Param Table 3-9 LED Control Param Parameter Description Setting Display Mode There are four modes can be chosen. [Setting method] Open: the LED is always lighting. Select from drop-down list.

  • Page 51: Visible Channel Image Settings

    Bi-spectrum network camera User Manual Visible Channel Image Settings Visible Channel Image Settings 4.1 Accessing the Image Settings Interface Procedure Step 1 On the web, move the cursor to the real-time video page of visible channel and right- click on the page. A shortcut menu is displayed, as shown in Figure 4-1 Figure 4-1 Image Settings Interface Or at “Configuration >...

  • Page 52: Mode

    Bi-spectrum network camera Visible Channel Image Settings User Manual Figure 4-2 Image Settings Step 2 Choose Image Settings and the dialog box appears. Step 3 Choose the scheme from drop-down list, there are four schemes can be set. ⚫ All sensor configure can be modified at debug mode. Click in the lower left corner of Sensor Setting, and choose Debug Mode.

  • Page 53: Image

    Bi-spectrum network camera User Manual Visible Channel Image Settings Figure 4-3 Mode Step 2 Choose the switch mode from the drop-down list. Step 3 Time mode: Set the Start Time, set the End Time. Step 4 Click Save, the message "Save succeed" is displayed, the system saves the settings. ----End 4.3 Image Figure 4-4 shows the Image tab page.
  • Page 54 Bi-spectrum network camera Visible Channel Image Settings User Manual Figure 4-4 Image Table 4-1 describes the parameters on the Image Adjust tab page. Table 4-1 Parameters of Image Parameter Description Configuration Method Brightness It indicates the total brightness of an image. As [Setting method] the value increases, the image becomes Drag the slider.

  • Page 55: Scene

    Bi-spectrum network camera User Manual Visible Channel Image Settings Saturation It indicates the color saturation of an image. As [Setting method] the value increases, the image becomes more Drag the slider. colorful. [Default value] Contrast It indicates the measurement of different [Setting method] brightness levels between the brightest white Drag the slider.

  • Page 56: Exposure

    Bi-spectrum network camera Visible Channel Image Settings User Manual Table 4-2 Parameters of Scene Parameter Description Configuration Method Scene Indoor or outdoor. [Setting method] Select a value from the drop-down list. [Default value] Indoor Mirror It is used to select the pixel location of [Setting method] an image.
  • Page 57 Bi-spectrum network camera User Manual Visible Channel Image Settings Figure 4-6 Exposure Table 4-3 describes the parameters on the Exposure setting tab page. Table 4-3 Parameters of Exposure Setting Parameter Description Configuration Method Exposure Mode The exposure modes include: [Setting method] Select a value from ⚫...
  • Page 58 Bi-spectrum network camera Visible Channel Image Settings User Manual Meter area Choose the area to meter, t there are full [Setting method] metering, spot metering and partial Select a value from metering. the drop-down list. [Default value] Full metering Max Shutter It is valid in mode.
  • Page 59 Bi-spectrum network camera User Manual Visible Channel Image Settings Figure 4-7 WB Table 4-4 describes the parameters on the WB tab page. Issue V 1.0（2023-05-24）...

  • Page 60: Daynight

    Bi-spectrum network camera Visible Channel Image Settings User Manual Table 4-4 Parameters of WB Parameter Description Configuration Method Mode It is used to display the real color of a [Setting method] monitoring scenario when the color temperature Select a value changes.
  • Page 61 Bi-spectrum network camera User Manual Visible Channel Image Settings Figure 4-8 Day-night Table 4-5 describes the parameters on the DayNight tab page. Issue V 1.0（2023-05-24）...
  • Page 62 Bi-spectrum network camera Visible Channel Image Settings User Manual Table 4-5 Parameters of Day Night Parameter Description Configuration Method DayNight It can be set to Auto, Day Mode, Night Mode [Setting method] Mode and Timing. Select a value from the drop-down list. ⚫...

  • Page 63: Noise Reduction

    Bi-spectrum network camera User Manual Visible Channel Image Settings IR LED Tick to enable the IR LED, there are two modes [Setting method] can be chosen, auto and manual. At manual Select a value from mode drag slider to adjust the value. the drop-down list.

