List of Commands
* When sending a sequence of commands to the unit from a controller, after each one, be sure to verify that an "ack" response is returned before
sending the next command.
* The network and password settings must be configured beforehand. When connecting, enter the password you already set.
Item
Select the program scene (PGM1 in DUAL mode)
Select the preset scene (PGM2 in DUAL mode)
Press the [CUT] button
Press the [AUTO] button
Press the [OUTPUT FADE] button
Set the [DSK] button on/off
Set the [LOGO] button on/off
Switch between MIX/WIPE
Change the WIPE pattern
Set transition time
Set the [AUTO TRANSITION] button on/off
Adjust the volume
Turn the solo function
on/off
Turn the mute function
on/off
Adjust the AUX send
level
MIC1–MIC6 channel
Adjust the pan
Adjust the reverb send
level
Turn USB send on/off
Set AUX PRE/POST
Adjust the volume
Turn the solo function
on/off
Turn the mute function
on/off
Adjust the AUX send
level
LINE1, LINE2, HDMI,
USB channel
Adjust the pan
Adjust the reverb send
level
Turn USB send on/off
Set AUX PRE/POST
Adjust the output volume
Turn the output solo function on/off
Turn the output mute function on/off
Auto mixing function on/off
Audio follow video function on/off
Adjust reverb
Sent command Response command Parameter
set,97,46,0,[a][lf ] ack,97,46,0,[a][lf ]
set,97,46,1,[a][lf ] ack,97,46,1,[a][lf ]
set,98,43,0,1[lf ] ack,98,43,0,1[lf ]
set,98,42,0,1[lf ] ack,98,42,0,1[lf ]
set,97,25,[a],[b][lf ] ack,97,25,[a],[b][lf ]
set,97,79,0,[a][lf ] ack,97,79,0,[a][lf ]
set,97,63,0,[a][lf ] ack,97,63,0,[a][lf ]
set,97,48,0,[a][lf ] ack,97,48,0,[a][lf ]
set,97,49,0,[a][lf ] ack,97,49,0,[a][lf ]
set,97,18,0,[a][lf ] ack,97,18,0,[a][lf ]
set,97,19,0,[a][lf ] ack,97,19,0,[a][lf ]
set,97,139,[a],[b][lf ] ack,97,139,[a],[b][lf ]
set,97,138,[a],[b][lf ] ack,97,138,[a],[b][lf ]
set,97,137,[a],[b][lf ] ack,97,137,[a],[b][lf ]
set,97,144,[a],[b][lf ] ack,97,144,[a],[b][lf ]
set,97,140,[a],[b][lf ] ack,97,140,[a],[b][lf ]
set,97,141,[a],[b][lf ] ack,97,141,[a],[b][lf ]
set,97,143,[a],[b][lf ] ack,97,143,[a],[b][lf ]
set,97,145,[a],[b][lf ] ack,97,145,[a],[b][lf ]
set,97,173,[a],[b][lf ] ack,97,173,[a],[b][lf ]
set,97,172,[a],[b][lf ] ack,97,172,[a],[b][lf ]
set,97,171,[a],[b][lf ] ack,97,171,[a],[b][lf ]
set,97,178,[a],[b][lf ] ack,97,178,[a],[b][lf ]
set,97,174,[a],[b][lf ] ack,97,174,[a],[b][lf ]
set,97,175,[a],[b][lf ] ack,97,175,[a],[b][lf ]
set,97,177,[a],[b][lf ] ack,97,177,[a],[b][lf ]
set,97,179,[a],[b][lf ] ack,97,179,[a],[b][lf ]
set,97,182,[a],[b][lf ] ack,97,182,[a],[b][lf ]
set,97,181,[a],[b][lf ] ack,97,181,[a],[b][lf ]
set,97,180,[a],[b][lf ] ack,97,180,[a],[b][lf ]
set,97,265,0,[a][lf ] ack,97,265,0,[a][lf ]
set,97,217,0,[a][lf ] ack,97,217,0,[a][lf ]
set,97,216,0,[a][lf ] ack,97,216,0,[a][lf ]
LAN/RS-232 Command Reference
a: 0–63 (1-1–8-8)
a: 0–63 (1-1–8-8)
a: 0 (PGM(DUAL Mode: PGM1)), 1(DUAL Mode: PGM2)
b: 0 (OFF), 1(ON)
a: 0 (OFF), 1(ON)
a: 0 (OFF), 1(ON)
a: 0 (MIX), 1(WIPE)
a: 0–3 (1–4)
a: 0–20 (0.0–2.0 sec)
a: 0 (OFF), 1(ON)
a: 0–5 (MIC1–MIC6 Channel)
b: 0–127 (Level)
a: 0–5 (MIC1–MIC6 Channel)
b: 0 (OFF), 1(ON)
a: 0–5 (MIC1–MIC6 Channel)
b: 0 (OFF), 1(ON)
a: 0–5 (MIC1–MIC6 Channel)
b: 0–127 (Level)
a: 0–5 (MIC1–MIC6 Channel)
b: -50–0–50 (L-C-R)
a: 0–5 (MIC1–MIC6 Channel)
b: 0–127 (Level)
a: 0–5 (MIC1–MIC6 Channel)
b: 0 (OFF), 1(ON)
a: 0–5 (MIC1–MIC6 Channel)
b: 0 (PRE), 1(POST)
a: 0–3 (LINE1, LINE2, HDMI, USB)
b: 0–127 (Level)
a: 0–3 (LINE1, LINE2, HDMI, USB)
b: 0 (OFF), 1(ON)
a: 0–3 (LINE1, LINE2, HDMI, USB)
b: 0 (OFF), 1(ON)
a: 0–3 (LINE1, LINE2, HDMI, USB)
b: 0–127 (Level)
a: 0–3 (LINE1, LINE2, HDMI, USB)
b: -50–0–50 (L-C-R)
a: 0–3 (LINE1, LINE2, HDMI, USB)
b: 0–127 (Level)
a: 0–3 (LINE1, LINE2, HDMI, USB)
b: 0 (OFF), 1(ON)
a: 0–3 (LINE1, LINE2, HDMI, USB)
b: 0 (PRE), 1(POST)
a: 0–3 (MAIN, AUX, USB, HDMI)
b: 0–127 (Level)
a: 0–3 (MAIN, AUX, USB, HDMI)
b: 0 (OFF), 1(ON)
a: 0–3 (MAIN, AUX, USB, HDMI)
b: 0 (OFF), 1(ON)
a: 0 (OFF), 1(ON)
a: 0 (OFF), 1(VFA), 2(AFV)
a: 0–127
