Bi-Spectral PTZ Network Camera
User Manual
Issue
V1.0
Date
2019-04-03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SN-TPT4231 and is the answer not in the manual?

Questions and answers

Related Manuals for Sunell Security SN-TPT4231

Summary of Contents for Sunell Security SN-TPT4231

  • Page 1 Bi-Spectral PTZ Network Camera User Manual Issue V1.0 Date 2019-04-03...

  • Page 3: Precautions

    Bi-Spectral PTZ Network Camera User Manual Precautions Precautions Precautions Fully understand this document before using this device, and strictly observe rules in this document when using this device. If you install this device in public places, provide the tip "You have entered the area of electronic surveillance" in an eye- catching place.
  • Page 4 Bi-Spectral PTZ Network Camera Overview User Manual  Strictly conform to local electrical safety standards and use power adapters that are marked with the LPS standard when installing and using this device. Otherwise, this device may be damaged.  Use accessories delivered with this device. The voltage must meet input voltage requirements for this device.
  • Page 5 Bi-Spectral PTZ Network Camera User Manual Precautions  Do not jam the ventilation opening. Follow the installation instructions provided in this document when installing the device.  Keep the device away from heat sources such as radiators, electric heaters, or other heat equipment.

  • Page 6: Table Of Contents

    Bi-Spectral PTZ Network Camera Overview User Manual Contents Precautions ........................i 1 Overview ........................7 1.1 Principle of Thermal Imaging and Advantages .............. 7 1.2 Product Introduction ....................... 7 1.2.1 Function ......................8 1.2.2 Product Features ....................8 1.3 Description of PTZ cable ....................9 1.3.1 Multi-cable ......................
  • Page 7 Bi-Spectral PTZ Network Camera User Manual Overview 4.2 Visible-light Web ......................34 4.2.1 Login and Logout ..................... 34 4.2.2 Main Page Layout .................... 35 4.2.3 Change the Password ..................37 4.2.4 Browse Video ....................38 4.2.5 Set Local Network Parameters ................. 40 5 Thermal Parameter Configuration ..............
  • Page 8 Bi-Spectral PTZ Network Camera Overview User Manual 8 Technical Specifications ..................76 A Troubleshooting....................80 B Common Emission Rate ..................83 Issue V1.0 (2019-04-03)

  • Page 9: Overview

    Bi-Spectral PTZ Network Camera User Manual Overview Overview 1.1 Principle of Thermal Imaging and Advantages Any object with temperature higher than the absolute zero (-273.15°F) will emit infrared (IR) ray, even though it does not emit light. The IR ray is also called thermal radiation.

  • Page 10: Function

    Bi-Spectral PTZ Network Camera Overview User Manual functions, suitable for large areas of monitoring, can be widely used in airports, stations, urban roads, traffic survey and monitoring, forest fire prevention, the high and heavy equipment rotary control and other important area. 1.2.1 Function ...

  • Page 11: Description Of Ptz Cable

    Bi-Spectral PTZ Network Camera User Manual Overview 1.3 Description of PTZ cable 1.3.1 Multi-cable Aviation power supply and network cable of twenty-six cores is shown as Figure 1-1 &Figure 1-2, and the description is shown in Table 1-1. Figure 1-1 Aviation power supply and network cable of twenty-six cores Figure 1-2 Definition of twenty-six cores Issue V1.0 (2019-04-03)
  • Page 12 Bi-Spectral PTZ Network Camera Overview User Manual Table 1-1 Description of twenty-six cores Name Description DC36V - Black (Thick) Red (Thick) DC36V + Black (Thick) DC36V - DC36V - Black (Thick) Alarm_OUT1 Red (Thin) DC36V + Red (Thick) DC36V + Red (Thick) Audio_IN(G) Audio masking...