  • Page 64: Enhance Image

    Bi-spectrum network camera Visible Channel Image Settings User Manual Table 4-6 Parameters of Noise Reduction Parameter Description Configuration Method 2D NR Auto /manual, default value is auto. [Setting method] By comparing and screening the images of the Drag the slider two frames before and after, the noise point strength.
  • Page 65 Bi-spectrum network camera User Manual Visible Channel Image Settings Figure 4-10 Enhance Image Table 4-7 describes the parameters on the enhance image setting tab page. Table 4-7 Parameters of Enhance Image Parameter Description Configuration Method It is intended to provide clear image [Setting method] performance in strong backlight areas such as Drag the slider.
  • Page 66 Bi-spectrum network camera Visible Channel Image Settings User Manual It indicates reverse bright points in the picture [Setting method] to black. As an effective approach to Drag the slider. recognize vehicle plate number at night, HLC [Default value] function can detect any spotlight diffused by object-vehicle and compensate it for obtaining clearer image.

  • Page 67: Thermal Channel Image Settings

    Bi-spectrum network camera User Manual Thermal Channel Image Settings Thermal Channel Image Settings 5.1 Accessing the Image Settings Interface Operation Procedure Step 1 On the web, move the cursor to the real-time video page of thermal channel and right- click on the page. A shortcut menu is displayed, as shown in Figure 5-1. Figure 5-1 Image Settings Configuration Or at “Configuration >...

  • Page 68: Mode

    Bi-spectrum network camera Thermal Channel Image Settings User Manual Figure 5-2 Thermal Channel Image Setting Step 2 Choose Image Settings. The dialog box is displayed, as shown in Figure 5-3. Step 3 Choose the scheme from drop-down list, there are four schemes can be set. ----End 5.2 Mode Figure 5-3 shows the Mode interface.

  • Page 69: Image

    Bi-spectrum network camera User Manual Thermal Channel Image Settings Figure 5-3 Mode Interface Operation Procedure Step 2 Click in the lower left corner of Sensor Setting, and choose Debug Mode. Step 3 Choose switch mode from the drop-down list. Step 4 Time mode: Set the Start Time, set the End Time. Step 5 Click Save, the message "...
  • Page 70 Bi-spectrum network camera Thermal Channel Image Settings User Manual Figure 5-4 Image Interface Step 2 Click in the lower left corner of Sensor Setting, and choose Debug Mode. Step 3 Drag the slider to adjust parameter of image. Step 4 Click Save, the message "Save succeed" is displayed, the system saves the settings. NOTE ⚫...

  • Page 71: Scene

    Bi-spectrum network camera User Manual Thermal Channel Image Settings 5.4 Scene Figure 5-5 shows the Scene setting interface. Figure 5-5 Scene Interface Step 2 Click in the lower left corner of Sensor Setting, and choose scene Step 3 Choose mirror mode from drop-list. Step 4 Click Save, the message "Save succeed"...

  • Page 72: Set Pseudocolor

    Bi-spectrum network camera Thermal Channel Image Settings User Manual 5.5 Set Pseudocolor Figure 5-6 shows the Set Pseudocolor setting interface. Figure 5-6 Set Pseudocolor Setting Interface Step 2 Click in the lower left corner of Sensor Setting, and choose set pseudo color Step 3 Choose polarity/LUT mode from drop-list.

  • Page 73: Ffc Control

    Bi-spectrum network camera User Manual Thermal Channel Image Settings ⚫ The temperatures of the temperature fields detected by the thermal imaging camera are separately mapped to values ranging from 0 to 255 by the algorithm. In the black/white display mode, this range is converted to the gray scale tones. For example, 0 indicates completely black, and 255 indicates completely white.
  • Page 74 Bi-spectrum network camera Thermal Channel Image Settings User Manual Figure 5-7 FFC Control Interface Table 5-1 lists the parameters on the FFC control interface. Table 5-1 Parameters of FFC Control Interface Parameter Description Setting The internal of the thermal imaging camera may comprise the mechanical action correction mechanism that can periodically improve the image quality.
  • Page 75 Bi-spectrum network camera User Manual Thermal Channel Image Settings Parameter Description Setting operations can prevent the grainy and image degradation problems. The FFC is especially important when the temperature of the camera changes. For example, after the camera is powered on or the ambient temperature is changed, you should immediately perform the FFC.

