This equipment has been tested and found to comply with the limits of a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. There is no guarantee that interference
will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the contents here and
specially disclaims any implied warranties of merchantability or fitness for any purpose. Further
the vendor reserves the right to revise this publication and to make changes to the contents here
without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first obtaining the
vendor's approval in writing.
The content of this user's manual is subject to be changed without notice and we will not be
responsible for any mistakes found in this user's manual. All the brand and product names are
trademarks of their respective companies.

FCC Information and Copyright

Dichiarazione di conformità sintetica
Ai sensi dell'art. 2 comma 3 del D.M. 275 del
30/10/2002
Si dichiara che questo prodotto è conforme
alle normative vigenti e soddisfa i requisiti
essenziali richiesti dalle direttive
2004/108/CE, 2006/95/CE e 1999/05/CE
quando ad esso applicabili
Short Declaration of conformity
We declare this product is complying with the
laws in force and meeting all the essential
requirements as specified by the directives
2004/108/CE, 2006/95/CE and 1999/05/CE
whenever these laws may be applied

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the J1800NH3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Biostar J1800NH3

  • Page 1: Fcc Information And Copyright

    FCC Information and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 2: Table Of Contents

    Table Of Contents FCC Information and Copyright ������������������������������������������������������������������������������� 1 Chapter 1: Introduction ������������������������������������������������������������������������������������������� 3 1.1 Before You Start ........................3 1.2 Package Checklist ........................ 3 1.3 Specifications ........................4 1.4 Rear Panel Connectors ......................5 1.5 Motherboard Layout ......................6 Chapter 2: Hardware installation �����������������������������������������������������������������������������...
  • Page 3: Chapter 1: Introduction

    J1800NH3 Chapter 1: Introduction 1�1 Before You Start Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below: •  Prepare a dry and stable working environment with sufficient lighting. •  Always disconnect the computer from power outlet before operation.
  • Page 4: Specifications

    1x Serial Port Header Form Factor Mini-ITX Form Factor, 170 mm x 170 mm Windows 7/ 8/ 8.1/ 10(32bit/64bit) OS Support Biostar reserves the right to add or remove support for any OS with or without notice. 4 | Chapter 1: Introduction...
  • Page 5: Rear Panel Connectors

    J1800NH3 1.4 Rear Panel Connectors Note »  HDMI & VGA ports only work with an Intel® integrated Graphics Processor. »  Maximum resolution HDMI: 1920 x 1200 @60Hz VGA: 2560 x 1600 @60Hz   » Since the audio chip supports High Definition Audio Specification, the function of each audio jack can be defined by software. The input / output function of each audio jack listed above represents the default setting. However, when connecting external microphone to the audio port, please use the Line In (Blue) and Mic In (Pink) audio jack. The 2/ 4/ 5.1/ 7.1-channel configuration Audio Port 2-channel 4-channel 5.1 channel 7.1 channel Blue (Rear Panel) Line In Line In Line In...
  • Page 6: Motherboard Layout

    1.5 Motherboard Layout Note »  represents the 1st pin. 6 | Chapter 1: Introduction...
  • Page 7: Chapter 2: Hardware Installation

    J1800NH3 Chapter 2: Hardware installation 2.1 Connect Cooling Fans These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.
  • Page 8 Step 1: Align a DIMM on the slot such that the notch on the DIMM matches the break on the Slot. Step 2: Insert the DIMM firmly into the slot until the retaining chip snap back in place and the DIMM is properly seated.
  • Page 9: Expansion Slots

    J1800NH3 2.3 Expansion Slots PEX1_1: PCI-Express Gen2 x1 Slot •  PCI-Express 2.0 compliant. •  Data transfer bandwidth up to 500MB/s per direction; 1GB/s in total. Install an Expansion Card You can install your expansion card by following steps: •  Read the related expansion card’s instruction document before install the expansion card into the computer.
  • Page 10: Jumper & Switch Setting

    2.4 Jumper & Switch Setting The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”. Pin opened Pin closed Pin 1-2 closed JCMOS1: Clear CMOS Jumper The jumper allows users to restore the BIOS safe setting and the CMOS data.
  • Page 11: Headers & Connectors

    J1800NH3 2.5 Headers & Connectors ATXPWR1: ATX Power Source Connector For better compatibility, we recommend to use a standard ATX 24-pin power supply for this connector. Make sure to find the correct orientation before plugging the connector. Assignment Assignment +3.3V +3.3V...
  • Page 12 PANEL1: Front Panel Header This 16-pin header includes Power-on, Reset, HDD LED, Power LED, and speaker connection. Pin Assignment Function Pin Assignment Function 10 N/A Speaker Connector 11 N/A Speaker 12 Power LED (+) HDD LED (+) Hard drive 13 Power LED (+) Power LED HDD LED (-) 14 Power LED (-)
  • Page 13 J1800NH3 F_AUDIO1: Front Panel Audio Header This header allows user to connect the chassis-mount front panel audio I/O which supports HD and AC’97 audio standards. HD Audio AC’97 Assignment Pin Assignment Mic Left in Mic In Ground Ground Mic Right in...
  • Page 14 J_COM1: Serial Port Header The motherboard has a serial port header for connecting RS-232 Port. Assignment Carrier detect Received data Transmitted data Data terminal ready Signal ground Data set ready Request to send Clear to send Ring indicator 14 | Chapter 2: Hardware installation...
  • Page 15: Chapter 3: Uefi Bios & Software

