Jxx00MH/Jxx00MD/Jxx00ML Setup Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee that
interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the contents
here and specially disclaims any implied warranties of merchantability or fitness
for any purpose. Further the vendor reserves the right to revise this publication
and to make changes to the contents here without obligation to notify any party
beforehand.
Duplication of this publication, in part or in whole, is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and we
will not be responsible for any mistakes found in this user's manual. All the brand
and product names are trademarks of their respective companies.
Dichiarazione di conformità
sintetica
Ai sensi dell'art. 2 comma 3 del D.M.
275 del 30/10/2002
Si dichiara che questo prodotto è
conforme alle normative vigenti e
soddisfa i requisiti essenziali richiesti
dalle direttive
2004/108/CE, 2006/95/CE e
1999/05/CE
quando ad esso applicabili
Short Declaration of conformity
We declare this product is complying
with the laws in force and meeting all
the essential requirements as specified
by the directives
2004/108/CE, 2006/95/CE and
1999/05/CE
whenever these laws may be applied

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the J 00MH Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Biostar J 00MH Series

  • Page 1 Jxx00MH/Jxx00MD/Jxx00ML Setup Manual FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    Table of Contents Chapter 1: Introduction ............... 1 Before You Start ................. 1 Package Checklist ..............1 Motherboard Specifications ............2 Central Processing Unit (CPU) ..........4 Rear Panel Connectors ............. 3 Motherboard Layout ..............4 Chapter 2: Hardware Installation ..........5 Connect Cooling Fans ...............
  • Page 3: Chapter 1: Introduction

    Jxx00MH/Jxx00MD/Jxx00ML CHAPTER 1: INTRODUCTION 1.1 Before You Start Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below:  Prepare a dry and stable working environment with sufficient lighting.  Always disconnect the computer from power outlet before operation.
  • Page 4: Motherboard Specifications

    1x Printer Port Header 1x Serial Port Header Form Factor Micro-ATX Form Factor, 190 mm x 188 mm Windows 7 / 8 / 8.1 OS Support Biostar reserves the right to add or remove support for any OS with or without notice.
  • Page 5: Rear Panel Connectors

    Jxx00MH/Jxx00MD/Jxx00ML 1.4 Rear Panel Connectors J1800MH/ J1900MH/ J2100MH J1800MD/ J1900MD/ J2100MD J1800ML/ J1900ML/ J2100ML Note 1: Since the audio chip supports High Definition Audio Specification, the function of each audio jack can be defined by software. The input / output function of each audio jack listed above represents the default setting.
  • Page 6: Central Processing Unit (Cpu)

    Motherboard Manual 1.5 Central Processing Unit (CPU) The motherboard is equipped with an onboard Intel procrssor and a CPU cooler. Motherboard Model: Onboard Intel CPU: J1800MH/ J1800MD/ J1800ML Intel® Celeron® J1800 processor (Dual core, 1M Cache, 2.58 GHz) J1900MH/ J1900MD/ J1900ML Intel®...
  • Page 7: Chapter 2: Hardware Installation

    Jxx00MH/Jxx00MD/Jxx00ML CHAPTER 2: HARDWARE INSTALLATION 2.1 Connect Cooling Fans These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1. SYS_FAN1/2: System Fan Header Assignment Ground...
  • Page 8 Motherboard Manual Step 2: Insert the DIMM vertically and firmly into the slot until the retaining clips snap back in place and the DIMM is properly seated. Note1: The DIMM must be installed to DDR3_A1 slot first. Note2: If the DIMM does not go in smoothly, do not force it. Pull it all the way out and try again. B.
  • Page 9: Expansion Slots

    Jxx00MH/Jxx00MD/Jxx00ML 2.3 Expansion Slots PEX16_1: PCI-Express Gen2 x16 Slot PCI-Express 2.0 compliant. Data transfer bandwidth up to 8GB/s per direction; 16GB/s in total. PEX1_1: PCI-Express Gen2 x1 Slot PCI-Express 2.0 compliant. Data transfer bandwidth up to 500MB/s per direction; 1GB/s in total. Install an Expansion Card You can install your expansion card by following steps: Read the related expansion card's instruction document before...
  • Page 10: Jumper Setting

    Motherboard Manual 2.4 Jumper Setting The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”. Pin opened Pin closed Pin1-2 closed JCMOS1: Clear CMOS Header Placing the jumper on pin2-3, it allows user to restore the BIOS safe setting and the CMOS data.
  • Page 11: Headers & Connectors