  • Page 13: Aviation Alarm Cable

    Bi-Spectral PTZ Network Camera User Manual Overview 1.3.2 Aviation Alarm Cable Aviation alarm cable of twenty-six cores is shown as Figure 1-3& Figure 1-4, and the description is shown in Table 1-2. Figure 1-3 Aviation power supply cable of twenty-six cores Figure 1-4 Definition of twenty-six cores Issue V1.0 (2019-04-03)
  • Page 14 Bi-Spectral PTZ Network Camera Overview User Manual Table 1-2 Description of twelve cores Name Description Reserved core Blank Reserved core Blank Reserved core Blank Reserved core Blank Reserved core Ground Reserved core Blank Reserved core Blank Reserved core Ground Reserved core Ground Reserved core Blank...
  • Page 15 Bi-Spectral PTZ Network Camera User Manual Overview Issue V1.0 (2019-04-03)

  • Page 16: Device Dimensions

    Dual Vision Light Load Thermal PTZ Device Dimensions User Manual Device Dimensions Figure 2-1 shows the dimensions of the Dual Vision Light Load Thermal PTZ. Figure 2-1 Dimensions (unit: mm) Issue V1.0 (2019-04-03)

  • Page 17: Device Installation

    Bi-Spectral PTZ Network Camera User Manual Device Installation Device Installation 3.1 Installation Method High definition dual spectrum intelligent cloud platform camera can be installed on camera base. Figure 3-1 shows the base dimensions of PTZ camera. Figure 3-1 Base dimensions of PTZ camera (unit: mm) 3.2 Device Installation 3.2.1 Installation of Basic Requirements Installation site and environment to meet the technical parameters mentioned in the...

  • Page 18: Installation Space And Installation Strength

    Dual Vision Light Load Thermal PTZ Device Installation User Manual Table 3-1 Installation tools Name Quantity Remarks 13mm wrench For mounting fixtures and mounting brackets 14mm sleeve Cross For common construction screwdriver(big) Used to disassemble the DIP cover to Cross adjust the device communication screwdriver(small) parameters...
  • Page 19 Bi-Spectral PTZ Network Camera User Manual Device Installation COLOR Function define Remark RS422 RX+ Blue RS422 RX- Yellow & Green In order to prevent lightning strikes, the grounding wire (yellow-green wire) in the cable outlet base must be grounded reliably and the grounding resistance should be <4Ω. ----End Issue V1.0 (2019-04-03)

  • Page 20: Quick Configuration

    Dual Vision Light Load Thermal PTZ Quick Configuration User Manual Quick Configuration 4.1 Thermal Web 4.1.1 Login and Logout You must use Internet Explorer 8 or a later version to access the web management system; otherwise, some functions may be unavailable. Login system Step 1 Open the Internet Explorer, enter the IP address of IP camera (default value:...

  • Page 21: Main

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration Logout To logout of system, click in the upper right corner of the main page, the login page is display after you log out of the system. 4.1.2 Main Page Layout On the main page, you can view real-time video, set parameter, Video parameter, Video control, PTZ control, PTZ Configure and log out of the system.

  • Page 22: Change The Password

    Dual Vision Light Load Thermal PTZ Quick Configuration User Manual Element Description the playback videos. Device You can choose a menu to set device parameters, configuration including the device information, audio and video streams, alarm setting, and privacy mask function. Change password You can click...

  • Page 23: Browse Video

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration The Change Password dialog box is displayed, as shown in Figure 4-3. Figure 4-3 Modify Password dialog box The change password page will be displayed if you don’t change the default password when you login the system for the first time.
  • Page 24 Dual Vision Light Load Thermal PTZ Quick Configuration User Manual Figure 4-4 Adding the a trusted site Step 2 In the Internet Explorer, choose Tool > Internet Options > Security > Customer level, and set Download unsigned ActiveX control and initialize and script ActiveX controls not marked as safe for scripting under ActiveX controls and plug-ins to Enable, as shown in Figure 4-5.

  • Page 25: Install Plugins

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration The login page is display when the control is loaded. 4.1.5 Install Plugins You will be prompted with a message “click here to use short delay Plugin for Live Video” as shown in Figure 4-6 when you login to the web management system for the first time.
  • Page 26 Dual Vision Light Load Thermal PTZ Quick Configuration User Manual Figure 4-7 Local Network page Step 2 Set the parameters according to Table 4-2. Table 4-2 Local network parameters Parameter Description Setting IP Protocol IPv4 is the IP protocol that uses [Setting method] an address length of 32 bits.
  • Page 27 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Parameter Description Setting Subnet Mask Subnet mask of the network [Setting method] adapter. Enter a value manually. [Default value] 255.255.255.0 Default Gateway This parameter must be set if [Setting method] the client accesses the device Enter a value manually.