  • Page 76: Noise Reduction

    Bi-spectrum network camera Thermal Channel Image Settings User Manual Parameter Description Setting adjust Background Click the icon and camera perform the action. Manually adjust ----End 5.7 Noise Reduction Figure 5-8 shows the Noise reduction interface. Figure 5-8 Noise Reduction Interface Table 5-2 lists the Noise reduction parameters.
  • Page 77 Bi-spectrum network camera User Manual Thermal Channel Image Settings Parameter Description Setting noise. Select from the drop-down list box. [Default value] Close [How to set] Select from the drop-down list box. Decrease the image 3DNR noise. [Default value] Close ----End Issue V 1.0（2023-05-24）...

  • Page 78: Intelligent Analysis

    Bi-spectrum network camera Intelligent Analysis User Manual Intelligent Analysis There are many kinds of intelligent analysis, such as Intrusion, Single Line Crossing, Double Line Crossing, Multi-Loitering, Retrograde, People Counting, Enter Area, Leave Area. The parameters of these analysis alarm are roughly similar, so we will describe someone in detail as a reference.
  • Page 79 Bi-spectrum network camera User Manual Intelligent Analysis interface, as shown in Figure 6-1. Figure 6-1 Intrusion Setting Interface Step 2 Set all parameters for Intrusion. The table describes the specific parameters. Table 6-1 Intrusion Parameter Description Parameter Description Setting Channel Channel 1: visible.
  • Page 80 Bi-spectrum network camera Intelligent Analysis User Manual Parameter Description Setting Sensitivity The sensitivity of detecting smoker, [How to set] when the value is high, the alarm can be Choose from the drop-down triggered easily, but the accuracy will be list lower.
  • Page 81 Bi-spectrum network camera User Manual Intelligent Analysis Parameter Description Setting Video Stream Enable the button, the draw line will [How to set] Draw Line show at live video when the stream is Click to enable FTP stream 2. Upload. [Default value] Step 3 Set a deployment area.

  • Page 82: Single Line Crossing

    Bi-spectrum network camera Intelligent Analysis User Manual Figure 6-2 Deployment Time Setting Interface Step 5 Click Apply to save the settings. ----End 6.2 Single Line Crossing Procedure Step 1 Select Configuration > Intelligent Analysis > Single Line Crossing to access the Single Line Crossing setting interface, as shown in Figure 6-3.
  • Page 83 Bi-spectrum network camera User Manual Intelligent Analysis Figure 6-3 Single Line Crossing Setting Interface Step 2 Set all parameters for the Single Line Crossing. Table 6-2 describes the specific parameters. Table 6-2 Parameters of Single Line Crossing Parameter Description Setting Channel Channel 1: visible.
  • Page 84 Bi-spectrum network camera Intelligent Analysis User Manual Parameter Description Setting Limit Type Effective alarms are set [How to set] based on target type, with Click to enable Limit options of Person or Car, Target Type. person, car. When the [Default value] device is used indoors, because of small space and large targets, alarms are...

  • Page 85: Double Line Crossing

    Bi-spectrum network camera User Manual Intelligent Analysis Parameter Description Setting FTP Upload Enable the button to enable [How to set] File Transfer Protocol. Click to enable FTP. [Default value] Video Stream Draw Enable the button to enable [How to set] Line Video Stream Draw Line, Click to enable Video...
  • Page 86 Bi-spectrum network camera Intelligent Analysis User Manual Double Line Crossing setting interface, as shown in Figure 6-4. Figure 6-4 Double Line Crossing Setting Interface Step 2 Set all parameters for the Double Line Crossing. Table 6-3 describes the specific parameters. Table 6-3 Description of Parameters for Double Line Crossing Parameter Description...
  • Page 87 Bi-spectrum network camera User Manual Intelligent Analysis Parameter Description Setting Limit Type Effective alarms are set based on target type, with [How to set] options of Person or Car, person, car. When the Click to enable device is used indoors, because of small space and Limit Target large targets, alarms are triggered by person Type.