    The BIOS can be updated using either of the following utilities: •  BIOSTAR BIO-Flasher: Using this utility, the BIOS can be updated from a file on a hard disk, a USB drive (a flash drive or a USB hard drive), or a CD-ROM.
  • Page 16 6. Select the proper BIOS file, and a message asking if you are sure to flash the BIOS file. Click “Yes” to start updating BIOS. 7. A dialog pops out after BIOS flash is completed, asking you to restart the system. Press the <Y> key to restart system.
  • Page 17 Then, the BIOS Update is completed. BIOS Update Utility (through a BIOS file) 1. Installing BIOS Update Utility from the DVD Driver. 2. Download the proper BIOS from http://www.biostar.com.tw/ 3. Launch BIOS Update Utility and click the “Update BIOS” button on the main screen.
  • Page 18 5. Choose the location for your BIOS file in the system. Please select the proper BIOS file, and then click on “Open”. It will take several minutes, please be patient. 6. After the BIOS Update process is finished, click on “OK” to reboot the system. 7.
  • Page 19: Software

    J1800NH3 3.3 Software Installing Software Insert the Setup DVD to the optical drive. The driver installation program would appear if the Auto-run function has been enabled. Select Software Installation, and then click on the respective software title. Follow the on-screen instructions to complete the installation.
  • Page 20: Chapter 4: Useful Help

    Chapter 4: Useful help 4.1 Driver Installation After you installed your operating system, please insert the Fully Setup Driver DVD into your optical drive and install the driver for better system performance. You will see the following window after you insert the DVD The setup guide will auto detect your motherboard and operating system.
  • Page 21: Ami Bios Beep Code

    J1800NH3 4.2 AMI BIOS Beep Code Boot Block Beep Codes Number of Beeps Description Continuing Memory sizing error or Memory module not found POST BIOS Beep Codes Number of Beeps Description Success booting. Display memory error (system video adapter) 4.3 Troubleshooting...
  • Page 22 CPU Overheated If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated. When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again. In this case, please double check: 1.
  • Page 23: Appendix I: Specifications In Other Languages

    J1800NH3 APPENDIX I: Specifications in Other Languages Arabic ‫اﻟﻤﻮاﺻﻔﺎت‬ ® ® Intel Celeron J1800 processor ‫ﻗﺎﻋﺪة وﺣﺪة اﻟﻤﻌﺎﻟﺠﺔ اﻟﻤﺮآﺰﻳﺔ‬ DDR3L 1333(1.35V/1.5V) ‫واﺣﺪة ﻗﻨ � ����ﺎة ﻳ � ���ﺪﻋﻢ‬ ‫ﺟﻴﺠﺎﺑﺎﻳﺖ ذاآﺮة‬ ‫، ﺗﺘﺤﻤﻞ آﺤﺪ أﻗﺼﻰ‬ SO-DIMM ‫ﻓﺘﺤﺎت اﻟﺬاآﺮة اﻟﻤﺰدوﺟﺔ‬ DDR3L ‫. ار‬...
  • Page 24: German

    1x Serieller Port-Header Formfaktor Mini-ITX Formfaktor, 170 mm x 170 mm Windows 7/ 8/ 8.1/ 10(32bit/64bit) OS-Unterstützung Biostar reserves the right to add or remove support for any OS with or without notice. 24 | APPENDIX I: Specifications in Other Languages...
  • Page 25: Russian

    1 контакт последовательного порта Конструктив Форм-фактор Mini-ITX, 170мм x 170 мм Windows 7/ 8/ 8.1/ 10(32bit/64bit) Поддержка ОС Biostar оставляет за собой право добавлять или удалять поддержку любой ОС, с уведомлением или без. APPENDIX I: Specifications in Other Languages | 25...
  • Page 26: Spanish

    Factor de Forma Mini-ITX, 170 mm x 170 mm Windows 7/ 8/ 8.1/ 10(32bit/64bit) Soporte OS Biostar reserva su derecho de añadir o retirar el soporte para cada OS con o sin notificación. 26 | APPENDIX I: Specifications in Other Languages...
  • Page 27: Thai

    สนั บ สนุ น OS Biostar ขอสงวนสิ ท ธิ ์ ใ นการเพิ ่ ม หรื อ ถอดการสนั บ สนุ น สำ า หรั บ ระบบปฏิ บ ั ต ิ ก าร OS ต่ า งๆ โดยไม่ ต ้ อ งแจ้ ง ให้ ท ราบล่ ว งหน้ า...
  • Page 28 this page intentionally left blank 28 | APPENDIX I: Specifications in Other Languages...