  • Page 28: Thermal Settings

    Dual Vision Light Load Thermal PTZ Quick Configuration User Manual 4.1.7 Thermal Settings 4.1.7.1 Temperature Parameters Temperature parameters include: temperature unit, ambient type, ambient temperature, cavity temperature, correctional coefficient and area temperature display mode. Operation Procedure Step 1 Choose Configuration >Thermal >Temperature Parameters. The Temperature Parameters page is displayed, as shown in Figure 4-8.
  • Page 29 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Parameter Description Setting Cavity The cavity temperature of Temperature camera. Correction Correction coefficient is refer to [Setting method] Coefficient the deviation of measured Enter a value manually. object temperature and [Default value] actual temperature.

  • Page 30: Temperature Area

    Dual Vision Light Load Thermal PTZ Quick Configuration User Manual Parameter Description Setting Area Alarm [Setting method] Interval Enter a value manually ranges from 1 to 1800. [Default value] Step 3 Click Apply. The message "Apply success" is displayed, the system saves the settings. ----End 4.1.7.2 Temperature Area Operation Procedure...
  • Page 31 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Figure 4-9 Temperature area and alarm configuration Step 2 Set the parameters according to Table 4-4 Table 4-4 Temperature area and alarm configuration Parameter Description Setting Channel [Setting method] Select a value from the drop-down list box.
  • Page 32 Dual Vision Light Load Thermal PTZ Quick Configuration User Manual Parameter Description Setting Type Type of temperature area. [Setting method] ID 0 is default rectangle area, Select a value from the which is full screen. drop-down list box. [Default value] Rectangle/Point Alarm Type Threshold alarm and...
  • Page 33 Bi-Spectral PTZ Network Camera User Manual Quick Configuration area. Step 3 temperature 1. Tick an area ID. 2. Select type from drop-list. 3. Press and hold the left mouse button, and drag in the video area to draw a temperature area, as shown in Figure 4-10. Right-click to finish the area selected. Figure 4-10 Temperature Area Setting Interface 4.

  • Page 34: Schedule Linkage

    Dual Vision Light Load Thermal PTZ Quick Configuration User Manual 4.1.7.3 Schedule Linkage Operation Procedure Step 1 Choose Configuration >Thermal > Schedule Linkage The Schedule Linkage page is displayed, as shown in Figure 4-11. Figure 4-11 Schedule Linkage Step 2 Tick the output channel.

  • Page 35: Bad Point Check

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration The message "Apply success" is displayed, the system saves the settings. ----End 4.1.7.4 Bad Point Check Description The points that can’t move when the environment or scenario change is bad point. You can delete the bad point by bad point check function.

  • Page 36: Visible-Light Web

    Dual Vision Light Load Thermal PTZ Quick Configuration User Manual Figure 4-13 Recover bad point Step 3 Click Reset to return the previous settings. Step 4 Click Apply. The message "Apply success" is displayed, the system saves the settings. ----End 4.2 Visible-light Web 4.2.1 Login and Logout You must use Internet Explorer 8 or a later version to access the web management...

  • Page 37: Main

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration Login system Step 1 Open Internet Explorer, enter the IP address of the IP camera (default value: 192.168.0.120) in the address box, and press Enter. The login page is displayed, as shown in Figure 4-14. Figure 4-14 Login page Step 2 Enter the user name, and password.
  • Page 38 Dual Vision Light Load Thermal PTZ Quick Configuration User Manual Figure 4-15 Main page layout Table 4-5 Elements on the main page Element Description Real-time video area Real-time videos are played in this area. You can also set sensor parameters. Playback You can query the playback videos in this area.

  • Page 39: Change The Password

    Bi-Spectral PTZ Network Camera User Manual Quick Configuration Element Description Fault icon When the device encounters an exception, the fault icon is displayed. You can click to view the fault information. Change password You can click to change the password. Sign Out You can click to return to the login page.