  • Page 88: People Counting

    Bi-spectrum network camera Intelligent Analysis User Manual Draw a line: Move the cursor to the drawing interface, hold down the left mouse button, and move the cursor to draw two lines. When you release the left mouse button, two numbered virtual fences are generated. Choose either of the Double Line Crossing to set the direction to Positive or Reverse.
  • Page 89 Bi-spectrum network camera User Manual Intelligent Analysis Figure 6-5 People Counting Step 2 Set all parameters for People Counting. Table 6-4 describes the specific parameters. Issue V 1.0（2023-05-24）...
  • Page 90 Bi-spectrum network camera Intelligent Analysis User Manual Table 6-4 Parameters of People Counting Parameter Description Setting Channel Channel 1: visible. [How to set] Channel 2: thermal. Choose one channel to set. Enable Enable the button to enable the alarm. [How to set] Click Enable to enable.
  • Page 91 Bi-spectrum network camera User Manual Intelligent Analysis Parameter Description Setting Output Channel If you check to set the Output Channel [How to set] and the device is connected to an external Click to select an ID. alarm indicator, the alarm indicator signals when an alarm is triggered.

  • Page 92: Enter Area / Leave Area

    Bi-spectrum network camera Intelligent Analysis User Manual 6.5 Enter Area / Leave Area Description The enter area refers to that an alarm is generated when a target enter the deployment area at the valid time. Procedure Step 1 Select Configuration > Intelligent Analysis > Enter Area / Leave Area to access the Enter Area / Leave Area setting interface, as shown in Figure 6-6.
  • Page 93 Bi-spectrum network camera User Manual Intelligent Analysis Figure 6-7 Leave Area Step 2 Set all parameters for Enter Area / Leave Area, the details please refer to above tables. Step 3 Set a deployment area. Move the cursor to the drawing interface and click to generate a point, move the cursor to draw a line, and then click to generate another point.

  • Page 94: Advanced Intelligent Analysis

    Bi-spectrum network camera Advanced Intelligent Analysis User Manual Advanced Intelligent Analysis At the advanced intelligent analysis interface, users can set the parameters of smoker detection, smoke and flame detection, and fire spot detection. Enable the linkage actions, the alarm information can be sent to user by the linkage. The advanced intelligent analysis can be used for detecting the smoking, if someone smoke in the indoor where smoking is forbidden.
  • Page 95 Bi-spectrum network camera User Manual Advanced Intelligent Analysis Figure 7-1 Smoker Detection Interface Step 2 Set all parameters for Smoker Detection. Table 7-1 describes the specific parameters. Table 7-1 Parameters of Smoker Detection Parameter Description Setting Enable At thermal channel, Enable the button to [How to set] enable the alarm.
  • Page 96 Bi-spectrum network camera Advanced Intelligent Analysis User Manual Parameter Description Setting Audible alarm Enable, when an alarm occurs, it will [How to set] play audio to alarm. Click to enable Audible Choose the audible alarm file (set at the alarm “Configuration >...

  • Page 97: Smoke And Flame Detection

    Bi-spectrum network camera User Manual Advanced Intelligent Analysis ⚫ A drawn line cannot cross another one, or the line drawing fails. ⚫ Any shape with 32 sides at most can be drawn. ⚫ The quantity of deployment areas is up to 8. Step 4 Set deployment time.
  • Page 98 Bi-spectrum network camera Advanced Intelligent Analysis User Manual Figure 7-2 Smoke and Flame Detection Interface Step 2 Set all parameters for Smoke and Flame Detection. Table 7-2 describes the specific parameters. Table 7-2 Smoke Flame Detection Description Parameter Description Setting Enable At thermal channel, Enable the button to [How to set]...
  • Page 99 Bi-spectrum network camera User Manual Advanced Intelligent Analysis Parameter Description Setting Audible alarm Enable, when an alarm occurs, it will [How to set] play audio to alarm. Click to enable Audible Choose the audible alarm file (set at the alarm “Configuration >...