    Jxx00MH/Jxx00MD/Jxx00ML 2.5 Headers & Connectors ATXPWR1: ATX Power Source Connector For better compatibility, we recommend to use a standard ATX 24-pin power supply for this connector. Make sure to find the correct orientation before plugging the connector. Assignment Assignment +3.3V +3.3V -12V +3.3V...
  • Page 12 Motherboard Manual PANEL1: Front Panel Header This 16-pin connector includes Power-on, Reset, HDD LED, Power LED, and speaker connection. It allows user to connect the PC case’s front panel switch functions. Assignment Function Assignment Function Speaker Connector Speaker Power LED (+) HDD LED (+) Power LED (+) Power LED...
  • Page 13 Jxx00MH/Jxx00MD/Jxx00ML F_USB1/F_USB2: Headers for USB 2.0 Ports at Front Panel This header allows user to connect additional USB cable on the PC front panel, and also can be connected with a wide range of simultaneously accessible external Plug and Play peripherals. Assignment +5V (fused) +5V (fused)
  • Page 14 Motherboard Manual J_COM1: Serial Port Connector The motherboard has a Serial Port Connector for connecting RS-232 Port. Assignment Carrier detect Received data Transmitted data Data terminal ready Signal ground Data set ready Request to send Clear to send Ring indicator J_PRINT1: Printer Port Connector This header allows you to connector printer on the PC.
  • Page 15: Chapter 3: Uefi Bios & Software

    CD-ROM, or from the file location on the Web. BIOSTAR BIOS Flasher BIOSTAR BIOS Flasher is a BIOS flashing utility providing you an easy and simple way to update your BIOS via USB pen drive. Note1: This utility only allows storage device with FAT32/16 format and single partition.
  • Page 16 Motherboard Manual 6. Select the proper BIOS file, and a message asking if you are sure to flash the BIOS file. Click Yes to start updating BIOS. 7. A dialog pops out after BIOS flash is completed, asking you to restart the system.
  • Page 17 Reset to restart the computer. Then, the BIOS Update is completed. BIOS Update Utility (through a BIOS file) 1. Installing BIOS Update Utility from the DVD Driver. 2. Download the proper BIOS from http://www.biostar.com.tw/ 3. Launch BIOS Update Utility and click the Update BIOS button on the main screen.
  • Page 18 Motherboard Manual 4. A warning message will show up to request your agreement to start the BIOS update. Click OK to start the update procedure. 5. Choose the location for your BIOS file in the system. Please select the proper BIOS file, and then click on Open.
  • Page 19: Software

    Jxx00MH/Jxx00MD/Jxx00ML 3.3 Software Installing Software Insert the Setup DVD to the optical drive. The driver installation program would appear if the Auto-run function has been enabled. Select Software Installation, and then click on the respective software title. Follow the on-screen instructions to complete the installation. Launching Software After the installation process is completed, you will see the software icon showing on the desktop.
  • Page 20 Motherboard Manual eHot-Line eHot-Line is a convenient utility that helps you to contact with our Tech-Support system. This utility will collect the system information which is useful for analyzing the problem you may have encountered, and then send these information to our tech-support department to help you fix the problem.
  • Page 21 Note2: If you are not using Outlook Express as your default e-mail client application, you may need to save the system information to a .txt file and send the file to our tech support with other e-mail application. Go to the following website http://www.biostar.com.tw/app/en/about/contact.php getting our contact information.
  • Page 22: Chapter 4: Useful Help

    Motherboard Manual CHAPTER 4: USEFUL HELP 4.1 Driver Installation After you installed your operating system, please insert the Fully Setup Driver DVD into your optical drive and install the driver for better system performance. You will see the following window after you insert the DVD The setup guide will auto detect your motherboard and operating system.
  • Page 23: Ami Bios Beep Code

    Jxx00MH/Jxx00MD/Jxx00ML 4.2 AMI BIOS Beep Code Boot Block Beep Codes Number of Beeps Description Continuing Memory sizing error or Memory module not found POST BIOS Beep Codes Number of Beeps Description Success booting. Display memory error (system video adapter) 4.3 Troubleshooting Probable Solution There is no power in the system.
  • Page 24 Motherboard Manual CPU Overheated If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again. In this case, please double check: The CPU cooler surface is placed evenly with the CPU surface.
  • Page 25: Appendix: Spec In Other Languages