  • Page 40: Browse Video

    Dual Vision Light Load Thermal PTZ Quick Configuration User Manual Figure 4-16 Modify Password dialog box The change password page will be displayed if you don’t change the default password when you login the system for the first time. User need to wait at least three minutes after changing password, and then restart the device.
  • Page 41 Bi-Spectral PTZ Network Camera User Manual Quick Configuration In the displayed dialog box, click Add, as shown in Figure 4-17. Figure 4-17 Add a trusted site Step 2 In Internet Explorer, choose Tools > Internet Options > Security > Customer level, and set Download unsigned ActiveX controls and Initialize and script ActiveX controls not marked as safe for scripting under ActiveX controls and plug-ins to Enable, as shown in Figure 4-18.

  • Page 42: Set Local Network Parameters

    Dual Vision Light Load Thermal PTZ Quick Configuration User Manual Step 3 Download and install the player control as prompted. If the repair tips displayed when installing the control, please ignore the prompt, and continue the installation, the login page is displayed when the control is loaded. Download the right control in the Internet Explorer Real-time video page pop-ups the message clicks to play live video with ActiveX control to reduce latency.
  • Page 43 Bi-Spectral PTZ Network Camera User Manual Quick Configuration  Procedure Step 1 Choose Configuration > Device > Local Network.. The Local Network page is displayed, as shown in Figure 4-19 Figure 4-19 Local Network page Step 2 Set the parameters according to Table 4-6. Table 4-6 Local network parameters Parameter Description...
  • Page 44 Dual Vision Light Load Thermal PTZ Quick Configuration User Manual Parameter Description Setting Obtain IP address The device automatically obtains [Setting method] automatically the IP address from the DHCP Click the button on server. to enable DHCP. NOTE To query the current IP address of the device, you must query it on the...
  • Page 45 Bi-Spectral PTZ Network Camera User Manual Quick Configuration Parameter Description Setting MTU(800-1500) Set the maximum value of network [Setting method] transmission data packets. Enter a value manually. NOTE The MTU value is range from 800 to 1500, the default value is 1500, Please do not change it arbitrarily.

  • Page 46: Thermal Parameter Configuration

    Dual Vision Light Load Thermal PTZ Thermal Parameter Configuration User Manual Thermal Parameter Configuration 5.1 Access the Sensor Setting Interface Operation procedure: Step 1 On the web interface or client interface, move the cursor to the real-time video page and right-click on the page. A shortcut menu is displayed, as shown in Figure 5-1,and Table 5-1 describes the sensor setting interface.

  • Page 47: Sensor Setting Parameter Description

    Dual Vision Light Load Thermal PTZ User Manual Thermal Parameter Configuration Step 2 Choose Sensor Configure and the Sensor Setting dialog box appears. ----End 5.2 Sensor Setting Parameter description 5.2.1 Time Segment Operation procedure: Step 1 Click Time Segment tag on sensor setting interface, the time segment page is displayed, as shown in Figure 5-2.
  • Page 48 Dual Vision Light Load Thermal PTZ Thermal Parameter Configuration User Manual Figure 5-3 Image setting interface Table 5-2 describes the image setting parameters. Table 5-2 Image setting parameter description Parameter Description Configuration Method The temperature field of a scenario detected by the thermal imaging camera will be mapped to the value range 0~255 by algorithm processing.

  • Page 49: Ffc Mode

    Dual Vision Light Load Thermal PTZ User Manual Thermal Parameter Configuration Parameter Description Configuration Method Sharpness of thermal images is not as good as [Configuration visible light, so the original image is difficult method] to identify. By the image enhancement and Dynamic Drag the slide bar edge processing technologies, the image can...
  • Page 50 Dual Vision Light Load Thermal PTZ Thermal Parameter Configuration User Manual Figure 5-4 FFC mode interface Table 5-3 describes the FFC mode parameters. Issue V1.0 (2019-04-03)
  • Page 51 Dual Vision Light Load Thermal PTZ User Manual Thermal Parameter Configuration Table 5-3 FFC mode parameter description Parameter Description Configuration Method The thermal imaging camera contains a mechanical correction actuator to periodically improve image quality. This actuator is called flat field correction (FFC).

  • Page 52: Noise Reduction

    Dual Vision Light Load Thermal PTZ Thermal Parameter Configuration User Manual Parameter Description Configuration Method [Configuration method] Drag the slide FFC interval In auto FFC mode, FFC interval range: 5~30 min (min) [Default value] In manual or external FFC mode, the camera will not Flat Field automatically execute FFC in case of temperature Correction...