  • Page 100: Fire Spot Detection

    Bi-spectrum network camera Advanced Intelligent Analysis User Manual ⚫ A drawn line cannot cross another one, or the line drawing fails. ⚫ Any shape with 32 sides at most can be drawn. ⚫ The quantity of deployment areas is up to 8. Step 4 Set deployment time.
  • Page 101 Bi-spectrum network camera User Manual Advanced Intelligent Analysis Figure 7-3 Fire Spot Detection Interface Step 2 Set all parameters for Fire Spot Detection. Table 7-3 describes the specific parameters. Table 7-3 Fire Spot Detection Description Parameter Description Setting Enable At thermal channel, Enable the button to [How to set] enable the alarm.
  • Page 102 Bi-spectrum network camera Advanced Intelligent Analysis User Manual Parameter Description Setting Audible alarm Enable, when an alarm occurs, it will [How to set] play audio to alarm. Click to enable Audible Choose the audible alarm file (set at the alarm “Configuration >...
  • Page 103 Bi-spectrum network camera User Manual Advanced Intelligent Analysis Figure 7-4 Set Deployment Area NOTE ⚫ A drawn line cannot cross another one, or the line drawing fails. ⚫ Any shape with 32 sides at most can be drawn. ⚫ The quantity deployment areas is up to 8. Step 4 Set deployment time.

  • Page 104: Ai Multi-Object

    Bi-spectrum network camera AI Multi-object User Manual AI Multi-object Step 1 At “ Configuration > AI Multiobject ” interface, user can enable full-body detection, vehicle detection to detect the person and vehicle, as shown in Figure 8-1. Figure 8-1 AI Multiobject Step 2 Set the parameters of AI multiobject following as the Table 8-1 .
  • Page 105 Bi-spectrum network camera User Manual AI Multi-object Channel 2 is thermal channel. drop list. Full body The camera will snap the whole body when detection someone appear in live video. The detection frame Enable is blue. Vehicle The camera will snap the licence when the vehicle detection appear in live video.

  • Page 106: Alarm Setting

    Bi-spectrum network camera Alarm Setting User Manual Alarm Setting 9.1 Alarm Output Procedure Step 1 Select Configuration > Alarm > Alarm Output to access the Alarm Output setting interface, as shown in Figure 9-1. Figure 9-1 Alarm Output Interface Step 2 Set alarm output of channel, name, enable valid signal and alarm time choose alarm output mode.

  • Page 107: Disk Alarm

    Bi-spectrum network camera User Manual Alarm Setting 9.2 Disk Alarm Procedure Step 1 Select Configuration > Alarm > Disk Alarm to access the disk alarm setting interface, as shown in Figure 9-2. Figure 9-2 Disk Alarm Interface Step 2 Enable the disk full alarm, when the disk is full it will alarm. Step 3 Set alarm interval and tick output channel.

  • Page 108: I/O Alarm Linkage

    Bi-spectrum network camera Alarm Setting User Manual Figure 9-3 Network Alarm Interface Step 2 Choose network card ID and enable exceptional alarm to set alarm interval. Tick output channel. Step 3 Click Apply to save the settings, click refresh will return last settings. ---End 9.4 I/O Alarm Linkage Procedure...

  • Page 109: Motion Alarm

    Bi-spectrum network camera User Manual Alarm Setting Figure 9-4 I/O Alarm Linkage Interface Step 2 Choose alarm input and trigger mode, set name, enable other linkages such as alarm input, PTZ linkage, Alarm Record SMTP, FTP upload, IR Cut and flashlight alarm. Step 3 Set alarm schedule, choose the duration of linkage.

  • Page 110: Push Message

    Bi-spectrum network camera Alarm Setting User Manual Figure 9-5 Motion Alarm Interface Step 2 Choose channel and enable the motion alarm, set alarm interval and sensitivity, enable other linkages such as SMTP, FTP upload and motion detect stream. Step 3 Set motion alarm schedule, Step 4 Click Apply to save the settings, click Refresh will return last settings.

  • Page 111: Audio Abnormal Detection

    Bi-spectrum network camera User Manual Alarm Setting Figure 9-6 Push Message Interface Step 2 Enable the push message, you will receive the message when the alarm happened. Step 3 Click Apply to save the settings, click Refresh will return last settings. ---End 9.7 Audio Abnormal Detection Procedure...
  • Page 112 Bi-spectrum network camera Alarm Setting User Manual Figure 9-7 Audio Abnormal Detection Interface Step 2 Enable the audio abnormal detection, enable sudden rise, sudden drop, when happen the condition of enable, it will alarm. Step 3 Tick the output channel, enable alarm record, SMTP, FTP upload. Step 4 Set alarm schedule, choose the duration of linkage.