    ‫دي‬ ‫دي‬ ‫اﻟﺬاآﺮة‬ DDR3L ‫ار‬ ‫دي‬ ‫ﺟﻴﺠﺎﺑﺎﻳﺖ دي‬ ‫ﻣﻴﺠﺎ ﺑﺎﻳﺖ‬ ‫ﺗﺘﺤﻤﻞ دون‬ DIMM ‫آﻞ ﻓﺘﺤﺔ ﻣﺰدوﺟﺔ‬ ‫ﻟﻘﺎﺋﻤﺔ دﻋﻢ اﻟﺬاآﺮة‬ www.biostar.com.tw ‫ﻳﺮﺟﻰ اﻟﺮﺟﻮع إﻟﻰ اﻟﻤﻮﻗﻊ‬ ‫اﻟﺜﺎﻧﻴﺔ‬ ‫ﻳﺖ‬ ‫ﺟﻴﺠﺎ ﺑﺎ‬ SATA 3 ‫ﺳﺎﺗﺎ‬ ‫وﺻﻠﺔ‬ ‫اﻟﺘﺨﺰﻳﻦ‬ AHCI ‫ﺗﺘﺤﻤﻞ راﻳﺪ اﻷم‬ Jxx00MH/ Jxx00MD: REALTEK RTL 8111G ‫رﻳﻴﺎﻟﺘﻴﻚ...
  • Page 26: French

    1x Embase port imprimante 1x Embase port série Facteur Facteur d'encombrement Micro-ATX, 190 mm x 188 mm d'encombrement Windows 7 / 8 / 8.1 Support SE Biostar se réserve le droit d’ajouter ou d'enlever le support pour toute SE avec ou sans préavis.
  • Page 27: German

    1x Header für klares CMOS 1x Header für Druckerport 1x Serieller Port-Header Formfaktor Micro-ATX Formfaktor, 190 mm x 188 mm Windows 7 / 8 / 8.1 OS-Unterstützung Biostar reserves the right to add or remove support for any OS with or without notice.
  • Page 28: Italian

    Distributore Slot Serie x1 Fattore di Forma Fattore di Forma Micro-ATX, 190 mm x 188 mm Windows 7 / 8 / 8.1 Supporto SO Biostar si riserva il diritto di aggiungere o ritirare il supporto per qualsiasi SO con o senza preavviso.
  • Page 29: Japanese

    1x フロント パネル ヘッダー 1x フロント オーディオ ヘッダー 1x クリア CMOS ヘッダー 1x プリンター ポート ヘッダー 1x シリアル ポート ヘッダー Micro-ATX フォーム ファクタ、190 mm x 188 mm フォーム ファクタ Windows 7 / 8 / 8.1 サポート OS Biostar には、通知なしでサポート OS を変更する権限があります。...
  • Page 30: Polish

    Złącze bezpośrednie CMOS x1 Złącze port drukarki x1 Port szeregowy x1 Obudowa Obudowa Micro-ATX, 190 mm x 188 mm Windows 7 / 8 / 8.1 Obsługa OS Biostar zastrzega sobie prawo do dodania lub wycofania obsługi dla OS, z wypowiedzeniem lub bez wypowiedzenia.
  • Page 31: Portuguese

    Dispositivo Porta Série x1 Fator de Fôrma Fator de Fôrma Micro-ATX, 190 mm x 188 mm Windows 7 / 8 / 8.1 Suporte OS Biostar reserva seu direito de adicionar ou retirar o suporte para qualquer OS com ou sem notificação.
  • Page 32: Russian

    1 контакт микросхемы Clear CMOS 1 контакт порта принтера 1 контакт последовательного порта Конструктив Форм-фактор Micro-ATX, 190мм x 188 мм Windows 7 / 8 / 8.1 Поддержка ОС Biostar оставляет за собой право добавлять или удалять поддержку любой ОС, с уведомлением или без.
  • Page 33: Spanish

    Distribuidor Ranura Serie x1 Factor de Forma Factor de Forma Micro-ATX, 190 mm x 188 mm Windows 7 / 8 / 8.1 Soporte OS Biostar reserva su derecho de añadir o retirar el soporte para cada OS con o sin notificación. 2014/05/29...