  • Page 53: Adjust The Screen

    Dual Vision Light Load Thermal PTZ User Manual Thermal Parameter Configuration Table 5-4 DNR parameter description Parameter Meaning Configuration Method [Configuration method] Select from the drop-down list 3D NR Reduce noise of image. [Default value] [Configuration method] Select from the drop-down list 2D NR Reduce noise of image.
  • Page 54 Dual Vision Light Load Thermal PTZ Thermal Parameter Configuration User Manual Table 5-5 Screen adjustment parameter description Parameter Meaning Configurati on Method Compared with images generated based on visible light, IR images boast the features of high background and low contrast.

  • Page 55: Visible-Light Parameter Configuration

    Dual Vision Light Load Thermal PTZ User Manual Visible-light Parameter Configuration Visible-light Parameter Configuration 6.1 Access the Sensor Interface Operation procedure Step 1 On the web or NVMS interface, move the cursor to the real-time video page and right-click on the page. A shortcut menu is displayed, as shown in Figure 6-1. Figure 6-1 Sensor Setting interface Step 2 Choose Sensor Configure and the Sensor Setting dialog box appears.

  • Page 56: Image Adjust

    Dual Vision Light Load Thermal PTZ Visible-light Parameter Configuration User Manual Figure 6-2 Time Segment page Step 2 Choose Debug Model in the lower left corner to activate the sensor setting page. Step 3 Set the time segment parameters. Step 4 Click save to save the setting.

  • Page 57: Scene Mode

    Dual Vision Light Load Thermal PTZ User Manual Visible-light Parameter Configuration Table 6-1describes the parameters on the Image Adjust tab page. Table 6-1 Parameters on the Image Adjust tab page Parameter Description Configuration Method Contrast It indicates the contrast between the bright part [Setting method] and the dark part of an image.
  • Page 58 Dual Vision Light Load Thermal PTZ Visible-light Parameter Configuration User Manual Figure 6-4 Scene mode interface Table 6-2describes the FFC mode parameters. Table 6-2 FFC mode parameters description Parameter Description Configuration Method It indicates the working mode of a camera.. [Configuration method] Select from the drop- ...

  • Page 59: Exposure

    Dual Vision Light Load Thermal PTZ User Manual Visible-light Parameter Configuration Parameter Description Configuration Method [Setting method] It can be set to on or off. It is used to Tick the Freeze status. Freeze enable or disable the image freezing [Default value] function of a camera.

  • Page 60: Wb Setting

    Dual Vision Light Load Thermal PTZ Visible-light Parameter Configuration User Manual Table 6-3 Exposure parameters description Parameter Meaning Configuration Method The exposure modes include: [Setting method]  Auto: The system performs auto exposure based Select a value on the monitoring environment. from the drop- ...
  • Page 61 Dual Vision Light Load Thermal PTZ User Manual Visible-light Parameter Configuration Figure 6-6 WB Setting interface Table 6-4 describes WB Setting parameters. Table 6-4 WB Setting parameters description Parameter Meaning Configuration Method It is adjusted based on application scenarios [Setting method] Mode to improve the fidelity of the image color.

  • Page 62: Daynight

    Dual Vision Light Load Thermal PTZ Visible-light Parameter Configuration User Manual Parameter Meaning Configuration Method It indicates the gain applied to blue channels. [Setting method] Blue Gain As the value increases, the color temperature Drag the slider. becomes higher. [Default value] This parameter is valid when Manual Mode is set to Customized.
  • Page 63 Dual Vision Light Load Thermal PTZ User Manual Visible-light Parameter Configuration Table 6-5 DNR parameters description Parameter Meaning Configuration Method D/N Setting It can be set to Auto, Day, Night or [Setting method] Timing. Mode Select a value from the drop-down list.

  • Page 64: Noise Reduction

    Dual Vision Light Load Thermal PTZ Visible-light Parameter Configuration User Manual Parameter Meaning Configuration Method It determines the night-to-day switching [Setting method] TRANSI.(N ->D)(dB) in auto mode. When the system gain is Drag the slider. smaller than the value of this parameter, [Default value] the system enters the day mode.