  • Page 113: Other Web Configurations

    Bi-spectrum network camera User Manual Other Web Configurations Other Web Configurations 10.1 Device Information You can view the information about device, as shown in Figure 10-1. Figure 10-1 Device Information Interface Issue V 1.0（2023-05-24）...

  • Page 114: Stream

    Bi-spectrum network camera Other Web Configurations User Manual 10.2 Stream 10.2.1 Base Stream Step 1 Choose Configuration > Stream >Base Stream, as shown in Figure 10-2. Figure 10-2 Base Stream Interface Issue V 1.0（2023-05-24）...

  • Page 115: Roi

    Bi-spectrum network camera User Manual Other Web Configurations Figure 10-3 Channel 2 (Thermal Channel) Stream Step 2 Choose channel, stream ID, video encode type, video encode level, audio encode type, resolution, frame rate, frame interval, bit rate type and bit rate from all drop list. Step 3 Set name of base stream, enable smart encode.

  • Page 116: Snapshot

    Bi-spectrum network camera Other Web Configurations User Manual Figure 10-4 ROI Interface Step 2 Click Draw and the frame is showing, adjust the position of frame to set ROI area. Step 3 Click Apply. The message "Apply success" is displayed, the system saves the settings. ---End 10.2.3 Snapshot Step 1 Choose Configuration >...

  • Page 117: Device

    Bi-spectrum network camera User Manual Other Web Configurations Figure 10-5 Snapshot Interface Step 2 Choose snapshot resolution and snapshot quality from drop list. Step 3 Click Apply. The message "Apply success" is displayed, the system saves the settings. ---End 10.3 Device You can set local network, device port, data and time, camera, OSD, microphone, CVBS, system, voice denoise and software licenses, as shown in Figure 10-6.
  • Page 118 Bi-spectrum network camera Other Web Configurations User Manual Figure 10-7 External Device Interface Issue V 1.0（2023-05-24）...

  • Page 119: Privacy Masking

    Bi-spectrum network camera User Manual Other Web Configurations 10.5 Privacy Masking Choose Configuration > Privacy masking. You can set privacy masking if some area needs keep secret, drag mouse to select the area to cover, double click will delete the setting, as shown in Figure 10-8.

  • Page 120: Privacy Manager

    Bi-spectrum network camera Other Web Configurations User Manual Description If the device is connected to a router or switch with a QOS function, and the priority rule of the corresponding mark is configured on the network device, the network device will preferentially pass the data packet of the corresponding mark.

  • Page 121: Protocol

    Bi-spectrum network camera User Manual Other Web Configurations Figure 10-10 Privacy Manager Interface 10.8 Protocol Choose Configuration > Protocol. You can set protocol information, security, CMS configuration and multicast parameter. Issue V 1.0（2023-05-24）...

  • Page 122: Device Log

    Bi-spectrum network camera Other Web Configurations User Manual Figure 10-11 Protocol Interface 10.9 Device Log Choose Configuration > Device Log. You can view operation log and alarm log, or collect all log information, as shown in Figure 10-12. Figure 10-12 Device Log Interface 10.10 Maintenance Choose configuration >...

  • Page 123: Local Config

    Bi-spectrum network camera User Manual Other Web Configurations Figure 10-13 Maintenance Interface 10.11 Local Config When users choose the plugin to play live video, this function can be set. Choose Configuration > Local Config. You can change the save path of snapshot and local record, choose the playback performance, as shown in Figure 10-14.

  • Page 124: Troubleshooting

    Bi-spectrum network camera A Troubleshooting User Manual A Troubleshooting Common Trouble Possible Cause Solution Unable to access Network is not Connect the network cable of the camera to the the web connected. PC to check whether the network cable is in good contact.
  • Page 125 Bi-spectrum network camera User Manual A Troubleshooting Common Trouble Possible Cause Solution The upgrade package Perform the correct upgrade package again. is incorrect. 1. Make sure ‘thermal mapping’ and ‘thermal calibration is configured The temperature correctly’ by checking highest temperature object at two channels. is too high.