  • Page 65: Enhance Image

    Dual Vision Light Load Thermal PTZ User Manual Visible-light Parameter Configuration Figure 6-8 Noise Reduction interface Table 6-6 describes DNR parameters. Table 6-6 DNR parameters description Parameter Meaning Configuration Method [Configuration method] Select from the drop- down list 3D NR Reduce noise of image.
  • Page 66 Dual Vision Light Load Thermal PTZ Visible-light Parameter Configuration User Manual Figure 6-9 Enhance image interface Table 6-7 Enhance image parameters description Parameter Meaning Configuration Method [Setting method] It is used to display the foreground and Tick the WDR background at the same time in the mode and drag the environment with a large brightness slider.

  • Page 67: Zoom Focus

    Dual Vision Light Load Thermal PTZ User Manual Visible-light Parameter Configuration Parameter Meaning Configuration Method It provides a clearer view of an image in the [Setting method] fogged environment when Defog is Tick the Defog enabled. mode and drag the As the value increases, the image becomes DeFog slider.
  • Page 68 Dual Vision Light Load Thermal PTZ Visible-light Parameter Configuration User Manual Parameter Meaning Configuration Method It can be set to the auto, manual or semi-automatic mode. Auto focus mode: The system automatically triggers focus based on [Configuration application scenarios. method] Select from the Manual focus mode: You can trigger Focus Mode...

  • Page 69: Ptz Function Application

    Dual Vision Light Load Thermal PTZ User Manual PTZ Function Application PTZ Function Application 7.1 PTZ Control function Operation Description PTZ Control function is only available to a camera with an external PTZ and High Speed Dome with PTZ function. PTZ Control When browsing real-time videos shot by a dome camera or a camera connected to an external PTZ, you can control the PTZ to view Video shot in different directions.

  • Page 70: Ptz Configuration

    Dual Vision Light Load Thermal PTZ PTZ Function Application User Manual Auto Iris Click to adjust the size of the front-end iris. Auto Focus Click to adjust the focus of the front-end lens. Speed Drag the slider on to adjust the rotational speed of the PTZ. ----End 7.2 PTZ configuration 7.2.1 PTZ setting...

  • Page 71: Configure And Apply Tracks

    Dual Vision Light Load Thermal PTZ User Manual PTZ Function Application Operation procedure Step 1 Click Preset tab page in the PTZ configuration interface, the add preset page is displayed, as shown in Figure 7-3. Figure 7-3 Add Preset Step 2 Select a preset ID (such as 1) from the Preset drop-down list box and enter the name of preset.

  • Page 72: Configure And Apply Scan

    Dual Vision Light Load Thermal PTZ PTZ Function Application User Manual Figure 7-4 Add Track Step 2 Select a track ID (such as 1) from the track drop-down list box and enter the name of track. Step 3 Click , then use eight arrow keys in the PTZ control area to configure a track, then click to complete adding a track.

  • Page 73: Configure And Apply Tour

    Dual Vision Light Load Thermal PTZ User Manual PTZ Function Application Figure 7-5 Add Scan Step 2 Select Scan ID (such as 1) from the track drop-down list box and enter the name of scan. Step 3 Click , then use eight arrow keys in the PTZ control area to configure two positions, then click to complete adding a scan.

  • Page 74: Configure And Apply Idle

    Dual Vision Light Load Thermal PTZ PTZ Function Application User Manual Figure 7-6 Add Tour Step 2 Select Tour ID (such as 2) from the drop-down list box, enter the tour name. Step 3 Select first required position preset from the preset drop-down list box. Step 4 Input the values from Wait Time area box to set the time to stay in this position preset.(0 sec~ 255 sec).

  • Page 75: Configure North

    Dual Vision Light Load Thermal PTZ User Manual PTZ Function Application Figure 7-7 Idle Step 2 Select a monitor type from the Type drop-down list box. Monitor type can choose preset, Scan, track, tour and Cir Scan. Step 3 Select a name form the Name drop-down list box. Step 4 Input a value from the Wait Time area box.

  • Page 76: Configure Timer

    Dual Vision Light Load Thermal PTZ PTZ Function Application User Manual Step 2 Click to set the current position of true north. ----End 7.2.8 Configure Timer Operation procedure Step 1 Click Timer tab page in the PTZ configuration interface, the set timer page is displayed, as shown in Figure 7-9.

  • Page 77: Configure Extension

    Dual Vision Light Load Thermal PTZ User Manual PTZ Function Application Step 5 Select the required begin time at the Begin Time drop-down list box, and then select the required end time at the End Time drop-down list box. Step 6 Select the required monitor type at the PTZ type drop-down list box, you can select preset, Scan, Track, Tour in the box, and then select a specific from the Name drop- down list box.(for example preset, 1).

  • Page 78: Technical Specifications

    Dual Vision Light Load Thermal PTZ Technical Specifications User Manual Technical Specifications Table 8-1 describes the technical specifications of the all-in-one thermal imaging IP camera. Table 8-1 Technical specification Item Parameter Description Detector type Non-cooling IR focal plane sensor Material Vanadium oxide Effective Pixel 400*300...
  • Page 79 Dual Vision Light Load Thermal PTZ User Manual Technical Specifications Item Parameter Description Lens Optical Zoom features Focal Length 6.24 mm~176.17mm Focus Control Auto/Manual Color：0.001Lux @ (F1.5，AGC ON) Black White: 0.0001Lux @ (F1.5，AGC ON) Min. Illumination 0 Lux with IR Day &...
  • Page 80 Dual Vision Light Load Thermal PTZ Technical Specifications User Manual Item Parameter Description Video Compression H.265/H.264//MJPEG Formats Audio Compression G.711:8kbps；RAW_PCM:16kbps formats 1080P/30fps(lighting) ，D1/30fps（thermal） Encode Resolution/Frame features Video System PAL/NTSC Multiple Stream Support Stream Control CBR/VBR IPv4/IPv6/RTSP/RTP/RTCP/TCP/UDP/HTTP/D Network Protocol HCP/DNS/FTP/DDNS/PPPOE/SMTP/SIP Maximum User Supports up to 10 users simultaneously access Access Amount Network...
  • Page 81 Dual Vision Light Load Thermal PTZ User Manual Technical Specifications Item Parameter Description Power-off Memory Support Reset Support Network Interface RJ-45 and 10/100Base-T Audio Interface 2 input, 2 output Alarm Interface 9 input , 4 output Interface features CVBS Interface 2-channel Pan &...

  • Page 82: A Troubleshooting

    Dual Vision Light Load Thermal PTZ Technical Specifications User Manual Troubleshooting Common Possible Cause Solution Trouble  Unable to Network is not Connect the network cable of the camera to access the connected. the PC to check whether the network cable is in good contact.
  • Page 83 Dual Vision Light Load Thermal PTZ User Manual Technical Specifications Common Possible Cause Solution Trouble An error The data in the Delete the cache of the Internet Explorer. The occurs in cache of browser is steps are as follows (taking IE9 as an example): not updated in time.
  • Page 84 Dual Vision Light Load Thermal PTZ Technical Specifications User Manual Common Possible Cause Solution Trouble video) Lack of network Replacement of industrial Gigabit switches bandwidth Access decoder Replacement of high-performance performance decoder Self-test Wrong wiring Rewiring normal, Set the baud rate, Screen configuration according to device can not protocol, address...

  • Page 85: B Common Emission Rate

    Dual Vision Light Load Thermal PTZ User Manual Technical Specifications Common Emission Rate Emission Rate The emission rate is the capability of an object to emit or absorb energy. An ideal transmitter provides an emission rate of emitting 100% of intake energy. An object with an emission rate of 0.8 can absorb 80% of intake energy, and reflect the remaining 20%.
  • Page 86 Dual Vision Light Load Thermal PTZ Technical Specifications User Manual Lead (99.9% purity, No 127/260 0.06 oxidized) Copper 199/390 0.18 Cobalt 599/1110 0.19 199/390 Steel 599/1110 0.57 Tinned iron sheet (Light) 28/82 0.23 Brass(High-polish) 247/476 0.03 Brass (Tough rolled, polished 21/70 0.04 metal wire)
  • Page 87 Dual Vision Light Load Thermal PTZ User Manual Technical Specifications Brick (Red, rough) 21/70 0.93 Brick (Unglazed, rough) 1000/1832 Carbon (T - carbon 0.9% ash) 127/260 0.81 Concrete 0.94 Glass (Glossy) 22/72 0.94 Granite (Surfaced) 21/70 0.85 0/32 0.97 Marble (I Polished, grey) 22/72 0.93 Asbestos board...
